- Page 1 Wall hung, fanflue, roomsealed, high efficiency gas boiler User manual and Installation instructions ANTARES Product name Models G.C. Appl. No. ANTARES 30S M300V.30 SR 41-583-41...
- Page 2 The Biasi ANTARES allow a higher efficiency by reducing the flue gas temperature such that the water vapour formed during the combustion is condensed out.
- Page 3 Remember that... The manual must be read thoroughly, so that you will be able to use the boiler in a safe and sensible way and must be carefully kept. It may be necessary for reference in the future. The first firing must be carried out by a competent and responsible Gas Safe engineer. The manufacturer •...
-
Page 4: Safe Handling Of Substances
On completion of the work, have a professionally qualified person check there efficiency. Repairs (under guarantee) must be carried out only by a Biasi an approved engineer, us- ing genuine spare parts. Thus do no more than switching off the boiler yourself (see the instructions). - Page 5 Combustion chamber panels Material: mineral fibres Known hazards - Some people can suffer reddening and itching of the skin. Fibre entry into the eye will cause foreign body irritation, which can cause severe irritation to people wearing contact lenses. Irritation to respiratory tract. Precautions - Dust goggles will protect eyes.
- Page 6 If you are in any doubts as to the installation or operation of the boiler please read the instruction manuals thoroughly and then if necessary contact Biasi UK for advice and as- sistance.
-
Page 7: Table Of Contents
10 MAINTENANCE..... 74 Technical data ANTARES 30S (M300V.30 SR) 34 10.1 Warnings......74 5 GENERAL REQUIREMENTS . -
Page 8: Appliance Description
APPLIANCE DESCRIPTION APPLIANCE DESCRIPTION Isolation valves The figures in this manual only Overview show one of the possible ways of installing cocks, pipes and fit- The model and serial number of the boiler is tings. shown on the bottom of the boiler. Fig. -
Page 9: Control Panel
APPLIANCE DESCRIPTION Control panel LCD general features For the boiler technical information refer to the section "TECHNICAL INFORMATION" on page 30. 1.0bar 1.3bar °C °C Thursday 30/11/2023 - 20:30 °C °C Heating in progress Fig. 1.3 10 Programming key 11 Programming key Fig. - Page 10 APPLIANCE DESCRIPTION FUNCTION Zone identification icon. 13 + Delta T M-R > 40K. Zone identification icon with request in progress. Pump fault or primary 14 + temperature above OFF mode. 105°C. Temperature gradi- Stand-by mode. 14 + ent circulation failure (>2K/s).
- Page 11 APPLIANCE DESCRIPTION FUNCTION FUNCTION Fault of cumulative gas Boiler in Stand-By, the 1.3bar valve timeout without symbol shown in the °C °C flame. °C 44 + figure appears (anti- Heating water low pres- freeze protection ac- sure fault, pressure be- Sunday 26/11/2023 - 14:07 tive).
-
Page 12: Lcd Display Settings
APPLIANCE DESCRIPTION LCD display settings (lan- • Press key 13 (Fig. 1.5) again to highlight guage, time, date, etc.) the value to be changed. • Press key 15 or 16 (Fig. 1.5) to select the • Power the boiler by turning on the two- desired language from those available way switch fitted during installation. - Page 13 APPLIANCE DESCRIPTION • Press key 13 (Fig. 1.5) to access the se- Display lected menu (Fig. 1.11). • Press key 13 (Fig. 1.5) again to highlight Contrast the value to be changed. Display lighting Auto • Press key 10 or 11 (Fig. 1.5) to select the Display current value CH&DHW desired menu (Fig.
-
Page 14: Instructions For Use
Warnings Therefore, when the boiler is not lit or used in cold weather, with consequent risk of Biasi UK Ltd support the Benchmark freezing do not switch off the boiler at the initiative. The Benchmark Checklist is fused spur isolation switch or close the gas located at the back of this manual and inlet cock. -
Page 15: Ignition
INSTRUCTIONS FOR USE Ignition Press any key to activate the display. The heating circuit pressure is shown at the • Check that the valves located in the lower top of the display (Fig. 2.2). part of the boiler are open Fig. 2.3. 1.3bar °C °C... -
Page 16: Adjusting The Temperature Of The C.h
INSTRUCTIONS FOR USE When the boiler is OFF, key 12 (Fig. 2.5) must be held down for at least 4 seconds to reactivate it. 1.0bar To select the various operating modes, sim- ply press key 12 (Fig. 2.5) repeatedly and °C °C select the desired mode (see Fig. -
Page 17: Setting Heating (Zones)
INSTRUCTIONS FOR USE Heating control can be set in three modes: Clock and programmes MANUAL, AUTOMATIC and OFF. Set date and time [...] Where: Aut. daylight saving time MAN = Manual Operation Schedules [...] In this mode heating is enabled manually Program Zone 1 [...] and lasts until the next and/or different set-... - Page 18 INSTRUCTIONS FOR USE Menu Zone 1 Settings Clock and programmes [...] Operating mode Information [...] Set delivery maximum °C Fault history [...] General settings [...] [...] DHW settings [...] Zones Fig. 2.12 Fig. 2.15 • Press key 10 or 11 (Fig. 2.11) to select the •...
-
Page 19: Setting Daily Programming
INSTRUCTIONS FOR USE Zones Zone 2 Adjustment Zone 1 [...] Set delivery maximum °C Zone 2 [...] Zone 3 [...] Fig. 2.17 Fig. 2.20 • Press key 13 (Fig. 2.11) to access the se- • Press key 13 (Fig. 2.11) to confirm the lected menu (Fig. - Page 20 INSTRUCTIONS FOR USE desired menu (Fig. 2.23). the value (return to previous level). Menu Holiday Program Boiler operation can be suspended for a Clock and programmes [...] certain period of time (1 to 30 days). The Information [...] program starts on the day of programming Fault history [...] and ends at midnight on the last set day.
-
Page 21: Fault And Anomaly Signals
INSTRUCTIONS FOR USE Fault and anomaly signals Frequent safety lockouts should be reported to an authorised The display signals any anomaly by show- service centre. ing a number adjacent to the symbol and the message "Fault in progress" at the bottom of the display (Fig. -
Page 22: 2.10 Reset / User Factory Settings
INSTRUCTIONS FOR USE Menu Clock and programmes [...] Information [...] Fault history [...] General settings [...] [...] DHW settings [...] Zones Fig. 2.35 • Press key 13 (Fig. 2.31) to access the se- lected menu (Fig. 2.36). General settings Language Closed Display [...]... - Page 23 INSTRUCTIONS FOR USE change or key 14 to exit without changing the value (return to previous level). - 23 -...
-
Page 24: Useful Advice
USEFUL ADVICE USEFUL ADVICE 1.3bar Central Heating For your comfort and added system control, °C °C °C you can install a room thermostat but you should not shut off the radiator in that room or have a TRV fitted on the radiator. If a radiator (or a convector) does not heat Sunday 26/11/2023 - 14:07... -
Page 25: External Cleaning
USEFUL ADVICE ried out: • condensing heat exchanger; • burner; 1.0bar • exhaust fume duct and flue; • pressurisation of the expansion tank; °C °C • filling up of the central heating circuit; Thursday 30/11/2023 - 20:30 • bleeding of air from the central heating system;... -
Page 26: Fault History
USEFUL ADVICE display. The boiler is in lockout mode. any air present in the radiators, if necessary. 1.3bar The pressure has gone down It is necessary to top up the appliance with °C water again, so as to raise the pressure to an adequate level as described in the sec- tion "Refilling procedure"... - Page 27 USEFUL ADVICE Fault history Boiler [...] 1.0bar °C °C Thursday 30/11/2023 - 20:30 Fig. 3.11 Fig. 3.8 • Press key 13 (Fig. 3.8) again to highlight the value to be changed (Fig. 3.12). • Press key 13 (Fig. 3.8) to access the main menu (Fig.
-
Page 28: Displaying In Info Mode
USEFUL ADVICE Displaying in INFO mode • Press key 13 (Fig. 3.14) to access the se- lected menu. The INFO mode allows the display of some • Press key 10 or 11 (Fig. 3.14) the scroll information on the boiler functioning status. through the list (Fig. -
Page 29: Remote Anomaly Code
USEFUL ADVICE mal boiler operation, please Menu Item Description contact an Authorized Service Displays the tem- Centre. System delivery perature read by temp. the system delivery The flue probe and safety thermal fuse 24 probe (optional) indicated in Fig. 3.18 are a safety device. Displays system Pump flow rate The flue probe 24 intervenes when the flue... -
Page 30: Technical Information
TECHNICAL INFORMATION TECHNICAL INFORMATION Overview Fig. 4.1 - 30 -... -
Page 31: Main Diagram
TECHNICAL INFORMATION Main diagram Fig. 4.2 25 C.H. temperature return probe NTC 3 Condensate drain pipe 4 C.H. flow valve 26 Condensing heat exchanger 5 Gas inlet valve 27 NTC heating delivery probe - NTC maxi- 6 C.H. pressure relief valve pipe mum temperature 7 Main circuit drain valve 28 Flame-detecting electrode/Ignition elec-... - Page 32 TECHNICAL INFORMATION 31 Pump 32 Gas valve inlet test point 33 Gas valve 34 Gas valve outlet test point 35 Primary circuit pressure transducer 36 Condensate trap 37 Fan 38 Air/gas mixer 39 Burner 40 C.H. expansion tank 41 Flue outlet pipe 42 Air intake pipe 43 Flue exhaust sampling point 44 Air sampling point...
-
Page 33: Hydraulic Specifications
The height difference between the pressure relief valve and the highest point in the sys- Model ANTARES 30S (M300V.30 SR) tem may be 10 m at most. For greater differences, increase the pre- Pressure (bar) 0,70... -
Page 34: Technical Data Antares 30S (M300V.30 Sr)
TECHNICAL INFORMATION Technical data ANTARES 30S (M300V.30 SR) Heat input Gas supply pressures 31,0 mbar Nominal net BTU/h 105776 2000 28,4 Nominal net with 20% H2NG Natural G20 1700 mixture BTU/h 96905 2500 34,4 3700 Nominal gross BTU/h 117412 Propane G31... - Page 35 TECHNICAL INFORMATION Other specifications Flue design Height Boiler type B23P C13 C33 C43 C53 C63 C83 C93 Width Ø Coaxial 60/100 Depth Ø Twin split pipes 80/80 Weight (dry) 36,0 Ø Roof 60/100 Water volume in the boiler (up to 1 l (kg) bar) Ø...
- Page 36 TECHNICAL INFORMATION Model(s): ANTARES 30S M300V.30 SR Condensing boiler: Low-temperature boiler (**): B1 boiler: Cogeneration space heater: If yes, equipped with a supplementary heater: Combination heater: Item Symbol Value Unit Item Symbol Value Unit Seasonal space heating Rated heat output η...
-
Page 37: General Requirements
GENERAL REQUIREMENTS GENERAL REQUIREMENTS Related documents The installation of this appliance must be in accordance with the relevant requirements of the current Gas Safe (Installation & Use) Regulations, the Local Building Regulations, the current I.E.E. Wiring Regulations, the Regulations and by-laws of the local water un- Benchmark places responsibilities on both dertaking, and in Scotland, in accordance with manufacturers and installers. -
Page 38: Flue System
GENERAL REQUIREMENTS guidance on this aspect. A compartment used to enclose the appliance must be designed specifically for this purpose. This appliance is not suitable for external installation. Flue system The provision for satisfactory flue termination must be made as described in BS 5440 part 1. For Ireland (IE), refer to I.S.813.2002. -
Page 39: Gas Supply
GENERAL REQUIREMENTS Minimum dimensions Symbol Location position (mm) Directly below an opening, air brick, opening window, etc. Above an opening, air brick, opening window, etc. Horizontally to an opening, air brick, opening window, etc. Below temperature-sensitive building components, e.g. D ** plastic gutter soil pipes or drain pipes E ** Below eaves... -
Page 40: Air Supply
GENERAL REQUIREMENTS Air supply If a part of the drainpipe runs externally this part should be kept as short as possible and The room in which the boiler is installed does protected to reduce the risk of freezing. not require a purpose provided air vent. Connection of condensate drainage pipe to internal soil and vent stack. -
Page 41: Water Circulation (C.h.)
GENERAL REQUIREMENTS Water circulation (C.H.) • A WRAS approved dry trap such as the Te- sla DTUN 1522 is utilised. Detailed recommendations are given in BS • That the condensate is connected down- 6798, BSEN 12828: 2003, BSEN 12831: 2003 stream of the trap as shown in the drawing &... -
Page 42: Water Treatment
GENERAL REQUIREMENTS facilitate complete filling of the system. with either plastic or copper pipes, it is impor- tant the system is fully flushed, on completion, Expansion vessel to ensure flux residues, swarf, oils and other The appliance has an integral sealed expan- installation debris is removed. -
Page 43: Installation
INSTALLATION INSTALLATION The safety relief valve and the condensate drain must be connected to a suitable drain, Warnings or discharged in a safe manner. The use of gas appliances is The electrical wiring must conform with cur- subject to statutory control; it is essential to observe the current rent Regulations, in particular: regulations and laws in force... -
Page 44: Installing The Bracket
We recommend the use of a suitable Build- cert approved universal inhibitor to protect the C.H. system from corrosion. Biasi UK strongly recommend that matched - 44 -... -
Page 45: Overall Dimensions
INSTALLATION Overall dimensions Joints The boiler respects the following dimen- The boiler uses the following fittings: sions: Pipe sizes Functions (o.d) Ø80 Ø80 Gas, C.H. return, C.H. flow Ø 22 mm Pressure relief valve Ø 15 mm Ø100 Ø 20 mm Condensate drain (rubber) sizes in mm o.d. -
Page 46: Fitting The Flue System
INSTALLATION Choice of flue The flue exhaust/air intake can be installed in the mode: The terminal must be higher than the boiler. The following kits to be connected to the boiler are available: Wall flue exhaust kit (Fig. 6.6 A) This kit allows the flues to be exhausted in Fig. - Page 47 INSTALLATION Coaxial pipe Ø 60/100 with 90° bend (B) For the bend of 45° loss 0.9 m Nominal length 1.55 m For the bend of 90° loss 1.65 m Minimum length 0.5 m Type C Maximum length 10 m 90° Additional bends at 45°...
- Page 48 INSTALLATION pipes by: Pluming kit B (Fig. 6.11) (Fig. 6.12) Push on type Ø 60 mm vertical plume man- For the bend of 45° loss 0.5 m agement kit For the bend of 90° loss This kit allows the products of combustion to be discharged at a different location, when Pluming kit A (Fig.
-
Page 49: Electric Connection
INSTALLATION ”a” vertical length (m) Allowed values ”b” horizontal length (m) Fig. 6.12 A Plume deflector is available to assist in overcoming boundary nuisance issues. Fig. 6.15 • Unscrew the screw "O" (Fig. 6.16). Fig. 6.13 Electric connection • Unscrew screws "M" and remove the front panel "N"... -
Page 50: Electric Power Supply
INSTALLATION terminal block, remote and external sen- sor (Fig. 6.17). Electric power supply Fig. 6.18 The earth cable must be the Fig. 6.17 longest of the electric power supply cables. Electric power supply connection • Connect the electric power supply ca- The appliance's electric power supply cable ble coming from the fused spur isolation or wire must have a section no less than... -
Page 51: Connecting The Room Thermostat Or Zone Valves
INSTALLATION 6.10 Connecting the room thermo- Connecting the zone valves controlled stat or zone valves by the ambient thermostat Use the clamps indicated in Fig. 6.18 to Ambient connect the ambient thermostat. Thermostat Remove the electric jumper present be- tween “1 and 2” when connecting any type of ambient thermostat. -
Page 52: Electric Connection Between The Boiler And The External Probe
INSTALLATION 6.13 Remote electric connection eaves and at least 2 m above ground. (optional) Use the clamps indicated in Fig. 6.22 to 6.12 Electric connection between connect the remote. the boiler and the external probe To connect the remote control to the boiler, To connect the external probe to the boiler refer also to the REMOTE CONTROL book- use electric cables with a section no less... - Page 53 INSTALLATION Hydraulic system examples Top zone + low temperature zone. External probe Low temperature Hight temperature Fig. 6.23 Top zone + 2 low temperature zones. External probe temperature 1 Hight temperature 2 temperature Fig. 6.24 - 53 -...
-
Page 54: Commissioning
COMMISSIONING COMMISSIONING Warnings The commissioning of this boiler and sys- tem must only be undertaken by a Gas Safe Registered Engineer in accordance with the requirements of the Gas Safe In- stallation and Use Regulations and be ap- proved by Gas Safe. Ensure that the Benchmark Checklist is satisfactorily completed during the com- missioning process. - Page 55 COMMISSIONING • Gradually open stopcock at the filling point • Electrically power the boiler by activat- connection to the C.H. system until water is ing the installed bipolar switch. The LCD heard to flow; do not open fully. display shows the symbol (boiler in •...
- Page 56 COMMISSIONING • Check the correct operation of the boiler. Assistance • Check the gas pressures and flow rates as shown in section "GAS CONVERSION" Boiler [...] on page 72 of this booklet. [...] • Check that the condensate produced during Heating [...] functioning fills the syphon and is regularly...
-
Page 57: Condensate Pipe And Traps
COMMISSIONING VALUE DESCRIPTION Function disabled (default). Forced once only on switching Once on the appliance. Forced each time the appli- ance is switched on. Fig. 7.11 Fig. 7.12 • Press key 13 (Fig. 7.4) to confirm the An alternative, to the removal of the flue el- change or key 14 to exit without changing bow, pour the water through the flue sampling the value (return to previous level). -
Page 58: Lighting The Boiler
Sunday 26/11/2023 - 14:07 CO/CO (The limits for the boiler is given in section "Technical data ANTARES 30S Fig. 7.16 (M300V.30 SR)" on pag. 34: CO con- tents / other flue gas figures) and complete •... -
Page 59: Check The Gas Pressures And Flow Rates
COMMISSIONING utes) the boiler does not function and a code adjacent to the symbol and the mes- sage "Fault in progress" at the bottom of the 1.0bar display(Fig. 7.19). Key 12 (Fig. 7.17) flashes to signal the appliance is in lockout. °C °C 1.3bar... -
Page 60: Checking The Ignition Device
78 of this manual. Reference figures are given in section "Tech- With the burner on high flame close the gas nical data ANTARES 30S (M300V.30 SR)" on cock. pag. 34 (Flue gas figures). After four ignition attempts (about four min-... -
Page 61: Advanced Commissioning
ADVANCED COMMISSIONING ADVANCED COMMISSIONING Menu Accessing the "Service" Clock and programmes [...] menu (Installer) Information [...] Access restricted to authorised Fault history [...] and appropriately trained tech- General settings [...] nicians. [...] DHW settings [...] Zones To access the "Service" menu, restricted to authorised and appropriately trained techni- Fig. -
Page 62: Selecting The Type Of External Sensor
ADVANCED COMMISSIONING Access level Access type Service 1.0bar °C °C Thursday 30/11/2023 - 20:30 Fig. 8.6 Fig. 8.7 • Press key 13 (Fig. 8.1) again to confirm access to the "Service" level or key 14 to • Press key 13 (Fig. 8.7) to go to the main exit (return to previous level). -
Page 63: Enabling Operation With The External Sensor And Setting The K Coefficient Of The External Temperature Probe
ADVANCED COMMISSIONING Enabling operation with the Assistance external sensor and setting the K coefficient of the exter- Boiler [...] nal temperature probe [...] The K coefficient is a parameter that in- Heating [...] creases or decreases the boiler delivery Inputs [...] temperature as the outdoor temperature Special functions... - Page 64 ADVANCED COMMISSIONING Zones Zone 1 [...] 1.0bar Zone 2 [...] °C °C Zone 3 [...] Thursday 30/11/2023 - 20:30 Fig. 8.17 Fig. 8.14 • Press key 10 or 11 (Fig. 8.14) to select the desired menu from those available (Fig. •...
-
Page 65: Selecting Minimum/Maximum Heating Temperature
ADVANCED COMMISSIONING Zone 1 Adjustment Modul. with ext. sensor 1.0bar Offset climatic curve °C °C °C Reduced Max. external temp. °C Thursday 30/11/2023 - 20:30 Min. external temp. °C Set delivery maximum °C Fig. 8.20 Fig. 8.22 • Use key 15 or 16 to modify the value of the selected parameter, referring to the •... -
Page 66: Setting Pump Post-Circulation
ADVANCED COMMISSIONING Setting pump post-circulation Assistance The pump, in heating mode, is set for a post-circulation of about one minute at the Boiler [...] end of each heat request. [...] This time can be changed from a minimum Heating [...] of 10 seconds to a maximum of 20 minutes Inputs [...]... -
Page 67: Selecting The Reignition Frequency
ADVANCED COMMISSIONING Menu Timers Information [...] Heating anti-cycling Fault history [...] Heating post-circulation General settings Heating ramp [...] DHW settings [...] Zones [...] [...] Assistance Fig. 8.30 Fig. 8.33 • Press key 13 (Fig. 8.28) to access the se- • Use key 15 or 16 to modify the value of lected menu (Fig. -
Page 68: Reset / "Service" Factory Settings (Installer)
ADVANCED COMMISSIONING • Press key 13 (Fig. 8.34) to go to the main Boiler menu (Fig. 8.35). External relays [...] Menu Flue system [...] Clock and programmes [...] Timers [...] Information [...] Anti-freeze function [...] Fault history [...] Pump [...] General settings [...] [...]... - Page 69 ADVANCED COMMISSIONING Assistance Boiler [...] 1.0bar [...] °C °C Heating [...] Inputs [...] Thursday 30/11/2023 - 20:30 Special functions [...] [...] Maintenance Fig. 8.43 Fig. 8.40 • Press key 10 or 11 (Fig. 8.40) to select the desired menu (Fig. 8.44). •...
-
Page 70: Boiler Adjustment Record
ADVANCED COMMISSIONING Only confirm the "Request for Menu confirmation" if you are sure you want to restore all user pa- Clock and programmes [...] rameters to factory settings! Information [...] Fault history [...] Request for confirmation General settings [...] [...] DHW settings [...] Zones... - Page 71 ADVANCED COMMISSIONING PARAMETER MENU ITEM MODEL VALUE Menu > General settings > Language Menu > Assistance > Boiler > Combustion > ANTARES 30S Model (M300V.30 SR) NG (CH4) Menu > Assistance > Boiler > Combustion > Gas type LG (G31) Menu >...
-
Page 72: Gas Conversion
GAS CONVERSION GAS CONVERSION Menu Warnings Clock and programmes [...] The commissioning of this boiler and Information [...] system must only be undertaken by a Fault history [...] Gas Safe Registered Engineer, quali- General settings [...] fied to work on Liquefied Petroleum Gas [...] DHW settings (LPG) in accordance with the require-... - Page 73 GAS CONVERSION "Warning if during any PCB re Boiler programming disengage the power supply to the boiler Hydraulic Mixed you may corrupt the software Set primary pres. min 1.0bar setup, ensure you wait at least Noise reduction 10 seconds after any re pro- Combustion [...] gramming before any power iso-...
-
Page 74: Maintenance
MAINTENANCE MAINTENANCE 10.1 Warnings 1.0bar The procedures detailed in this chapter must be carried out only by a Gas Safe °C °C Registered Engineer. Thus you are ad- Thursday 30/11/2023 - 20:30 vised to contact an Authorised Service Agent. For Ireland (IE), the servicing work must be carried out by a competent RGII reg- istered Person. -
Page 75: Dismantling The External Panels
MAINTENANCE front panel "D" by pulling it towards you Assistance and then pushing it upwards in order to free it from the upper seats (Fig. 10.7 and Boiler [...] Fig. 10.8). [...] Heating [...] Side panels Inputs [...] Loosen the screws "B", "C", "G" and "H" in Special functions [...] Fig. -
Page 76: Reassembly The External Panels
MAINTENANCE Control panel Remove screws "I" and turn the control panel "J", as shown in figure Fig. 10.9, for optimal access to the internal components of the boiler. Close position Fig. 10.10 • Loosen the central heating drain cock 7 indicated in Fig. -
Page 77: Cleaning The Condensing Primary Exchanger And The Burner
MAINTENANCE • Remove the front panel and lower the controls panel (see "Dismantling the ex- ternal panels" on page 75). • Disconnect the wiring of the ignition and detection electrodes. • Unscrew the connector "K" and remove the pipe "L". •... -
Page 78: Check The Pressure Of The Heating Expansion
MAINTENANCE Electrodes disclaimer. More specific maintenance will be valuated Note to service engineers: It is and carried out by a competent Gas Safe required that the burner seal, Registered Engineer. lip seal and mixing chamber seal along with the flame de- Attention, to reassemble repeat tection electrode are inspected the operations carried out in re-... -
Page 79: Checking The Condensate Drain Pipe
80). • Check the combustion of the boiler using the outlets located on the flue tubes (Fig. 10.16) and compare the data measured with that following. Model ANTARES 30S - M300V.30 SR Nominal heat input 31,0 (A) (E) Nominal efficiency... -
Page 80: 10.13 Water Inhibitor Concentration
MAINTENANCE 10.13 Water inhibitor concentration • Press key 10 or 11 (Fig. 10.19) to select Where chemical products are used the level the desired menu (Fig. 10.21). of water treatment should be checked on an annual basis and re treated after full or par- Menu tial drain down. - Page 81 MAINTENANCE light the value to be changed. To exit the parameters menu: • wait 15 minutes without pressing any key; Chimney sweep function • switch off the electric power supply; • set "Chimney sweep fun.active" = 0 (Fig. Chimney sweep fun.active 10.24) (return to previous level).
-
Page 82: Benchmark Commissioning
Benchmark Commissioning & Warranty Validation Service Record It is a requirement that the boiler is installed and commissioned to the manufacturers’ instructions and the data fields on the commissioning checklist completed in full. To instigate the boiler warranty the boiler needs to be registered with the manufacturer within one month of the installation. -
Page 83: Gas Boiler System Commissioning Checklist & Warranty Validation Record
GAS BOILER SYSTEM COMMISSIONING CHECKLIST & WARRANTY VALIDATION RECORD Address: Boiler make and model: Boiler serial number: Commissioned by (PRINT NAME): Gas Safe registration number: Company name: Telephone number: Company email: Company address: Commissioning date: Heating and hot water system complies with the appropriate Building Regulations? Optional: Building Regulations Notification Number (if applicable): Time, temperature control and boiler interlock provided for central heating and hot water Boiler Plus requirements (tick the appropriate box(s)) -
Page 84: Service & Interim Boiler Work Record
SERVICE & INTERIM BOILER WORK RECORD It is recommended that your boiler and heating system are regularly serviced and maintained, in line with manufacturers’ instructions, and that the appropriate service / interim work record is completed. Service provider When completing a service record (as below), please ensure you have carried out the service as described in the manufacturers’ instructions. Always use the manufacturers’... - Page 85 SERVICE & INTERIM BOILER WORK RECORD It is recommended that your boiler and heating system are regularly serviced and maintained, in line with manufacturers’ instructions, and that the appropriate service / interim work record is completed. Service provider When completing a service record (as below), please ensure you have carried out the service as described in the manufacturers’ instructions. Always use the manufacturers specified spare parts.
- Page 86 NOTES - 86 -...
- Page 88 *1796239490* 17962.3949.0 4124 88A5 Biasi UK Ltd Commercial Road Leamore Enterprise Park WALSALL WS2 7NQ Sales Tel. 01922 714600 Tech. Service Tel. 01922 714636 www.biasi.co.uk...
