Wall hung, fanflue, roomsealed, high efficiency gas boiler
Service manual
RINNOVA ADAPTIVE
Product name
RINNOVA ADAPTIVE 30S
Leave this manual adjacent to the gas meter
Warning:
Service / repairs must be carried out, only by a qualified Gas Safe Registered
Engineer, who will be responsible for the current Regulations for gas
appliances.
Note:
After servicing, complete the relevant Service Interval Record section of the
Benchmark Checklist of the user and installation manual.
Models
M300V.30 SR
G.C. Appl. No.
41-583-39
