- Page 1 All manuals and user guides at all-guides.com Sensing & Inspection Technologies Druck UPS-II Loop Calibrator User manual - K0434 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 2: Approved Service Agents
All manuals and user guides at all-guides.com Approved Service Agents For the list of service centres visit our web site: www.gesensinginspection.com Symbols This equipment meets the requirements of all relevant European safety directives. The equipment carries the CE mark. Do not dispose of this product as household waste. -
Page 3: Operation
All manuals and user guides at all-guides.com Introduction The Druck UPS-II Loop Calibrator can supply power (source mode) and produce readings (measure mode) to perform field calibrations on 2-wire devices. Operation For different applications place switches in position as indicated below:... - Page 4 All manuals and user guides at all-guides.com To output these currents automatically select "fixed steps" and press keys simultaneously. Time between steps is 10 seconds. Stepping starts at the low end of span. To return to manual press Valve mode In the valve mode, stepping will be 3,8 - 4 - 4,2 or 19 - 20 - 21 mA.
- Page 5 All manuals and user guides at all-guides.com UPS-II Loop Calibrator Technical Notes Current reading Switch positions Loop power Function Read Ext. Transmitter Calibration Switch positions Loop power Function Read Int. K0434 Issue No. 2 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 6 All manuals and user guides at all-guides.com Transmitter Simulation Switch positions Loop power Function Ext. Valve Stroking Switch positions Loop power Function Int. K0434 Issue No. 2 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 7 All manuals and user guides at all-guides.com Calibration Instructions General A calibration period of 12 months is recommended. The actual calibration interval depends on instrument usage and the total measurement uncertainty acceptable for the specified application. The UPS-II is a precise measuring instrument and the test equipment and conditions of test must be suitable for the type of work.
-
Page 8: Calibration Check
All manuals and user guides at all-guides.com Calibration Check Check the instrument for accuracy in measure and source modes, if there is an error greater than the permitted error, the instrument requires a calibration adjustment. Calibration Adjustment Note: For complete accuracy, the measure mode and source mode adjustment must be carried together and in the following order. - Page 9 All manuals and user guides at all-guides.com Source mode Connect the UPS-II to the electrical calibrator. Switch on the electrical calibrator and allow it to thermally stabilise. Switch on the UPS-II and allow the instrument to thermally stabilise. Select INT on the LOOP PWR slide switch. Use the display menu to select the calibration values: Calibration Procedure mA Output 2 seconds...
-
Page 10: Specifications
All manuals and user guides at all-guides.com Specifications Range..................0 to 22.2 mA Accuracy................ 0,05% of range Resolution..............10 microamps Temperature effect......0,003%/°C - 0,0015%/°F Internal loop power...........24 VDC stabilized External loop power............48 VDC max. Measurement input........... 12 ohms fused Drive capability..............
