RLRB SERIES RADIANT CHAR BROILERS
For Your Safety
Do NOT store or use gasoline or
other flammable vapors and liquids
in the vicinity of this, or any other
equipment.
11990 Rivera Rd. Santa Fe Springs, CA 90670
Telephone: (714) 547-9218 (562) 464 – 9901
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operation and maintenance instructions
thoroughly before installing or servicing this equipment.
www.connertoncooking.com
Installation,
Operation &
Maintenance
Instructions
Warning!
1
