OPERATION
MANUAL
٤۷-۳۰ اﻟﺻﻔﺣﺔ
Instruction manual
To obtain the best performance, please read this instruction manual completely.
คู ่ ม ื อ การใช ้ ง าน
เพื อได ้รั บ การทํ า งานที ดี ท ี สุ ด โปรดอ่ า นคู ่ ม ื อ อย่ า งละเอี ย ด
< H1189: B >
اﻟﻌرﺑﯾﺔ دﻟﯾل اﻟﺗﻌﻠﯾﻣﺎت
(RC-AGU1EA0G)
Page 1~26
หน ้า 27~54
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hitachi air Home 400 RAK-DJ60PHAE
Summary of Contents for Hitachi air Home 400 RAK-DJ60PHAE
- Page 1 OPERATION MANUAL (RC-AGU1EA0G) ٤۷-۳۰ اﻟﺻﻔﺣﺔ اﻟﻌرﺑﯾﺔ دﻟﯾل اﻟﺗﻌﻠﯾﻣﺎت Instruction manual Page 1~26 To obtain the best performance, please read this instruction manual completely. คู ่ ม ื อ การใช ้ ง าน หน ้า 27~54 เพื อได ้รั บ การทํ า งานที ดี ท ี สุ ด โปรดอ่ า นคู ่ ม ื อ อย่ า งละเอี ย ด <...
-
Page 2: Safety Precaution
SAFETY PRECAUTION Please read the “Safety Precaution” carefully before operating the unit to ensure correct usage of the unit. ● ● Pay special attention to signs of “ Warning” and “ Caution”. The “Warning” section contains matters which, if not observed strictly, may cause death or serious injury. - Page 3 PRECAUTIONS DURING OPERATION The product shall be operated under the manufacturer specifi cation and ● not for any other intended use. Do not attempt to operate the unit with wet hands, this could cause fatal ● accident. When operating the unit with burning equipments, regularly ventilate the ●...
-
Page 4: Operation Range
Operation Range Operation mode Cooling/Dehumidifying Heating Outdoor temperature -10 to 46°C -15 to 21°C Names and Functions of Each Part Indoor Unit Pre-fi lter To prevent dust from coming into the indoor unit. (Refer page 12) Front panel (Refer page 13) Indoor unit indicators Light indicator showing the operating condition. - Page 5 Names and Functions of Each Part Indoor Unit Indications Timer Lamp (Orange) Operation Lamp (Yellow) This lamp lights when the timer This lamp lights during operation. is working. The Operation Lamp fl ashes in the following cases during heating. Wi-Fi Lamp (Blue) (1) During preheating For about 2-3 minutes after starting up.
-
Page 6: Backlight Function
Home is a cloud-based solution for remotely may be shorter. controlling your Hitachi air conditioning system via smart phone. You can operate the air conditioner from Signal Transmission outside the home with your smartphone and check the... -
Page 7: Initial Settings
(1) Before using this air conditioner, make sure that Wireless LAN router (Hereinafter router) local radio stations for identification of mobile objects, specifi ed low-power radio stations and Please use a router that supports the 2.4GHz band. ● amateur radio stations are not operating nearby. For security, be sure to use a router that can set ●... -
Page 8: Usage Restrictions
Your smartphone and air conditioner communicate ● About fi rmware data via our server using the Internet. Therefore, due to the condition of the communication line of your This air conditioner has the function of connecting ● mobile phone company or provider, the setting of your to our server through the Internet and automatically router, or the stop of service due to maintenance of updating its fi... -
Page 9: About Software License
About Software License The software installed in this air conditioner is composed of multiple independent software modules, and each software module has the copyright of Johnson Controls Air Conditioning (Herein after referred to as “the Company”) and a third party. This air conditioner also contains software modules developed or created by us, but these software and accompanying documents have proprietary rights and intellectual property rights... - Page 10 (4) Switch ON your air conditioner now. Once your air conditioner is switched on, or reset the internal settings (restore the factory settings) by remote control, it will automatically set into pairing mode for 10 minutes. Wi-Fi LED on air conditioner’s panel (see diagram in status indicator section) will blink for 3 times repeatedly showing air conditioner is in pairing mode.
- Page 11 Initialization of the Built-in airCloud Home Module Reset the internal settings (restore the factory settings) by remote controller. Please note that the confi guration will be cleared and pairing procedure will be required to do again to use the built-in airCloud Home module. (1) Pressing Mode key &...
-
Page 12: Maintenance
MAINTENANCE CAUTION Cleaning and maintenance must be carried out only by qualifi ed service personnel. Before cleaning, stop operation and switch off the power supply. PRE-FILTER Clean the Pre-fi lter, as it removes dust inside the room. In case the Pre-fi lter is full of dust, the air fl ow will decrease and the cooling capacity will be reduced. - Page 13 CLEANING OF FRONT PANEL Remove the front panel and wash with clean water. ● Wash it with a soft sponge. After using neutral detergent, wash thoroughly with clean water. When front panel is not removed, wipe it with a soft ●...
-
Page 14: Regular Inspection
Regular Inspection FrostWash Operation PLEASE CHECK THE FOLLOWING POINTS BY QUALIFIED It does not wash when outside temperature is less than about 1 SERVICE PERSONNEL EITHER EVERY HALF YEARLY OR degrees Celsius or more than 43 YEARLY. CONTACT YOUR SALES AGENT OR SERVICE degrees Celsius. - Page 15 Shows preheating or defrosting operation The horizontal defl ector remain open. is underway. As the protective circuit Room temperature or humidity may rise. or preheat sensor operates when unit Depending on situation, Mold Guard will OPERATION operation is stopped during preheating operate with Fan Mode.
