CRB SERIES RADIANT BROILERS
For Your Safety
Do NOT store or use gasoline or other
flammable vapors and liquids in the
vicinity of this, or any other
equipment.
Telephone:(714) 547-9218
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operation and maintenance instructions
thoroughly before installing or servicing this equipment.
11990 Rivera Rd. Santa Fe Springs, CA 90670
www.connertoncooking.com
Installation,
Operation &
Maintenance
Instructions
Warning!
(562) 464 - 9901
1
Advertisement
Related Manuals for Connerton CRB Series
Summary of Contents for Connerton CRB Series
- Page 1 Installation, Operation & Maintenance Instructions CRB SERIES RADIANT BROILERS For Your Safety Warning! Do NOT store or use gasoline or other Improper installation, adjustment, alteration, service or flammable vapors and liquids in the maintenance can cause property damage, injury or death.
- Page 2 To Purchaser After installation of your broiler, immediately contact your local gas supplier to obtain information in the event the user of your equipment smells gas. This information must be posted in a prominent location. To User RETAIN THIS MANUAL FOR FUTURE USE Upon receipt of this broiler, inspect it thoroughly for any damage which may have occurred during shipment.
- Page 3 3- Gas Piping: Make sure the gas pressure regulator supplied with the broiler is installed correctly. Connect outlet side of regulator to broiler. The regulator is set at 4 inches w.c. on natural gas and 11 inches w.c. on propane gas. A 1/8” pressure tap is provided on the gas manifold at the front of the broiler for checking the gas pressure.
- Page 4 CRB RADIANT BROILERS 30-400-DS body 30-350-00 pilot stem & tip 30-425-DS front panel 30-300-DS gas manifold pipe 30-450-DS grease pan 00-225-00 pilot valve 30-100-00 4 bar top grate (3x22.5) 00-250-00 manual control valve 30-100-01 **modified top grate (6x22.5) 00-500-00 chrome knob 30-125-00 cast iron radiant 13a 15-251-02 **brushed s/s knob 30-150-00 tubular burner...
-
Page 5: Troubleshooting Guide
Effective January 2020 CONNERTON (Company) warrants to the original owner that the product be free from defects in materials and/or workmanship. This warranty shall apply to units properly installed in a static location only and be in effect for two (2) years from the date of purchase but shall not exceed 30 months from the date of shipment from the Company. - Page 6 CONNERTON parts. Damage resulting from the use of or exposure to harsh chemicals or improper cleaning procedures. Damages caused by flood, fire or other acts of nature. The Company shall not be responsible or liable for any incidental or consequential damage and/or injury, claims of loss of use, loss of product or profit.
