- Page 1 Mini Soil Conditioner Mini Skid Steer Loaders Mini Track Loaders Operator’s Manual Set-Up Assembly Maintenance Parts Information Read this Manual Before Use...
-
Page 2: Table Of Contents
Serial Number………….. YOUR ATTACHMENTS DEALER ADDRESS: PHONE: CONTACT: NOTE: Erskine Attachments LLC reserves the right to make improvements in design or changes in specifications at any time without notice and without incurring any obligations to install them on units previously sold. -
Page 3: Safety
Indicates potentially Erskine Attachments LLC cannot anticipate every hazardous situation which, if not avoided, possible circumstance that might involve potential will result in death or serious injury. hazard. The safety messages found in this manual and on the machine are therefore not all inclusive. - Page 4 • Do not modify equipment or add attachments that • Avoid the hazard by relieving the are not approved by Erskine Attachments LLC. pressure before disconnecting • Use adequate safety warning lights and devices hydraulic lines.
-
Page 5: Serial Number/Decal Location
SERIAL NUMBER AND SAFETY DECAL LOCATIONS Serial Number Location: It is important to refer to the serial number of the attachment when making repairs or ordering parts. Early or later models (identification made by serial number) may use different parts, or it may be necessary to use different procedures in doing a specific operation. - Page 6 Mini Brand Decal The locations of the safety decals are shown. Location: On each side of sub frame If these decals are missing, damaged, or Quantity: 2 painted over they must be replaced. Call Erskine Attachments LLC (218-435-4045) for replacement decals.
-
Page 7: Users Instructions For Mounting The Mini Soil Conditioner
USER’S INSTRUCTIONS FOR MOUNTING THE MINI SOIL CONDITIONER__ After uncrating the attachment, use the following procedure to mount the attachment to the loader. Coupler wedges or pins must extend through the holes in attachment. Levers must be fully down and locked. Failure to secure wedges or pins can allow attachment to come off and cause injury or death. - Page 8 USER’S INSTRUCTIONS FOR MOUNTING THE MINI SOIL CONDITIONER_ Attaching Hydraulics: 1. Connect the hydraulic quick couplers from the attachment to the loader. Be sure to thread the hoses through the hose holder on the loader. Bungee straps can be used as an alternate method of securing the hoses.
-
Page 9: Operating The Mini Soil Conditioner
OPERATING THE MINI SOIL CONDITIONER Getting Started IMPORTANT: Always operate the attachment with the loader arms fully lowered. (see diagrams below) 1. If the soil is very hard or compacted, break up the ground before using this attachment. CORRECT LOADER ARM POSITION 2. - Page 10 OPERATING THE MINI SOIL CONDITIONER____________ Adjusting Working Depth – Rigid Style Adjust the working depth by moving the quick- release pins to the desired holes in the wheel arm supports. See figure for approximate working depth of each pin setting. Once depth pins are set, depth adjustments can be made during operation by adjusting the tilt of the loader mount plate.
- Page 11 OPERATING THE MINI SOIL CONDITIONER Clearing Usually, clearing an area of rocks is the final operation, except for areas that have abundant rocks. When clearing rocks, it is necessary to set the Mini Soil Conditioner at a very shallow depth, just touching the soil.
-
Page 12: Routine Maintenance
ROUTINE MINI SOIL CONDITIONER MAINTENANCE_______ Lower the attachment to rest on the skid shoes and rear roller, shut down the engine, relieve the hydraulic pressure to the attachment, wait for all motion to stop, and set park brake before leaving the operator’s seat to perform service of any kind. It is the operator’s responsibility to make daily inspections of the attachment and loader for damage, loose bolts, fluid leaks, or anything else that could cause a potential service or safety problem. - Page 13 ROUTINE MINI SOIL CONDITIONER MAINTENANCE Lubrication (continued) Grease both lower float arm pivot bushings after every 8 hours of operation. Grease the rotor bearing after every 8 hours of operation. Grease the wheel bearings after every 4 hours of operation.
-
Page 14: Set Up Assembly
SET UP ASSEMBLY OF THE MINI SOIL CONDITIONER The mini soil conditioner is shipped with the caster wheel arms in a reversed position. To place them in the working position, remove the pin or bolt from hole A and remove the wheel arm fully. Align the arm bushing in hole B with the tire out in front of the attachment, and install the bolt in hole B. -
Page 15: Set Up Assembly Of The Generic Control Harness
SET UP ASSEMBLY OF THE GENERIC CONTROL HANDLE HARNESS Mounting the generic control handle wire harness will vary from loader to loader. Use these instructions as a general guide. You may need to drill holes to mount pieces of this harness. Mounting hardware is not included. -
Page 16: Parts Information
MINI SOIL CONDITIONER RIGID PARTS INFORMATION... - Page 17 MINI SOIL CONDITIONER RIGID PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NUMBER 400201 DRUM 48 W/A 400212 DRUM 60 W/A 400200 MOTOR MOUNT W/A 400203 MAIN FRAME 48 W/A 400213 MAIN FRAME 60 W/A 400204 TIRE ARM W/A 400205 TIRE SPINDLE W/A 400000 MOUNT FRAME TORO MINI W/A OPTIONAL MOUNT PACKAGE...
- Page 18 MINI SOIL CONDITIONER FLOAT PARTS INFORMATION...
- Page 19 MINI SOIL CONDITIONER FLOAT PARTS INFORMATION ITEM PART NO. DESCRIPTION STOCK NUMBER 400201 DRUM 48 W/A 400212 DRUM 60 W/A 400200 MOTOR MOUNT W/A 400203 MAIN FRAME 48 W/A 400213 MAIN FRAME 60 W/A 400204 TIRE ARM W/A 400205 TIRE SPINDLE W/A 400000 MOUNT FRAME TORO MINI W/A OPTIONAL MOUNT PACKAGE...
- Page 20 MINI SOIL CONDITIONER PARTS INFORMATION__________ Manual Option Hydraulic Option...
-
Page 21: Manual Option
MINI SOIL CONDITIONER PARTS INFORMATION__________ MANUAL OPTION PART ITEM NUMBER DESCRIPTION STOCK NUMBER 400287 HOSE 1/2X34 10MB-10FJX 400288 HOSE 1/2X80 10FJX-8FJX 400289 HOSE 1/2X112 10MB-8FJX 200170 MOTOR 300214 ADPT NIPPLE 10MJ-10MJ HYDRAULIC OPTION PART ITEM NUMBER DESCRIPTION STOCK NUMBER 400287 HOSE 1/2X34 10MB-10FJX 400288 HOSE 1/2X80 10FJX-8FJX... - Page 22 WIRE HARNESS PARTS INFORMATION______________ REF. PART NO. DESCRIPTION QTY. PKG WIRE HRN GENERIC MINI ………………………………. 1 300248 HRN WIRE LOWER MINI ……………………………………….. 1 300244 CONN 4-WAY TRAILER MALE ………………………………… 1 200083 CONN 4-WAY TRAILER FEMALE ……………………………... 1 200079 HRN WIRE UPPER MINI ………………………………………... 1 300243 SWITCH DPDT ……………………………………………………...
-
Page 23: General Specifications
MINI SOIL CONDITIONER GENERAL SPECIFICATIONS Model Mini SC 48 Rigid Mini SC 48 Float Mini SC 60 Rigid Mini SC 60 Float Working Width 48” 60” Working Width Angled 43.5” 54.4” Overall Width 56.75” 68.75” Overall Length 49” 55.5” 49”... -
Page 24: Bolt Torque Information
BOLT TORQUE INFORMATION... -
Page 25: Notes
NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________... - Page 26 NOTES ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________ ____________________________________________________...
-
Page 27: Warranty
Erskine Attachments, LLC to improve its products whenever it is possible and practical to do so. Erskine Attachments, LLC reserves the right to make changes and or add improvements at any time without incurring any obligation to make such changes or add such improvements to products previously sold. - Page 28 P/N 300440-A Date Printed: 2/22/2021 Printed in U.S.A. Erskine Attachments LLC...
