ACCESSORY BAG Yellow bag for mounting accessories ASSEMBLY INSTRUCTION CURVED HORIZONTAL ELEMENTS Consists of plug in elements with integrated pin-lock screw connection...
Page 3
FOLDABLE CENTER SUPPORT VERTICAL FRAME ELEMENTS Modular plug-in frame system Frame components in custom length BASIC FRAME 4x corner parts 34x52cm...
INDEX SCOPE OF DELIVERY GENERAL OVERVIEW FULLWHITE CURVE FRAME COMPONENTS HORIZONTAL FRAME SECTIONS CORNER ELEMENTS VERTICAL FRAME ELEMENTS TOP FRAME SECTION & CENTER SUPPORTS SURFACE ATTACHMENT FRAME COMPLETION LEG ATTACHMENT ACCESSORIES...
GENERAL QUALITY AND SAFETY: This projection screen is in accordance with the safety regulations in DIN standard 19045 and DIN 56950. The screen fabric is comply with DIN 4102 part 1 and the specifications of the according data sheet. WARRANTY: The warranty period for production deficiencies is 5 years for the frame elements and 24 months for the projection surface.
OVERVIEW SYSTEM COMPONENTS: The hollow chamber profile with trapezoid shape gives an extra high stability and allows a perfect wrinkle-free application of the projection surface on the backside of the profile with hooks. CURVED CONNECTIONS Curved horizontal parts are connected by locking pins with conical grooves for a gap-free assembly. Additional wedge clamps ensure a perfect alignment of the profile edges.
FULLWHITE CURVE FRAME COMPONENTS FULLWHITE CURVE All components are labeled and/or numbered. Numbering starts with the left top corner in clockwise direction. Required tools are enclosed: • 5mm hexagonal screwdriver • 3mm hexagonal screwdriver • Torx TX25 screwdriver Depending on screen size we recommend to use stepladders to ease the assembly.
HORIZONTAL FRAME SECTIONS 1-3 Assembled horizontal frame sections 4 Assemble the upper and lower horizontal elements according to the numbering. 4-6 Plug together equal numbered parts and slightly screw in the two set screws with the 5mm hexagonal screwdriver so that the connection is secured, but do not fasten.
Page 9
7-8 Next tighten the wedge clamp until the profile edges are perfectly aligned. 9-10 Now fasten the two 5mm hexagonal set screws completely. Repeat this step until both horizontal sections are completed.
CORNER ELEMENTS BOTTOM LEFT BOTTOM RIGHT TOP LEFT TOP RIGHT 1-4 Now attach the corner parts on both sides of the already assembled bottom and top horizontal frame sections.
VERTICAL FRAME ELEMENTS BOTTOM LEFT BOTTOM RIGHT 1-2 Plug in the first vertical frame element on each side of the bottom corners. Tighten the two clamp screws 3-4 and secure it with the center safety screw 5.
TOP FRAME SECTION & CENTER SUPPORTS 1-3 Next connect the first vertical element to each corner of the top frame section and bolt the center supports at the appropriate labeled positions.
SURFACE ATTACHMENT Unfold the projection surface with, according to the screen size appropriate number of people. Start to hook in the projection surface at one corner. Make sure that the lateral hooks are secured by the black plastic corner clip. Once the first corner is covered properly you can attach the surface to the top horizontal frame section.
Secure the two vertical frame connections and bolt the center supports to the bottom frame. LEG ATTACHMENT Attach the legs to the threaded round spacers of the center supports in the desired height, with the delivered wing screws. Once the Fullwhite curve is on legs the attachment of the projection surface can be finished.
ACCESSORIES PIVOT NUTS General attachment of pivot Nuts M8 with flexible tongue (Different to the illustration above, the pivot Nuts M8 for SET UP SUPPORT is equipped with a spring loaded ball) MOUNTING OPTIONS MOUNTING BRACKET FOR WALL MOUNTING Optional as vertical or horizontal mounting point MOUNTING BRACKET FOR CEILING SUSPENSION...
