Fine Cooking Equipment For Over
MODEL A-1F OVER/UNDER BROILER
For Your Safety
Do NOT store or use gasoline or
other flammable vapors and liquids
in the vicinity of this, or any other
appliance.
After installation of your broiler, immediately contact your local gas supplier to obtain
information in the event the user of your equipment smells gas. This information must be
posted in a prominent location.
Upon receipt of this broiler, inspect it thoroughly for any damage which may have occurred during
shipment. If damage is observed, contact the delivery agency immediately.
1. Preparation For Installation:
upon it's proper installation. It should be installed in accordance with the National Fuel Gas Code
Z223.1
, these instructions, and applicable State and Local Codes.
Installation must be made by a licensed plumber.
Initial setup must be made by a licensed service company.
A gas pressure regulator is supplied with your broiler. The regulator must be installed before connecting
broiler to gas supply line.
Install regulator in a drip-free area.
The broiler and it's individual shutoff valve must be disconnected from the gas supply piping system
during any pressure testing of that system at test pressures in excess of 1/2 psig (3.45 kPa).
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operation and maintenance
instructions thoroughly before installing or servicing this
equipment.
To Purchaser
RETAIN THIS MANUAL FOR FUTURE USE
Safe and satisfactory operation of the broiler depends, to a great extent,
Please note: air vent can plug with grease, thereby shutting gas supply off.
Connennon
5199 E. Pacific Coast HWY Suite# 310 Long Beach, CA 90804
Telephone: (714) 547-9218 Fax: (714) 547-1969
www.connertoncooking.com
80
Years
Warning!
To User
Installation,
Operation &
Maintenance
Instructions
Advertisement
Related Manuals for Connerton A-1F
Summary of Contents for Connerton A-1F
- Page 1 Installation, Operation & Maintenance Instructions Fine Cooking Equipment For Over Years MODEL A-1F OVER/UNDER BROILER For Your Safety Warning! Do NOT store or use gasoline or Improper installation, adjustment, alteration, service or other flammable vapors and liquids maintenance can cause property damage, injury or death.
- Page 2 Ceramic radiants are boxed and placed in grease pan for shipment. Remove top griddle plate and carefully place them over top burners like a saddle. 2. Clearances And Ventilation: This appliance is design certified for installation on combustible floors and adjacent to combustible walls.
- Page 3 Operator Notes: 1. Flexible Gas Line: To prolong the life, it is important that the flexible gas line is not twisted or bent while installing same. Carefully follow instructions, using two wrenches. Also, do not operate broiler with the inner track pulled out, as this will cause excessive wear and breakage of the flexible gas line. 2.
- Page 4 Installing Radiants: Carefully remove radiant from it’s shipping container. Radiants are made from ceramic material and are easily chipped or broken. Position radiant over top burner. Lower radiant onto burner, aligning holes in the top of the radiant with the tabs extending from the burner. Check radiant to make sure that it is centered and resting on top of the burner, held in position by the tabs on the burner.
-
Page 5: Preventative Maintenance
PREVENTATIVE MAINTENANCE Overview: Daily: Grease chute must be kept clear and clean. Clean griddle surfaces with grill screens and/or 3M-type coarse blending or cleaning pad. Remove stainless steel side and back liners, clean and replace. Drain and clean the grease pan. Weekly: Check thermostat calibration with surface thermometer. - Page 6 Monthly Preventative Maintenance: Checking Leveling Rods: There are two leveling rods that adjust the lower griddle plate. Each rod has two adjusting nuts at the top end, just behind the face plate of the bottom grill. The lower nut adjusts the pitch of the back of the grill, and the upper nut tightens to secure the firm tension of the leveling rod.
- Page 7 The orifice caps must be kept clean. To clean the orifices, use the following guidelines: Remove the orifices to clean them. Clean hole in orifice hood with a toothpick from the inside to the outside , being careful not to break the toothpick off inside the orifice. If cleaned while installed on orifice assembly, grease will be pushed into the hood and will eventually re-plug the hole.
- Page 8 18-L/R 24-B 22-A 24-C 24-B 46-C 46-B Model A1-F Parts List Ceramic Radiant Removable Back Liner Top Burner 18-L Removable Side Liner (left) Top Lighter Tube (R & L) 18-R Removable Side Liner (right) Bracket For Lighter Tube Flexible Gas Connector Top Lighter Tube Orifice Track Support Top Manifold (left)
- Page 9 26-A 34-B 35-B 31-A Model A1-F Parts List (Cont.) Bottom Griddle Plate Bottom Pilot Bottom Carryover Tube 35-B Tubing for Bottom Pilot 26-A Carryover Tube Bracket Bottom Carryover Orifice Bottom Burner Orifice Bottom Griddle Support Frame Bottom Manifold w/Orifices Support Frame Leveling Rod Mechanism Trim Panel Axis Shaft Mechanism Drawer Handle...
- Page 10 FLEXIBLE GAS CONNECTOR INSTRUCTIONS To prolong the life of your flexible gas connector, it is important that the following instructions be precisely adhered to. The connector is provided with hex-shaped fittings on each end. Fitting ‘A’ should be held firmly with a wrench and not allowed to turn while a second wrench is used to tighten fitting ‘B’.
-
Page 11: Troubleshooting Guide
TROUBLESHOOTING GUIDE Condition Probable Cause Solution Small/no burner flame Regulator failure Unplug regulator vent hole or replace regulator. Plugged orifice cap Unplug hole with toothpick or replace orifice. Plugged burner port Unplug burner port(s). No top burner flame Gas orifices Unplug orifice hole with toothpick or replace orifice. -
Page 12: Limited Warranty
LIMITED WARRANTY The Connerton warrants to the original user for a period of one year from date of installation, not to exceed 18 months from date of shipment by Connerton, that the equipment manufactured is free from defects in material or workmanship.
