AUDIBLE ALARM CONTROLS

INSTRUCTION MANUAL

DRAWING NO. 20215 REV. C

LC1000-A SERIES

INTRINSICALLY SAFE

ALARM CONSOLE

1785 EXPRESSWAY DRIVE NORTH

HAUPPAUGE, NY 11788

(631) 293-8450 Phone

(631) 293-8533 Fax

(800) 209-7858 Support

www.pneumercator.com

72027 – LC1000-A Instruction Manual.docx

October 15, 2024

Table of Contents

Need help?

Do you have a question about the LC1000-A Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Pneumercator LC1000-A Series

Page 1 Date: 2024.11.06 13:35:10 -05'00' AUDIBLE ALARM CONTROLS INSTRUCTION MANUAL DRAWING NO. 20215 REV. C LC1000-A SERIES INTRINSICALLY SAFE ALARM CONSOLE © COPYRIGHT 2024 PNEUMERCATOR CO., INC. 1785 EXPRESSWAY DRIVE NORTH HAUPPAUGE, NY 11788 (631) 293-8450 Phone (631) 293-8533 Fax (800) 209-7858 Support www.pneumercator.com 72027 –...
Page 3: Table Of Contents
LC1000-A INSTRUCTION MANUAL TABLE OF CONTENTS TABLE OF CONTENTS Page Safety Information ....................5 Section 1 PRODUCT DESCRIPTION 1.1 General System Overview ..................8 1.2 Control Console Description ................... 9 1.3 Liquid Sensor Description ..................15 Section 2 INSTALLATION DETAILS 2.1 Installation Checklist .....................
Page 5: Safety Information
The following warnings must be considered in order to comply with accepted codes. Any inquiries about this manual, or to return defective equipment should be directed to: PNEUMERCATOR COMPANY 1785 EXPRESSWAY DRIVE NORTH HAUPPAUGE, NY 11788 Attention: Technical Services...
Page 6 LC1000-A INSTRUCTION MANUAL SAFETY WARNING Installation must be performed in strict accordance with this manual as adopted from the following documents: - ISA RP12.6, "Installation of intrinsically Safe Instrument Systems in Class I Hazardous Locations." - FM – FM Approvals - NFPA 70, "National Electric Code."...
Page 7 LC1000-A INSTRUCTION MANUAL SAFETY WARNING Alteration, modification or replacement with non-factory components could impair the intrinsic safety of this equipment, void the warranty and void the FM Listing. FAILURE TO COMPLY MAY RESULT IN PERSONAL INJURY, PROPERTY LOSS AND EQUIPMENT DAMAGE. PRECAUCIÓN La alteración, modificación o reemplazo con componentes que no sean de fábrica podrían afectar la seguridad intrínseca de este equipo, anular la garantía...
Page 8: Product Description
SECTION 1 – PRODUCT DESCRIPTION 1.1 GENERAL SYSTEM OVERVIEW The LC1000-A series is for use as a secondary containment leak alarm console, single or multi-point level alarm or control, or simply as a remote audible/visual alarm indicator. The console is available in one, two, three or four sensor input configurations, with a corresponding number of super-bright visual LED indicators and Form C relay contact outputs.
Page 9: Control Console Description
PRODUCT DESCRIPTION 1.2 CONTROL CONSOLE DESCRIPTION The Model LC1000-A Series Alarm console provides a front panel-mounted audible alarm, 1-4 visual alarms, a TEST pushbutton to confirm audible/visual alarms and relay operation, and a RESET pushbutton to acknowledge alarms. Sensor inputs are activated on the occurrence of liquid level or secondary containment leak conditions using any combination of Pneumercator level and leak sensors described in Section 1.3.
Page 10 LC1000-A INSTRUCTION MANUAL PRODUCT DESCRIPTION WARNING This product is designed for Ordinary Location, Non-Hazardous classified installation only, as defined by FM Approvals (FM) and the National Electrical Code (NEC). DO NOT install where flammable vapors may be present. FAILURE TO COMPLY MAY RESULT IN PERSONAL INJURY, PROPERTY LOSS AND EQUIPMENT DAMAGE.
Page 11 LC1000-A INSTRUCTION MANUAL PRODUCT DESCRIPTION ENCLOSURE OPTION "F" [186] [143] 4 15 [125] (2) INDICATOR INDICATOR LIGHT LIGHTS ANNUNCIATOR [222] [242] RESET TEST RESET TEST POWER LIGHT RESET TEST PUSHBUTTON PUSHBUTTON OPTIONAL 316 STAINLESS STEEL PADLOCK LATCH (3) Ø [Ø22] HOLES FOR PADLOCK EYE 3 [9] DIA.
Page 12 LC1000-A INSTRUCTION MANUAL PRODUCT DESCRIPTION ENCLOSURE OPTION "F" 16 [291] 8 [156] [138] (3) INDICATOR LIGHTS (4) INDICATOR LIGHTS ANNUNCIATOR [236] [153] RESET TEST RESET TEST RESET TEST POWER LIGHT PUSHBUTTON PUSHBUTTON OPTIONAL 316 STAINLESS STEEL PADLOCK LATCH Ø.375 PADLOCK EYE (5) Ø...
Page 13 LC1000-A INSTRUCTION MANUAL PRODUCT DESCRIPTION WARNING Do not drill or modify enclosure. Use only conduit entries provided. FAILURE TO COMPLY WILL VOID WARRANTY AND MAY PRESENT A SAFETY HAZARD RESULTING IN PERSONAL INJURY, PROPERTY LOSS AND EQUIPMENT DAMAGE. PRECAUCIÓN No taladre ni modifique el recinto. Utilice solo entradas de conducto proporcionadas.
Page 14 LC1000-A INSTRUCTION MANUAL PRODUCT DESCRIPTION MODELS LC1000-A-[ ]-10-[ ] OR LC1000-A-[ ]-20-[ ] MODELS LC1000-A-[ ]-30-[ ] OR LC1000-A-[ ]-40-[ ] NON-INTRINSICALLY SAFE INTRINSICALLY SAFE CONDUIT OPENINGS AND CONDUIT OPENINGS AND DESIGNATED USES: DESIGNATED USES: 1/2" NPT CONDUIT SIZE * 1/2"...
Page 15: Liquid Sensor Description
The LC1000-A provides up to 4 sensor inputs; check the specific job design drawings for the actual number and type specified. Figures 1-5 through 1-8 show four (4) Pneumercator sensor models with their typical applications. Please note that non-Pneumercator sensors may be used with approval from Pneumercator, however, Pneumercator’s EPA-compliant third-party approval will not apply.
Page 16: Model Series
LC1000-A INSTRUCTION MANUAL PRODUCT DESCRIPTION FIGURE OR FIGURE OR FEATURE FEATURE MODEL SERIES OUTLINE MODEL SERIES OUTLINE DRAWING DRAWING TEST LEVER TEST LEVER FIG. 1 (BELOW) LS600M 10620 S.S. STEM S.S. OR S.S. OR BRASS STEM FIG. 2 (BELOW) FIG. 1 (BELOW) LS600 LS600W BRASS STEM...
Page 17 LC1000-A INSTRUCTION MANUAL PRODUCT DESCRIPTION 16' LONG 22 AWG CABLE CABLE GRIP PVC HOUSING FLOAT HIGH ALARM 18.25" 11.00" 15.00" ALARM 2.25" Ø2.88" DRAWING NO. 20056 REV. N/C Figure 1-8 – RSU800 (Refer to Bulletin 134 for Installation/Operation/Testing Instructions) Commonly used in Wet Interstitial Spaces of Fiberglass Tanks PAGE 17...
Page 18: Installation Details
LC1000-A INSTRUCTION MANUAL INSTALLATION DETAILS SECTION 2 – INSTALLATION DETAILS 2.1 INSTALLATION CHECKLIST WARNING Do NOT apply power to this product until its installation has been checked and found to be in accordance with these instructions, National Electric Code, Federal, State and Local codes, and any other applicable safety codes. FAILURE TO COMPLY MAY RESULT IN PERSONAL INJURY, PROPERTY LOSS AND EQUIPMENT DAMAGE.
Page 19 LC1000-A INSTRUCTION MANUAL INSTALLATION DETAILS The following points should be reviewed in preparation for installation, and again when installation is complete. 1. Review Figures 3-2 and/or 3-3 to ensure that all of the safety/wiring requirements have been met. 2. Check that all equipment at job site matches the DESIGN DRAWING SPECIFICATIONS for the tank sizes and control features required.
Page 20: Control Console Installation
LC1000-A INSTRUCTION MANUAL INSTALLATION DETAILS 2.2 CONTROL CONSOLE INSTALLATION The console is the center of operations for any tank monitor system therefore its location should be selected for the operator’s convenience, or as specified on the DESIGN DRAWINGS. Select a flat wall surface and prepare it with four wall-mounting inserts to accept up to 1/4-inch size bolts.
Page 21 LC1000-A INSTRUCTION MANUAL INSTALLATION DETAILS I.S. COMPARTMENT COVER TYPICAL (2) PLACES (SHOWN CLOSED) COVER CAPTIVE SCREW TYPICAL (2) PLACES I.S. GROUND INTERCONNECTIONS FUSE COVER FUSE HOLDER FUSE (2) I.S. COMPARTMENTS (COVER OPENED) BOARD #1 (LEFT) BOARD #1 (LEFT) DC POWER CABLE I.S.
Page 22: Leak Sensor Installation - Steel Tanks
The cap or reducer bushing IS NOT SUPPLIED with the sensor and must be provided by the installer. A 2” (SK2) or 4” (SK4) Sensor Cap Kit can be ordered separately from Pneumercator). 3. Measure the "MOUNTING HEIGHT" from top to bottom of monitoring pipe.
Page 23: Leak Sensor Installation - Piping Sumps And Dispenser Pans, Vaulted Tank
LC1000-A INSTRUCTION MANUAL INSTALLATION DETAILS 2.4 LEAK SENSOR INSTALLATION IN PIPING SUMPS AND DISPENSER PANS Check the specific design drawings for the job, or use the LS600LD Series as illustrated in Figure 1-5. Install sensor per Figure 2-3 as follows: 1.
Page 24: Leak Sensor Installation - Fiberglass Underground Tanks
(SK2) or 4” (SK4) Sensor Cap Kit can be ordered 12 Feet 222 in. separately from Pneumercator). 4. At riser top, attach the annular space PULL CORD (this is part of the tank supplier's pre-installed accessories) to the sensor's PULL HOLE.
Page 25: Other Dry Contact Float Switches
LC1000-A has not been specifically approved for use with sensors not manufactured by Pneumercator. Please consult with your local regulators and with Pneumercator to discuss the compatibility of your particular sensor with the console and application.
Page 26: Wiring Installation
SECTION 3 WIRING INSTALLATION 3.1 PC BOARD LAYOUT AND SETUP The LC1000-A Series includes either one (1-2 channels) or two (3-4 channels) PC boards within the enclosure. Each board is equipped with a set of switches for each channel to configure the sensor inputs and relay outputs to suit the particular application.
Page 27 LC1000-A INSTRUCTION MANUAL WIRING PNEUMERCATOR Liquid Level Control Systems 10W AC POWER SUPPLY CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. REMOVING COVER WILL VOID WARRANTY. Model: 900867-1* Input Voltage: 95-250VAC 1/2A. 5x20mm Auto Switching Fast Acting Frequency: 50/60Hz Replacement...
Page 28 LC1000-A INSTRUCTION MANUAL WIRING CAUTION Sensors connected to this product may be in installed in hazardous-classified areas typical of hydrocarbon-based liquid fuel tanks. For these applications, it is CRITICAL that electrical conduit and wiring be installed by qualified installers familiar with all provisions of the National Electrical Code relating to equipment intended for use in EXPLOSION HAZARD areas.
Page 29: System Wiring
LC1000-A INSTRUCTION MANUAL WIRING 3.2 SYSTEM WIRING The Appendix in the back of this manual contains typical System Wiring Diagrams that must be followed when running conduit and wires between the HAZARDOUS TANK area and the NON-HAZARDOUS CONSOLE area. This follows FM and other codes for proper installation. SENSOR WIRING INSTALLATION.
Page 30: Switch Inputs
LC1000-A INSTRUCTION MANUAL WIRING LIGHT #2 LIGHT #1 OPEN HORN CLAXON KLAXON  OPEN MINUTES MINUTO S MINUTES (0-9) SENSOR RELAY SENSOR RELÉ LC1000-A-03-20-0 CAPTEUR RELAIS   LIGHT #1 OPEN HORN CLAXON KLAXON  MINUTES MINUTO S MINUTES (0-9) SENSOR RELAY SENSOR...
Page 31: Relay Output Wiring
LC1000-A INSTRUCTION MANUAL WIRING 5. The alarm console is separated into two wiring sections, for each printed circuit board, by an aluminum cover. The wiring and terminal block on the left side are intrinsically safe and are physically separated from the AC power wiring on the right side. This separation must be maintained.
Page 32 LC1000-A INSTRUCTION MANUAL WIRING CAUTION Sensor wires are to be routed through their designated conduit openings and connected ONLY to their designated input terminals of the INTRINSIC SAFETY compartment. DO NOT allow sensor wires to cross over into the non-intrinsically safe section.
Page 33 LC1000-A INSTRUCTION MANUAL WIRING CAUTION Relay output terminals are located on the NON-INTRINSICALLY SAFE side of the console. ALL wiring to these terminals MUST enter through the designated conduit opening. Refer to FIGURE 1-4. FAILURE TO COMPLY MAY RESULT IN PERSONAL INJURY, PROPERTY LOSS AND EQUIPMENT DAMAGE.
Page 34: Sensor Map/System Setup
LC1000-A INSTRUCTION MANUAL WIRING 3.3 SENSOR MAP/SYSTEM SETUP The sensor map/system setup below should be completed by the electrical installer as each sensor and control output function is wired to the LC1000-A system. This will provide the equipment operator a means of identifying each field device for proper system setup and use. The SENSOR MAP/SYSTEM SETUP should be adhered to or kept near the LC1000-A console.
Page 35: Installation As A Remote Alarm Panel
A single pair of wires per signal would connect the main system via the dry contact output to the LC1000-A on the Switch input. All Pneumercator systems equipped with relay outputs are considered dry contact, or outputs without power. Other equipment manufacturers may use powered relay outputs. Consult the system manufacturer to determine if the system is equipped with outputs that are dry contact that can be used to represent the desired alarm condition.
Page 36: Operation
LC1000-A INSTRUCTION MANUAL OPERATION SECTION 4 OPERATION 4.1 GENERAL The LC1000-A Alarm system provides three (3) functions when a field sensor experiences an alarm condition: A light blinks, a horn annunciates and a relay changes state. The horn may be silenced by pressing the RESET button, and the light will stay on without blinking and the relay will remain in the alarm state as long as the field sensor remains in the alarm condition, e.g., high liquid level.
Page 37: Troubleshooting
LC1000-A INSTRUCTION MANUAL TROUBLESHOOTING SECTION 5 TROUBLESHOOTING 5.1 GENERAL The On/Off switching control operation of the LC1000-A makes it simple to test and troubleshoot the system. Pressing the TEST button performs a functional test of the horn and all indicator lights.
Page 38: Maintenance/Testing
LC1000-A INSTRUCTION MANUAL MAINTENANCE SECTION 6 MAINTENANCE/TESTING WARNING Testing MUST be performed by qualified personnel familiar with local wiring codes and explosion hazard electrical safety practices. FAILURE TO COMPLY MAY RESULT IN PERSONAL INJURY, PROPERTY LOSS AND EQUIPMENT DAMAGE. PRECAUCIÓN Las pruebas DEBEN ser realizadas por personal calificado que esté...
Page 39: Appendix Wiring/Specifications
(RED) TO (RED) TO CONSOLE (WHT) TO (WHT) (AS SHOWN ABOVE) (BLK) TO (BLK) DRY CONTACT INPUTS DRY CONTACT INPUTS DRY CONTACT INPUTS (LEAK/POINT-LEVEL SENSORS) (LEAK/POINT-LEVEL SENSORS) (LEAK/POINT-LEVEL SENSORS) PNEUMERCATOR Liquid Level Control Systems 50506 No Change (09/13/17) Page 1 of 2...
Page 40 WIRING DRAWING - LEAK/POINT-LEVEL ALARM CONSOLE (LC1000-A) NO CHANGES WITHOUT PRIOR FM APPROVAL NON I.S. wiring 1 TO 2-CHANNEL 1 TO 4-CHANNEL IMPORTANT NOTES - READ CAREFULLY BEFORE INSTALLATION (NOT ALL FEATURES ARE SHOWN TO SCALE) (NOT ALL FEATURES ARE SHOWN TO SCALE) UNLESS OTHERWISE SPECIFIED: (NOTES 2-3 DO NOT APPLY TO THIS PAGE) NON I.S.
Page 42: Wiring Specifications
LC1000-A INSTRUCTION MANUAL WIRING/SPECIFICATIONS SPECIFICATIONS Operating Temperature: -40 ºF to 160 ºF (-40 ºC to 70 °C) Humidity: 95% Non-condensing Enclosure Rating: NEMA 4X (IP66) Power Requirements: Universal 95-250 VAC, 50-60 Hz, 10 W Max. Audible Alarm: 103 dB w/Louvered Volume Control Visual Alarm Indicators: Super-bright LED, Wide Viewing Angle Power Indicator:...
Page 44: Warranty
This constitutes our obligation and none other stated for any purpose except the above shall apply. Contact Pneumercator for detailed warranty documentation. REVISION 101008 Distributed by: Pneumercator Co.
