- Page 1 FULLWHITE MANUAL...
- Page 2 CORNER ELEMENTS 4 pieces- basic frame 52x52 cm (fig.: including SET UP SUPPORT, optional) CENTRE SUPPORT Consists of plug in elements with integrated screw connection ACCESSORY BAG Yellow bag for mounting accessories PROJECTION SCREEN BAG Lined storage bag for folded projection screen (Optional transport tube for rolled delivery)
- Page 3 128x25x30 cm big 133x31x35 cm (optional Flightcase) FULLWHITE FRAME Modular plug-in frame system Basic frame (4 corners 52x52 cm), Frame components in custom length Fullwhite compact: standard and supplementary frame components in short lengths for small transport volume ASSEMBLY INSTRUCTION...
-
Page 4: Table Of Contents
GENERAL STANDARDS, REGULATIONS AND TECHNICAL SPECIFICATION SAFETY OPERATION, MAINTENANCE and SERVICE WARRANTY OVERVIEW FULLWHITE FRAME COMPONENTS CLAMP CONNECTION FRAME MOUNTING WITH SET UP SUPPORT CENTER SUPPORT PIVOT NUTS ATTACHMENT OF SET UP SUPPORT MOUNTING OPTIONS FRAME MOUNTING WITHOUT SET UP SUPPORT ACCESSORIES ©www.pi-tec.com... -
Page 5: General
GENERAL STANDARDS, REGULATIONS and TECHNICAL SPECIFICATION This projection screen is in accordance with the safety regulations in DIN standard 19045 and DIN 56950. The screen fabric is comply with DIN 4102 part 1 and the specifications of the according data sheet. For the technical details and projection-specific material parameters please refer to the corresponding product data sheet: www.AVstumpfl.com/projectionmaterials Detailed data of frame components, legs and projection surface can be found on the type labels on each component and on the labeled soft bags, roller bags or flight cases. - Page 6 SET UP-ASSEMBLY MECHANICAL HAZARDS Danger of injury due to improper assembly. Make sure all frame parts assembled correctly and all hinges and joints are locked before raising screen to standing position. Falling parts can cause severe injury or death! Projection surface damage in case of faulty assembly or set up. Make sure all frame parts assembled correctly and all hinges and joints are locked before one unfold and attach the projection surface.
- Page 7 WARNING FULLWHITE systems are developed for indoor use only. Failure to follow warning may result in personal injury due to unforeseen acts of nature. Any damage and consequential damage caused by outdoor use is not covered by warranty. BASIC SAFETY REQUIREMENTS Basic safety requirements for „flying“...
-
Page 8: Operation, Maintenance And Service
DISASSEMBLY For disassembly the same safety instructions apply as for assembly and set up. Bring down a projection screen with the appropriate number of people to avoid falling over of the screen. Falling parts can cause severe injury or death! OPERATION, MAINTENANCE and SERVICE FRAME ELEMENTS, LEGS and ACCESSORIES: The frame elements, legs and additional elements are maintenance-free. -
Page 9: Warranty
WARRANTY The warranty period for production deficiencies is 5 years for the frame elements and 24 months for the projection surface. Mobile projection screens are developed for indoor use only. Any damage and consequential damage caused by outdoor use is not covered by warranty. The general terms and conditions are available at http://avstumpfl.com/agb LIMITATION OF LIABILITY All the details in this manual were compiled in consideration of the standards and legal regulations... -
Page 10: Overview
OVERVIEW Further development of the mobile projection screens for applications where hidden technology and puristic design is required. With the minimalistic design this projection screen fits easily in every optical superior installation. Universal, invisible mounting options as well as high stability and flexibility are essential features of this projection system. -
Page 11: Fullwhite Frame Components
FULLWHITE FRAME COMPONENTS FULLWHITE All components of the projection screen are labeled. For assembly, start with the basic frame. Place the corner elements 1 to 4 according to drawing above. Afterwards separate the frame components to „horizontal“ and „vertikal“ and halve the number for each frame site. -
Page 12: Clamp Connection
CLAMP CONNECTION The Fullwhite clamp connector is equipped with a center safety screw. Beware of pinch points! The clamp connection is tightened with the two screws (1&2) and additionally secured with a center safety screw (3). Therefore use the included TORX screwdriver TX25. -
Page 13: Frame Mounting With Set Up Support
FRAME MOUNTING WITH SET UP SUPPORT PROTECTIVE FOIL Before you unroll the projection surface with the projection side down, the floor has to be cleaned com- pletely and the supplied protective foil has to be laid out. The protective foil is to prevent dirt and damage of the projection surface. FRAME MOUNTING Detailed instruction for SET UP SUPPORT (optional accessory) on page 13 NOTE: SET UP SUPPORTS can remain folded up on the frame after mounting. -
Page 14: Center Support
CENTER SUPPORT 1-2 Put together the center support according to the labels and secure the connections with the two wing nuts. 3 Detach the pivot nuts from the top and bottom center support element and insert them into the inner slot of the horizontal frame bar. - Page 15 SURFACE ATTACHMENT 1-2 Foldaway legs hold the projection screen’s frame in position above the floor to allow the surface attachment from top. 3-4 Lay out the surface on the frame with the label „OBEN-TOP“ corresponding with the upper frame bar. It is necessary to carry out this step with several people to avoid damage of the projection surface.
- Page 16 5-6 Attach the surface by starting at the first corner to fix one vertical and horizontal hook to the corner clip. Repeat this step according to the order in picture 7. Finally stretch all the remaining hooks one by one over the profile edge and put them into the bottom profile slot.
-
Page 17: Pivot Nuts
ATTACHMENT OF SET UP SUPPORT The installation of the projection surface with large FULLWHITE is done by using SET UP SUPPORTS. Those foldaway legs hold the frame approx. 12 cm above the floor to allow the surface attachment from top. -
Page 18: Mounting Options
MOUNTING OPTIONS MOUNTING BRACKET FOR WALL MOUNTING Optional as vertical or horizontal mounting point MOUNTING BRACKET FOR CEILING SUSPENSION MOUNTING BRACKETS FOR LEGS: Individually movable mounting brackets for legs can be mounted at the inner side of the frame profile. -
Page 19: Frame Mounting Without Set Up Support
FRAME MOUNTING WITHOUT SET UP SUPPORT In case of frame mounting without SET UP SUPPORT the profiles have to be placed on the floor with the profile groove to the top . -
Page 20: Protective Foil
PROTECTIVE FOIL Before you unroll the projection surface with the projection side down, the floor has to be cleaned completely and the supplied protective foil has to be laid out. The protective foil is to prevent dirt and damage to the projection side of the projection surface. SURFACE MOUNTING The frame now needs to be placed flat onto the backside of the projection surface according to the photo.This step has to be carried out with several people to avoid any damage of the projection... -
Page 21: Accessories
3. WARNING Falling parts! CONNECTION BRACKETS AND CONNECTION PLATES To connect Fullwhite frames, several types of connection are available on request. Example 1: Connection bracket outside corner 90° Example 2: Connection bracket inner corner... - Page 22 AV Stumpfl GmbH | Mitterweg 46 | 4702 Wallern AVstumpfl@AVstumpfl.com | www.AVstumpfl.com | +43 7249 42811...
