Hitachi airHome 400 RAK-DJ07QHAA Installation Manual

INSTALLATION
●
Flare nut must use a torque wrench without fail. Tighten with the specifi ed tightening torque. If the fl are
nut is tightened too much, after a long period of time, the fl are nut breaks, Gas leakage, stagnation,
MANUAL
touching fi re, rarely cause ignition.
●
Sharp bending of the pipe use the polyethylene rod, bend not crushed the pipe. Gas leakage from the
crushed part, stagnation, touching fi re, rarely cause ignition.
●
Please request your sales agent or qualifi ed technician to install your unit. Water leakage, short circuit
or fi re may occur if you do the installation work yourself.
●
Please observe the instructions stated in the installation manual during the process of installation. Improper
Home installation may cause water leakage, electric shock and fi re.
●
Make sure that the units are mounted at locations which are able to provide full support to the weight
of the units. If not, the units may collapse and impose danger.
●
Observe the rules and regulations of the electrical installation and the methods described in the installation
manual when dealing with the electrical work. Use cables which are offi cially approved in your country.
Be sure to use the specifi ed circuit. A short circuit and fi re may occur due to the use of low quality wire
or improper work.
● Be sure to use the specifi ed cables for connecting the indoor and outdoor units. Please ensure that
the connections are tight after the conductors of the wire are inserted into the terminals to prevent the
SPLIT TYPE AIR CONDITIONER
external force is being applied to the connection section of the terminal base. Improper insertion and
loose contact may cause over-heating and fi re.
INDOOR UNIT ● Please use the specifi ed components for installation work. Otherwise, the units may collapse or water
leakage, electric shock, fi re or stronger vibration may occur.
RAK-DJ07QHAA
● Be sure to use the specifi ed piping set for R32. Otherwise, this may result in broken copper pipes or
RAK-DJ09RHAA
faults.
RAK-DJ12RHAA
● When installing or transferring an air conditioner to another location, make sure that air other than the
specifi ed refrigerant(R32) does not enter the refrigeration cycle. If other air should enter, the pressure
level of the refrigeration cycle may increase abnormally which could result in a rupture and injury.
EN INSTRUCTION MANUAL
● Be sure to ventilate fully if a refrigerant gas leak while at work. If the refrigerant gas comes into contact
with fi re, a poisonous gas may occur.
● After completion of installation work, check to make sure that there is no refrigeration gas leakage. If the
FOR SERVICE
refrigerant gas leaks into the room, coming into contact with fi re in the fan-driven heater, space heater,
etc., a poisonous gas may occur.
PERSONNEL ONLY
● Unauthorized modifi cations to the air conditioner may be dangerous. If a breakdown occurs please call
a qualifi ed air conditioner technician or electrician. Improper repairs may result in water leakage, electric
shock and fi re, etc.
● Be sure to connect the earth line from the power supply wire to the outdoor unit and between the outdoor
● Carefully read through the procedures of
and indoor unit. Do not connect the earth line to the gas tube, water pipe, lighting rod or the earth line
proper installation before starting installation
of the telephone unit. Improper earthing may cause electric shocks.
work.
●
When fi nishing the refrigerant collection (pumping down), stop the compressor and then remove the
● The sales agent should inform customers
coolant pipe. If you remove the refrigerant pipe while the compressor is operating and the service valve
regarding the correct operation of installation.
is released, air is sucked and a pressure in the freezing cycle system will build up steeply, causing an
explosion or injury.
●
When installing the unit, be sure to install the refrigerant pipe before starting the compressor. If the
Tools Needed For Installation Work
refrigerant pipe is not installed and the compressor is operated with the service valve released, air is
(Mark is exclusive use tool for R32)
sucked and the pressure level of the refrigeration cycle may increase abnormally which could result in
● + – Screwdriver ● Measuring Tape a rupture and injury.
●
The electric cables should neither be reworked nor added. Make sure to use an exclusive circuit breaker.
● Knife ● Saw ● ø 2-18/32" (65mm)
Otherwise fi re or electric shock might occur by connection failure, isolation failure or over current.
Power Drill ● Hexagonal Wrench Key
●
Make sure to connect cables to terminal properly and terminal cover should close fi rmly. Otherwise, over
( 5/32"(4mm)) ● Wrench (18/32"(14mm),
heating at terminal contact, fi re or electric shock might occur.
21/32"(17mm), 24/32"(19mm), 28/32" ●
Make sure that there is no dust on any connected points of electric cables and fi x fi rmly. Otherwise, fi re
(22mm)) Gas Leakage Detector or electric shock might occur.
●
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
● Pipe Cutter ● Putty ● Vinyl Tape
mental capabilities or lack of experience and knowledge, unless they have been given supervision or
● Pliers ● Flare Tool Vacuum Pump
instruction concerning use of the appliance by a person responsible for their safety.
Adaptor Manifold Valve Charge Children should be supervised to ensure that they do not play with the appliance.
●
Appliance shall be installed in accordance with national wiring regulations and is not intended for use at
Hose Vacuum Pump
altitudes exceeding 2000m (6561-22/32ft).
SAFETY PRECAUTION
Read the safety precautions carefully before
Refrigerant
operating the unit.
Safety Group
A2L
● The contents of this section are vital to ensure safety. Please pay special attention to the following sign.
! WARNING ....... Incorrect methods of installation !
may cause death or serious injury.
Make sure to connect earth line.
Be sure that the unit operates in proper condition after installation. Explain to customer the proper operation and maintenance of
the unit as described in the user's guide. Ask a customer to keep this installation manual together with the instruction manual.
< IA2669: D >
1 Installation of Hanger, Wall Penetration and Installation of Protection Pipe
The draining of the water container inside the indoor unit can be done from the left. Therefore the hanger
●
must be fi xed horizontally or slightly tilted towards the side of drain hose. Otherwise, condensed water
may overfl ow the water container.
Direct Mounting On The Wall
Please use hidden beams in the wall to hold the hanger.
●
4-27/32"
(123mm)
ø2-9/16" (ø65mm)
3 -11/32" 2-18/32"
62-12/32"
(60mm) (85mm) 30-23/32" (780mm) (65mm)
Procedures of Installation and Precautions
Procedures to fi x the hanger.
●
1. Drill holes on wall. 2. Push plug into the holes.
(As shown below) (As shown below)
1-17/64"
(32mm)
Procedures to fi x the holder of remote control.
●
1. Drill holes on wall. 2. Push plug into the holes.
(As shown below) (As shown below)
25/32"
(20mm)
Wall Penetration and Installation of Protection Pipe
Drill a ø 2-18/32" (65mm) hole on
●
wall which is slightly tilted towards
the outdoor side. Drill the wall at a
small angle.
Cut the protection pipe according
●
to the wall thickness.
Seal with
Empty gap in the sleeve of protection
●
putty
pipe should be completely sealed
with putty to avoid dripping of rain
water into the room.
Protection
pipe
>
< IA2669: D
WARNING
!
This appliance is fi lled with R32.
CAUTION ......... Improper installation may
result in serious consequence.
This sign in the fi gures indicates prohibition.
! CAUTION
4-27/32"
(123mm)
ø2-9/16" (ø65mm)
3-5/32"
(80mm)
3. Fix the hanger on wall
with 5/32 x 1-17/64 (4.1 x 32) screw
(As shown in fi gure below)
above 1-31/32"
(50mm)
5/32 x 1-17/64 (4,1 x 32) Screw
WARNING
!
Indoor Outdoor
Be sure that the wire is not
in contact with any metal
3/32" (2mm) -
6/32" (5mm) in the wall. Please use
the protection pipe as wire
Seal with
passing through the hollow
putty
part of the wall so as to
prevent the possibility of
damaged by mouse.
Unless it seals completely,
any air with high humidity
WALL
fl ows from outdoor and dew
Sleeve of
may drop.
protection pipe
The Choice of Mounting Site
(Please note the following matters and obtain permission from customer before installation).
CAUTION
!
● A circuit breaker must be installed in the house distribution box
for the direct connected power supply cables to the outdoor unit.
In case of other installations a main switch with a contact gap
or more than 4/32" (3mm) has to be installed. Without a circuit
breaker, the danger of electric shock exists.
● Do not install the unit near a location where there
is fl ammable gas. The outdoor unit may catch fi re if
fl ammable gas leaks around it.
● Please ensure smooth fl ow of water when installing the drain
hose. Improper installing may wet your furniture.
Piping shall be suitable supported with a maximum spacing of
●
3-9/32' (1m) between the supports.
● Please ensure fi eld selected electrical components (switches,
wires, etc) are following approved local regulation requirements.
● The unit should be mounted at stable, non-vibratory location which can provide full support to the unit.
● No nearby heat source and no obstruction near the air outlet is allowed.
The clearance distances from top, right and left are specifi ed in fi gure below.
●
The location must be convenient for water drainage and pipe connection with the Outdoor unit.
●
● No nearby leakage risk of fl ammable gas, and no nearby source of vapor or oil smoke.
To avoid interference from noise, please place the unit and its remote controller at least 3.28ft(1m) from the radio and television.
●
● To avoid any error in signal transmission from the remote controller, please put the controller far away from high-frequency
machines and high-power wireless systems.
● The installation height should be at least 90-18/32" (2300mm) or more from the fl oor.
The distance from the air outlet to the fi re alarm must be at least 59-2/32" (1500mm) and there must be no fi re alarm in the
●
front direction of the indoor unit.
Do not install the indoor unit in a machine shop, kitchen and laundry rooms when vapor from oil or its mist fl ows to the indoor
●
unit. The oil will deposit on the heat exchanger, thereby reducing the indoor unit performance and may deform and in the
worst case, break the plastic parts of the indoor unit.
Figure showing the Installation of Indoor Unit.
above 1-31/32"
(50mm)
1
above 3-15/16"
(100mm)
Be sure to
completely
seal any gap
with putty.
above 3-15/16"
90-5/8" (2300mm)
or more
The indoor piping should be
insulated with the enclosed
insulation pipe. (If the insulator
is insufficient, please use
commercial products.)
6
Plug
3
5
4
2 Installation of the Indoor Unit
Cutting Low Cover bush
While installing the pipe from the right, left or bottom
●
side, use a knife to cut openings as shown in fi gure.
Then smoothen the edges of openings with a fi le.
PIPING FROM THE RIGHT SIDE (BACKWARD, DOWNWARD, HORIZONTAL)
1
Preparation
Connect connecting cord.
●
Pull out the pipe, connecting cord and drain hose.
●
Installation
Insert the pipe through the wall hole.
●
1 The upper part of the Indoor unit is hanged on the hanger.
2 The projection at the lower part of the Indoor unit is hooked
onto the hanger
1 Hanger
Lift the body of
Refrigerating
the unit upwards
pipe
and then force it
downwards.
Protection Pipe
Connecting Cord
Drain Hose
2 PIPING FROM THE LEFT SIDE (BACKWARD, DOWNWARD, HORIZONTAL)
Preparation
Changed of Drain Hose and Installation Procedures
Exchange the location of drain hose and drain cap while installing the pipe from the left side as shown in below.
●
Be sure to plug in the drain hose until the insulating material folds upon itself.
Please use pliers to pull out the drain cap.
●
(This is an easier way to remove the drain
cap).
Drain cap Drain Hose
Remove low cover.
●
Insert drain cap up to the location securely till the cap stops.
●
Drain hole
CAUTION
!
The rubber strap used for fi xing the insulator should not be tied with great force.
●
Otherwise, this will damage heat insulation and causes water condensation..
Please pull the lower part of the indoor unit outwards to check if the unit is hooked
●
onto the hanger. Improper installation may cause vibration and noise.
Transform the piping while holding down the lower portion of pipe-support by
●
hand.
WARNING
Refrigerant
Safety Group
This appliance is fi lled with R32
A2L
CAUTION
This symbol shows that the Operation Instructions
should be read carefully.
CAUTION
This symbol shows that a service personnel should
be handling this equipment with reference to the
Installation Manual.
CAUTION
This symbol shows that there is information included
in the Operation Manual and/or Installation Manual.
WARNING
!
! CAUTION
Names of Indoor Components
No. Item
Direction of Piping
Hanger
2
Backward piping from left
1
Screw for Hanger
2 (5/32 x 1-17/64)
Connection
(4.1 x 32)
There are 6 directions
(100mm)
Holder for Remote
allowed, namely,
Controller
backward piping, 3
backward piping from
left, horizontally piping
from right, horizontally
AAA size Battery
piping from left, vertically
4
down from right,
vertically down from left.
Screw for Remote
Controller Holder
5
(1/8 x 5/8)
(3.1 x 16)
No. Item Qty
Remote Controller
Conduit Plate
6
Screws for
Conduit Plate
(2 pieces)
8
1
(5/32 x 1/4)
Purifying Filter
(4.0 x 6)
7
Openings
Openings
Connecting cords, pipe
and drain hose must
be laid together with
Vinyl tape.
Wall hole
Pipe
Drain hose
Cable
1 Hanger
1
Drain layout of backward piping
2
Projection
CAUTION
!
Insuffi cient insert may result in water leakage.
Push the pipe deeply until the insulating section
●
of the drain hose end gets over the rib at the
indoor unit side.
Rubber strap tied
Pipe
with great force
Transform after
Pipe support
bending downward
Qty
1
6
1
2
2
1
2
