Page 1: Installation Instructions
Wall hung, fanflue, roomsealed, high efficiency gas boiler User manual and Installation instructions Advance Plus Models G.C. Appl. No. Advance Plus 25C 47-583-29 Advance Plus 30C 47-583-30 Advance Plus 35C 47-583-31... - Page 2 This allows a gain of useful heat that otherwise would be lost. Biasi UK Ltd is a licensed member of the Benchmark Scheme which aims to improve the standards of installation and commissioning of domestic heating and hot water systems in the UK and to encourage regular servicing to optimise safety, efficiency and performance.
-
Page 3: Using The Boiler
Remember that... The manual must be read thoroughly, so that you will be able to use the boiler in a safe and sensible way; must be carefully kept. It may be necessary for reference in the future. The lighting up must be carried out by competent and responsible engineer. The manufacturer •... - Page 4 On completion of the work, have a professionally qualified person check their efficiency. Repairs (under guarantee) must be carried out only by a Biasi an approved engineer, us- ing genuine spare parts. Thus do no more than switching off the boiler yourself (see the instructions).
-
Page 5: Installing The Boiler
Combustion chamber panels Material: mineral fibres Known hazards - Some people can suffer reddening and itching of the skin. Fibre entry into the eye will cause foreign body irritation, which can cause severe irritation to people wearing contact lenses. Irritation to respiratory tract. Precautions - Dust goggles will protect eyes. - Page 6 If you are in any doubts as to the installation or operation of the boiler please read the instruction manuals thoroughly and then if necessary contact Biasi UK for advice and as- sistance.
-
Page 7: Table Of Contents
7.17 Instructing the user ..... . 67 Technical data Advance Plus 25C ..26 7.18 Adjustment of useful c.h. -
Page 8: Appliance Description
APPLIANCE DESCRIPTION APPLIANCE DESCRIPTION Overview Isolation valves The model and serial number of the boiler are printed on bottom right side. Fig. 1.2 3 Gas supply label Fig. 1.1 4 C.h. flow valve 1 Controls panel 5 D.h.w. outlet valve 2 House for possible time switch (c.h. -
Page 9: Controls Panel
APPLIANCE DESCRIPTION Controls panel °C RESET Fig. 1.4 The symbol indicates that the boiler can be directly reactivat- ed by the user, by pressing the Fig. 1.3 reset button The symbol indicates that the 12 D.h.w. temperature increase key fault requires intervention on 13 D.h.w. - Page 10 APPLIANCE DESCRIPTION FUNCTION FUNCTION Boiler in winter mode Faulty external temp. Er 08 (c.h.+ d.h.w.) probe NTC The primary circuit tem- Faulty flue temp. probe Er 09 perature is displayed. Boiler on demand for Flue probe intervention Er 10 d.h.w. power. lockout The d.h.w.
- Page 11 APPLIANCE DESCRIPTION FUNCTION FUNCTION Boiler chimney sweep in function. Boiler anti-freeze The activation of the phase (bP flashing + chimney sweep occurs temperature flashing) configuring the "param- eter P09=01" and is visualized: LP = minimum dhw hP = minimum heating Boiler in antifrost phase cP = maximum heating (AF flashing + temper-...
-
Page 12: Instructions For Use
Installer for this purpose. Warnings Biasi UK Ltd support the Benchmark initi- If you are in any doubt regarding this pro- cedure you are advised to contact your ative. The Benchmark Checklist is located at the back of this manual and should be Installer or an Approved Engineer. -
Page 13: Ignition
INSTRUCTIONS FOR USE Fig. 2.2 Open If you experience any difficulty with the position operation of the boiler, switch off the boil- er immediately at the fused spur isolation Fig. 2.3 switch and contact your Installer or an ap- proved Service Engineer. •... -
Page 14: Circuit Temperature
INSTRUCTIONS FOR USE °C Fig. 2.8 C.h. circuit temperature The output temperature of c.h. water can be adjusted by acting on keys 15 (reduce) and 16 (increase) (Fig. 2.7) from a minimum of about 25°C to a maximum of about 85°C. Fig. - Page 15 INSTRUCTIONS FOR USE The control of the set temperature reached can be seen on the LCD display by means of the missing symbol Power request in c.h. power. When the boiler has a power request in the c.h. mode, the symbol is displayed on the display followed by an increase of the c.h.
-
Page 16: Temperature
INSTRUCTIONS FOR USE es or when the function status is set to "oF". tures will be appreciated. Hold down keys 15 and 16 (Fig. 2.14). If water hardness is particularly high, we rec- ommend that the boiler be adjusted to a tem- perature less than 50°C. -
Page 17: Extinguishing
INSTRUCTIONS FOR USE NOTE: Should the power to the boiler fail, wait at least one minute before reactivating the function upon reactivation. To disable the 3 star preheating function Fig. 2.19 press keys 12 and 13 together (Fig. 2.18) un- til the letters "cF"... -
Page 18: Useful Advice
USEFUL ADVICE USEFUL ADVICE Central Heating For reasonably economical service install a room thermostat. Never shut off the radia- Fig. 3.2 tor in the area where the room thermostat is installed. Therefore, when the boiler is not lit and If a radiator (or a convector) does not heat used in cold weather, with consequent risk up, check that no air is present in it and that of freezing do not switch off the boiler at the... -
Page 19: External Cleaning
USEFUL ADVICE ried out: • domestic hot water heat exchanger; • condensing heat exchanger; • burner; • exhaust fume duct and flue; RESET • pressurisation of the expansion tank; • filling up of the central heating circuit; • bleeding of air from the central heating system;... - Page 20 USEFUL ADVICE Noise due to air bubbles are heard dur- ing operation You should check that the pressure on the pressure gauge is not below the correct set- ting. If required, top up the system correctly, as described in the section "Refilling proce- dure"...
-
Page 21: Displaying In Info Mode
USEFUL ADVICE Water should occasionally leak from the boiler Shut off the valves positioned under the boiler to page 17 and call an Authorised Service Centre Engineer. In this case or in case of prob- lems other than those men- tioned here, switch off the boil- er, as described in section Fig. -
Page 22: Flue Probe
USEFUL ADVICE Flue probe intervention lock- Flame detection error No circulation, of faulty pump or intervention primary tem- perature limit. Flue probe The flue probe 19 and safety thermal fuse 20 indicated in Fig. 3.8 are a safety device. The flue probe 19 intervenes when the flue temperature exceeds 110°C placing the boiler in safety block switching it off. -
Page 23: Technical Information
TECHNICAL INFORMATION TECHNICAL INFORMATION Overview Fig. 4.1 - 23 -... -
Page 24: Main Diagram
TECHNICAL INFORMATION Main diagram Fig. 4.2 4 C.h. flow valve 18 Condensing heat exchanger air purger 5 D.h.w. outlet valve valve 6 Gas inlet valve 19 Flue temperature probe NTC 7 D.c.w. inlet valve 20 Safety thermal fuse 21 C.h. temperature probe NTC 8 C.h. - Page 25 TECHNICAL INFORMATION 24 Flame-detecting electrode 25 Air manifold 26 C.h. pressure relief valve 27 Automatic air purger valve 28 Pump 29 Pump vent plug 30 Gas valve 31 Gas valve inlet test point 32 D.h.w. temperature probe NTC 33 Control box containing: External temperature probe terminal block, remote terminal block, d.h.w tank terminal block, power supply terminal...
-
Page 26: Technical Data Advance Plus 25C
TECHNICAL INFORMATION Technical data Advance Plus 25C Heat input Central heating 20,0 Min/Max flow temperature settings* °C 25 - 85 Nominal net central heating BTU/h 68243 Maximum pressure 25,0 Nominal net domestic hot water BTU/h 85304 Minimum pressure 22,2 Nominal gross... - Page 27 TECHNICAL INFORMATION Gas supply pressures Electrical data Voltage mbar Frequency 2000 Power consumption Natural G20 1700 Protection degree IPX5D 2500 3000 External fuse rating Propane G31 2000 N° 2 - 2 Internal fuse rating 3500 Flue design Gas rate maximum - central heating Boiler type Natural G20 2,15...
- Page 28 TECHNICAL INFORMATION contents - central heating Nominal heat input 20,0 (A) (E) content with gas G20 (range 9,2 - 9,8 min - max) content with gas G31 (range 9,9 - min - max) 10,8 Minimum heat input (A) (E) content with gas G20 (range 8,7 - 9,3 min - max) content with gas G31 (range...
-
Page 29: Technical Data Advance Plus 30C
TECHNICAL INFORMATION Technical data Advance Plus 30C Heat input Central heating 25,0 Min/Max flow temperature settings* °C 25 - 85 Nominal net central heating BTU/h 85304 Maximum pressure 30,0 Nominal net domestic hot water BTU/h 102364 Minimum pressure 27,8 Nominal gross central heating BTU/h 94687 27,0... - Page 30 TECHNICAL INFORMATION Gas supply pressures Electrical data Voltage mbar Frequency 2000 Power consumption Natural G20 1700 2500 Protection degree IPX5D 3000 External fuse rating Propane G31 2000 N° 2 - 2 Internal fuse rating 3500 Flue design Gas rate maximum - central heating Boiler type Natural G20 2,65...
- Page 31 TECHNICAL INFORMATION contents - central heating Nominal heat input 25,0 (A) (E) content with gas G20 (range 9,2 - 9,8 min - max) content with gas G31 (range 9,9 - min - max) 10,8 Minimum heat input (A) (E) content with gas G20 (range 8,7 - 9,3 min - max) content with gas G31 (range...
-
Page 32: Technical Data Advance Plus 35C
TECHNICAL INFORMATION Technical data Advance Plus 35C Heat input Central heating 30,0 Min/Max flow temperature settings* °C 25 - 85 Nominal net central heating BTU/h 102364 Maximum pressure 34,0 Nominal net domestic hot water BTU/h 116013 Minimum pressure 33,3 Nominal gross central heating BTU/h 113624 27,0... - Page 33 TECHNICAL INFORMATION Electrical data Gas supply pressures Voltage mbar Frequency 2000 Power consumption Natural G20 1700 Protection degree IPX5D 2500 External fuse rating 3000 N° 2 - 2 Propane G31 2000 Internal fuse rating 3500 Flue design Gas rate maximum - central heating Boiler type Natural G20 3,17...
- Page 34 TECHNICAL INFORMATION contents - central heating Nominal heat input 30,0 (A) (E) content with gas G20 (range 9,2 - 9,8 min - max) content with gas G31 (range 9,9 - min - max) 10,8 Minimum heat input (A) (E) content with gas G20 (range 8,7 - 9,3 min - max) content with gas G31 (range...
-
Page 35: Hydraulic Specifications
The by-pass is calibrated to a differential Model Advance Plus 25C pressure of about 0.3-0.4 bar. Pression (bar) 0,50 0,45 Expansion vessel... -
Page 36: General Requirements
GENERAL REQUIREMENTS GENERAL REQUIREMENTS indicate compliance to I.S.813.2002. This appliance must be installed by a competent person in accordance with the Gas Safe (installation & Use) Regula- tions. Benchmark places responsibilities on both Related documents manufacturers and installers. The purpose is to ensure that customers are provided The installation of this appliance must be in with the correct equipment for their needs,... -
Page 37: Flue System
GENERAL REQUIREMENTS lations. Where possible, terminal position which could cause a nuisance should be avoided. Where a room-sealed appliance is in- The minimum acceptable spacing from stalled in a room containing a bath or the terminal to obstructions and ventilation shower, any electrical switch or appli- openings are specified in Fig. -
Page 38: Gas Supply
GENERAL REQUIREMENTS O Above the roof pitch with roof Air supply slope less than or equal to 30° The room in which the boiler is installed does O Above the roof pitch with roof not require a purpose provided air vent. slope more than 30°... -
Page 39: Water Circulation (C.h.)
GENERAL REQUIREMENTS boiler; E Sink • the number of bends and joints should be F Open end of condensate drainage pipe kept at minimum; direct into gully below grating but above • the drain pipe should be adequately fixed water level to prevent pipe sagging. -
Page 40: Domestic Water
GENERAL REQUIREMENTS heat exchanger. valve be fitted to the incoming mains wa- If you are installing a system that includes ter supply and a mini expansion vessel in- thermostatic radiator valves (TRV) and/or stalled on the domestic circuit. These devices will protect the boiler and the small bore (8-10 mm) it may be necessary to fit an external by-pass to facilitate correct domestic system from damage due to ex-... -
Page 41: Water Treatment
GENERAL REQUIREMENTS 5.10 Water treatment permits a complete switching off in the con- C.h. circuit ditions of the overvoltage category III. Alter- Where a new boiler is fitted to a new system natively it can be used a 3A fused three pin plug and unswitched shuttered socket outlet with either plastic or copper pipes, it is im- portant the system is fully flushed, on com-... -
Page 42: Installation
INSTALLATION INSTALLATION The electrical wiring must conform with cur- rent Regulations, in particular: Warnings • the boiler must be earthed using the cor- The use of gas appliances is rect bonding clamp. subject to statutory control; it is • a fused spur isolation switch, must be in- essential to observe the current stalled near to the boiler that allows com- regulations and laws in force... -
Page 43: Installing The Bracket
INSTALLATION cleans out the system, but also has an anti- corrosive effect by promoting formation of a protective skin on metal surfaces and neu- tralising gases present in the water. We recommend the use of a suitable uni- versal inhibitory to protect the c.h. system from corrosion. -
Page 44: Overall Dimensions
INSTALLATION Overall dimensions Joints The boiler respects the following dimen- The boiler uses the following fittings: sions: Pipe sizes Functions (o.d) Ø80 Ø80 Ø80 Gas, c.h. return, c.h. flow ø 22 D.c.w. inlet ø 15 Ø100 D.h.w. outlet ø 15 Pressure relief valve ø... -
Page 45: Fitting The Flue System
INSTALLATION • Fit the filling loop "S" to the pipes d.c.w. inlet "T" and c.h. return "U". See also sec- tion "Water circulation (c.h.)" pag. 39 in this manual. Fitting the flue system For a correct installation of the flue pipe, re- fer to the sheet provided together with the pre-selected kit. -
Page 46: Choice Of Flu
INSTALLATION CORRECT system for installing INCORRECT system for installing Fig. 6.6 Fig. 6.7 A = air intake A = air intake S = flue exhaust S = flue exhaust Choice of flu The flue exhaust/air intake can be installing in the mode: Refer to the sheet provided with the pre- selected kit, in separate packaging. - Page 47 INSTALLATION ready angled. These bends when used with the pipe re- The following kits to be connected to the duce the maximum length of the flue pipe boiler are available: For the bend of 45° loss 0,5 m Wall flue exhaust kit (Fig. 6.8 A) For the bend of 90°...
- Page 48 INSTALLATION Type C For the bend of 45° loss 0,9 m For the bend of 90° loss 1,65 m 90° Type C 90° 45° 45° Ø 125 Fig. 6.10 Fig. 6.11 TYPE Extensions are available for reaching the If using pipes and terminals by other manu- maximum height.
-
Page 49: Electric Connection
INSTALLATION 90° =--- 0,85 m ø 60 mm 45° =--- 0,65 m 90° =--- 1 m ø 60/100 mm 45° =--- 0,5 m Fig. 6.12 In the last section, the fumes are expelled through a vertical section. Extensions and elbows can be added to ex- tend the kit’s length. - Page 50 INSTALLATION Remote External Probe Electric power supply Fig. 6.14 Electric power supply connection Ambient • Connect the electric power supply ca- thermostat ble coming from the fused spur isolation switch to the power supply terminal block of the boiler Fig. 6.15 keeping the same Fig.
-
Page 51: Connecting The Room Thermostat Or Zone Valves
INSTALLATION Allow the cables to exit the boiler by using the relevant cable clamps Y (Fig. 6.17). Potential clean contacts of the Ambient Thermostat Fig. 6.18 Room thermostat (230V rating) Fig. 6.17 6.10 Connecting the room thermo- stat or zone valves Use the clamps indicated in Fig. -
Page 52: External Frost Protection
INSTALLATION 6.11 External frost protection II ( ) or must be correctly connected to earth. • Connect the frost thermostat between ter- minals 1 and 2 as shown in Fig. 6.22 or Connecting the zone valves controlled Fig. 6.23. by the ambient thermostat Do not connect live wires to terminals to which the frost thermostat must be con- Ambient... -
Page 53: Installation Of The External Temperature Probe
INSTALLATION 6.12 Installation of the external temperature probe (optional) The external probe must be installed on the external wall of the building avoiding: • Direct radiation of solar rays. Remote • Humid walls or walls subject to the forma- tion of mildew. •... -
Page 54: Example Of Hydraulic Plants With Hydraulic
INSTALLATION The route of the remote control cable must Hydraulic plant examples follow the route indicated in Fig. 6.16. Allow the cables to exit the boiler by using Top zone + low temperature zone. the relevant cable clamps Y (Fig. 6.17). External probe 6.15 Example of hydraulic plants with hydraulic separator... -
Page 55: Commissioning
COMMISSIONING COMMISSIONING the appliance for leaks. Warnings The commissioning of this boiler and system must only be undertaken by a Gas Safety registered engineer in ac- cordance with the requirements of the Gas Safe Installation and Use Regula- tions and be approved by Gas Safe. Ensure that the Benchmark Checklist is satisfactorily completed during the com- missioning process. - Page 56 COMMISSIONING the pump shaft by turning in the direction indicated by the arrow on the information plate. • Replace the pump plug. • Continue filling the system. The actual reading should ideally be 1,3 bar and not less than 0,3 bar. •...
-
Page 57: Condensate Pipe And Traps
An alternative, to the removal of the flue el- supply pressure table in the "Technical bow, pour the water through the flue sam- Data" section (pag. 26 Advance Plus 25C, pling point (Fig. 7.5). pag. 29 Advance Plus 30C and pag. 32 Advance Plus 35C). -
Page 58: Lighting The Boiler
CO/CO (The limits for the boiler is given in "Technical Data" section pag. 26 Advance Plus 25C, pag. 29 Advance Plus 30C and pag. 32 Advance Plus 35C: contents / other flue gas figures) and complete the Certificate of Exemp- tion section of the Benchmark. - Page 59 COMMISSIONING °C Fig. 7.9 RESET • Open the gas cock • Make sure that the ambient thermostat is in the “heat request” position”. • Check the correct functioning of the boiler RESET both in domestic hot water mode and in heating mode.
-
Page 60: Enabling Functioning Of The External Temperature Probe By The Remote Control
COMMISSIONING 7.10 Enabling functioning of the external temperature probe by the remote control Functioning with the external probe in the boiler must be enabled if the remote control (optional) is used. Act on the programming of the REMOTE control to enable its functioning if the re- mote control (optional) is used. - Page 61 COMMISSIONING Sequence for setting the K coefficient C.h. flow temperature °C • Enter in "programming mode" by pressing K=4 K=3 K=1,5 keys 14 - 15 - 16 (Fig. 7.17) for 10 seconds at the same time until the letters Pr that al- ternate with code 01 are displayed on the LCD display, indicating that "parameter 01", has been activated (Fig.
- Page 62 COMMISSIONING At this point the plant flow temperature will follow the trend in relation to the K coeffi- cient set. However, if the ambient temperature is not comfortable, the flow temperature of the heating plant can be increased or reduced by ±...
-
Page 63: Setting The Pump Post-Circulation
COMMISSIONING at the same time until the letters Pr that al- ternate with code 01 are displayed on the LCD display, indicating that "parameter 01" (Fig. 7.25) has been activated. Fig. 7.22 Press button to display the K REG window (Fig. 7.23). Fig. - Page 64 COMMISSIONING Programming using the REMOTE con- trol • Press button for more than 3 seconds to enter in mode (Fig. 7.28). Fig. 7.26 Fig. 7.28 • Press keys 14 and 16 (Fig. 7.24) at the same time until the value of parameter 11 at the same •...
-
Page 65: Selecting The Reignition Frequency
COMMISSIONING • To modify the programmed SET, act on buttons and wait for the programmed number to flash (Fig. 7.31). Each step increased or decreased corre- sponds to 1 second. Fig. 7.32 Fig. 7.31 • To exit programming, press button . 7.13 Selecting the reignition fre- quency When the boiler functions in normal on/off... - Page 66 COMMISSIONING • Press keys 14 and 16 (Fig. 7.32) at the same time until the value of parameter 10 (30=180 seconds) is displayed on the LCD display (Fig. 7.35). Fig. 7.36 • Press buttons at the same time to enter transparent programming Fig.
-
Page 67: Checking The Ignition Device
COMMISSIONING minutes. Press the reset key on the boiler control Each step increased or decreased corre- panel 14 to reset its functioning. sponds to 2 seconds. 7.15 Checking the flue system • To modify the programmed SET, act on buttons and wait for the The flue system should be visually checked number programmed to flash (Fig. -
Page 68: Adjustment Of Useful C.h. Output
Advance Plus 30C time and temperature controls (if fitted). Explain how to turn off the appliance for both Advance Plus 25C short and long periods and advise on the precautions necessary to prevent damage should the appliance be inoperative when freezing conditions may occur. -
Page 69: Setting Record
• Press keys 14 and 16 (Fig. 7.42) at the same time until the value of parameter 12 PARAMETER DIGIT VALUES (74=Advance Plus 25C or 78=Advance Boiler type (to be Plus 30C or 84=Advance Plus 35C) is dis- updated with the Pr 01 played on the LCD display (Fig. - Page 70 Pr 26 --------------- same time until the value of parameter 01 C.h. minimum set- Pr 27 (35=Advance Plus 25C or 36=Advance point Plus 30C or 37=Advance Plus 35C) is dis- Maintenance inter- Pr 28 played on the LCD display (Fig. 7.49).
- Page 71 COMMISSIONING Fig. 7.49 • Press keys 14 and 15 (Fig. 7.47) at the same time to exit without changing the value (return to the parameters list Fig. 7.48). • Scroll the various parameters using keys 15 or 16 until the letters Pr that alternate with code 02 are displayed on the LCD display, indicating that ”parameter 02”...
-
Page 72: Gas Conversion
Warnings ring to the "Technical Data" section page The commissioning of this boiler and 26 (Advance Plus 25C), page 29 (Ad- system must only be undertaken by a vance Plus 30C) and page 32 (Advance Gas Safety Registered Engineer, quali- Plus 35C). - Page 73 GAS CONVERSION 01" (Fig. 8.4) has been activated. • Press keys 14 and 16 (Fig. 8.3) at the same time until the value of parameter 05 (00=G20) is displayed on the LCD display (Fig. 8.6). Fig. 8.3 Fig. 8.6 • By pressing key 16 three times, it is pos- sible to change the value of parameter 05 from 00=G20 to 05=G31, which is ok for LPG gas.
-
Page 74: Maintenance
MAINTENANCE MAINTENANCE Warnings The procedures detailed in this chapter must be carried out only by a Gas Safe- ty Registered Engineer. Thus you are advised to contact an Authorised Service Agent. For Ireland (IE), the servicing work must be carried out by a competent Person. For efficient and continuous operation of the boiler you are advised to have, at least once a year, maintenance and cleaning done by... -
Page 75: Reassembly The External Panels
MAINTENANCE Fig. 9.3 Reassembly the external panels Side panels Fit the external panels E and G in the re- Fig. 9.4 verse order to that described on section "Dismantling the external panels" to page Emptying the d.h.w. system • Turn off the d.c.w .inlet isolating valve 7 Front panel (Fig. -
Page 76: Emptying The C.h. System
MAINTENANCE • Turn on the hot water taps and any drain cocks. Emptying the c.h. system • Close the c.h. isolating valves (4 and 8 in Fig. 9.5). • Loosen the central heating drain cock 10 indicated in Fig. 9.6. Fig. - Page 77 MAINTENANCE • Unscrew the connector L, remove the fix- ing fork K and remove the pipe J. • Unhook the silencer pipe. • Insert a flat screwdriver in the connector recess M and lever towards the bottom, disconnect the connector at the same time O by pulling towards the front O (Fig.
-
Page 78: Vessel
9.12) and compare the data measured Checking the flue expulsion with that following. pipe Have the integrity of the flue outlet pipe air Model Advance Plus 25C intake pipe, checked periodically, at least Nominal heat input 20,0 (A) (E) once a year. For all the above maintenance... -
Page 79: Checking The Condensate Drain Pipe
MAINTENANCE clogged. Model Advance Plus 30C Unscrew the plug to clean inside the pipe. Nominal heat input 25,0 (A) (E) Nominal efficency 97,4 Combustion efficency 98,2 Air index 1,23 Flue gas CO content 9,2 - 9,8 Flue gas O content Flue gas CO content Flue gas temperature °C... -
Page 80: Water Inhibitor Concentration
MAINTENANCE 9.14 Water inhibitor concentration Where chemical products are used the level of water treatment should be checked on an annual basis and re treated after full or par- tial drain down. A conductivitymeter can be used to check the correct concentration of inhibitor in the heating water. - Page 81 MAINTENANCE ney sweep function” at the minimum pow- alternate with the heating water tempera- er during heating (Fig. 9.20). ture value (e.g.99), the "chimney sweep function" is at maximum output in domes- tic hot water mode (Fig. 9.22). Fig. 9.20 Chimney sweep function at maximum Fig.
-
Page 82: List
Failure to install and commission according to the manufacturer’s instructions and complete this Benchmark Commissioning Checklist will invalidate the warranty. This does not affect the customer’s statutory rights. If yes, and if required by the manufacturer, has a water scale reducer been fitted? Condensing Boilers only The condensate drain has been installed in accordance with the manufacturer’s instructions and/or BS5546/BS6798 If the condensate pipe terminates externally has the pipe diameter been increased and weatherproof insulation fitted? -
Page 83: Service Record
service record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. - Page 84 *1796221990* 17962.2199.0 1512 84A5 Biasi UK Ltd Commercial Road Leamore Enterprise Park WALSALL WS2 7NQ Sales Tel. 01922 714600 Tech. Service Tel. 01922 714636 www.biasi.co.uk...
