  • Page 1 VARIO CURVE MANUAL...

  • Page 2: Table Of Contents

    FRAME SET UP ....................8 CENTRE SUPPORT ................... 9 SURFACE MOUNTING ...................10 AV Stumpfl GmbH | Mitterweg 46 | 4702 Wallern AVstumpfl@AVstumpfl.com | www.AVstumpfl.com | +43 7249 42811 We reserve the right to make modifications in the interest of technical progress.

  • Page 3: General

    BACK GENERAL STANDARDS, REGULATIONS AND TECHNICAL SPECIFICATION This projection screen is in accordance with the safety regulations in DIN standard 19045 and DIN 56950. The screen fabric is comply with DIN 4102 part 1 and the specifications of the according data sheet.
  • Page 4 BACK SET UP-ASSEMBLY MECHANICAL HAZARDS Danger of injury due to improper assembly. Make sure all frame parts assembled correctly and all hinges and joints are locked before raising screen to standing position. Falling parts can cause severe injury or death! Projection surface damage in case of faulty assembly or set up.
  • Page 5 BACK WARNING Vario Curve systems are developed for indoor use only. Failure to follow warning may result in personal injury due to unforeseen acts of nature. Any damage and consequential damage caused by outdoor use is not covered by warranty.

  • Page 6: Operation, Maintenance And Service

    BACK DISASSEMBLY For disassembly the same safety instructions apply as for assembly and set up. Bring down a projection screen with the appropriate number of people to avoid falling over of the screen. Danger of injury Beware of due to improper pinch points.

  • Page 7: Warranty

    BACK WARRANTY The warranty period for production deficiencies is 5 years for the frame elements and 24 months for the projection surface. Mobile projection screens are developed for indoor use only. Any damage and consequential damage caused by outdoor use is not covered by warranty. The general terms and conditions are available at www.AVstumpfl.com/agb LIMITATION OF LIABILITY All the details in this manual were compiled in consideration of the standards and legal regulations...

  • Page 8: Frame Set Up

    BACK FRAME SET UP Required tools: • 3-5 ladders • 4mm Allen key 1-2 Assemble the upper and lower horizontal elements according to the numbering and fasten them (1 Nm). 3-4 Unfold the lateral vertical elements and plug them with the lower horizontal corner elements according to the labeling and tighten the thread bolts with the allen key.

  • Page 9: Centre Support

    BACK CENTRE SUPPORT 5-7 Unfold the center support and bolt them to the lower horizontal frame section according to the labeling with the enclosed wing screws. Beware of pinch points! 8-9 Attach the upper frame section to the top end of the vertical frame sections with at least 3 people. WARNING Falling parts!

  • Page 10: Surface Mounting

    BACK SURFACE MOUNTING 10-12 Unroll the projection surface with, according to the screen size appropriate number of people and hook it onto the rail of the upper horizontal frame section and slide it with several people gently till the opposite corner.
