XDrum DD-460P Instruction Manual

Mesh e-drum kit
Hide thumbs Also See for DD-460P:

Advertisement

Quick Links

00073463 - XDrum DD-460P Mesh E-Drum Kit
00073464 - XDrum DD-460C Mesh E-Drum Kit
Instruction manual
Revision: 04-2023

Advertisement

loading
Need help?

Need help?

Do you have a question about the DD-460P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for XDrum DD-460P

  • Page 1 00073463 - XDrum DD-460P Mesh E-Drum Kit 00073464 - XDrum DD-460C Mesh E-Drum Kit Instruction manual Revision: 04-2023...
  • Page 2: Table Of Contents

    XDrum DD-460 E-Drum __________________________________________________________________________ © 2023 These operating instructions are protected by copyright. The reproduction of these operating instructions, even in part, is only permitted with the approval of Musikhaus Kirstein GmbH. The same applies to the reproduction or copying of images, even in modified form.
  • Page 3 XDrum DD-460 E-Drum __________________________________________________________________________ Thank you for choosing this product. To ensure that you are completely satisfied with this product, please read this instruction manual carefully before using our product. Keep these operating instructions in a safe place. The operating instructions must be passed on to all subsequent users.
  • Page 4: Safety Precautions And Precautionary Measures

    XDrum DD-460 E-Drum __________________________________________________________________________ Safety precautions and precautionary measures Always place the device securely on a level surface to avoid injuries caused by the device falling over. Do not place any devices that can heat up (e.g. lighting equipment or fog machines) on the device.
  • Page 5: Important Information

    XDrum DD-460 E-Drum __________________________________________________________________________ Important information Power supply Do not plug the device into the same outlets as other electrical equipment controlled by an inverter (e.g. freezer, washing machine, microwave or air conditioner) or containing a motor. Depending on how the electrical appliance is used, disturbances in the power supply may cause malfunctions and/or produce audible noises.
  • Page 6: Structure And Functions

    XDrum DD-460 E-Drum __________________________________________________________________________ Structure and functions 1. Drum module 2. Hi-Hat Cymbal 3. Crash cymbal 4. Tom 1 pad 5. Tom 2 Pad 6. Ride cymbal 7. Tom 3 Pad 8. Snare Pad 9. Foot machine 10. Hi-Hat Controller...
  • Page 7: Installation Guide

    XDrum DD-460 E-Drum __________________________________________________________________________ Installation guide  Open the packaging with a knife and remove all components. Compare the components with the parts list above.  Assemble the components as described in the pictures below and then screw them tight.
  • Page 8 XDrum DD-460 E-Drum __________________________________________________________________________  Mount cymbal pads to cymbal rods...
  • Page 9: Module

    XDrum DD-460 E-Drum __________________________________________________________________________  Attach the tom to the rack g.  You can now place the pedals on the floor and connect the cymbal pads, as well as the toms to the module via cable. Module Front...
  • Page 10 XDrum DD-460 E-Drum __________________________________________________________________________ 1. Display: For displaying various information. 2. Volume control: To adjust the overall volume. 3. +/- buttons: Press these buttons to switch drum kits, metronome tempo selection, song selection, etc. Pressing the [+] button will increase the value and pressing the [-] button will decrease the value.
  • Page 11 XDrum DD-460 E-Drum __________________________________________________________________________ Back cover: 1. CRASH 2 connector: Use this jack to connect a second crash cymbal. 2. TOM 4 connector: Use this connector to connect a fourth tom pad. 3. Headphone output: for connecting stereo headphones. When using headphones, the LINE OUT is not muted.
  • Page 12: Quick-Start

    XDrum DD-460 E-Drum __________________________________________________________________________ Quick-Start Connect the power supply and audio equipment (headphones, external speaker) to the module according to the instructions. Now press the [POWER] button on the module to start the device and enter the Start-screen. You can use the [-], [+] buttons to switch to different drum kits. Use the drumsticks to play each pad.
  • Page 13: Coach Mode

    XDrum DD-460 E-Drum __________________________________________________________________________ Beat Controls the number of beats per measure. You can choose between 1 and 16. Rhythm There are seven different rhythm patterns available. Volume Controls the volume of the metronome. Range: 0-127. Controls the panorama of the metronome.
  • Page 14: Loop Recording

    XDrum DD-460 E-Drum __________________________________________________________________________ B. Beats Displays the number of beats per measure and can also be set in the metronome settings. C. Meas Specifies how many bars are recorded in total. The possible setting range is between 1 and 16.
  • Page 15: Song Mode

    XDrum DD-460 E-Drum __________________________________________________________________________ Song mode Press [♪] to enter Song mode (as shown below). A. Song Name Displays the name of the currently selected song. Use the [<] and [>] keys to switch between the different songs. B. Song volume Use [+], [-] to adjust the volume of the songs.
  • Page 16: Instrument Settings

    XDrum DD-460 E-Drum __________________________________________________________________________ KIT NUMBER Indicates the position of the currently selected drum kit. You can use the [+] and [-] keys to adjust the order of the drum kits. This changes the order in drum kit mode. MIDI CONFIG Use the [+] and [-] buttons to select one of the four MIDI codes for each drum kit.
  • Page 17: Pad Settings

    XDrum DD-460 E-Drum __________________________________________________________________________ Wave Gives you the option to set different instruments/sounds for each pad. Use [+] and [-] to change the instrument. You can also press [OK] to enter the sound list menu, as shown below. Here you have a better overview of the different instruments.
  • Page 18 XDrum DD-460 E-Drum __________________________________________________________________________ linear The volume increases evenly the harder you hit the pad. The volume reaches the maximum faster with less punch. Ideal for sounds you want to play without a large dynamic range. The volume reaches the maximum more slowly or requires more punch. Ideal for sounds with additional nuances.
  • Page 19: Midi Settings

    XDrum DD-460 E-Drum __________________________________________________________________________ With a high value, it will thus be difficult to play very fast. Set this to as low a value as possible using the [+] and [-] keys. If the second hit is stronger than the previous one, Mask Time will not be activated.
  • Page 20 XDrum DD-460 E-Drum __________________________________________________________________________ CHANNEL Specifies the MIDI channel number for transmission. Range: 0-15 MIDI IN Sets whether MIDI data sent from an external MIDI device is received (ON) or not received (OFF). The preset default is ON. MIDI OUT Determines whether MIDI data is sent (ON) or not sent (OFF) to an external MIDI device.
  • Page 21: Options

    XDrum DD-460 E-Drum __________________________________________________________________________ Options Use the up and down arrow keys to select the parameters to adjust and use [+] and [-] to change the value or type of the selected parameters. LCD-CONTRAST Adjust the display contrast. Range: 0-20 AUTO TRACE Turn the pad tracking function on or off.
  • Page 22: Simplified Eu Declaration Of Conformity

    XDrum DD-460 E-Drum __________________________________________________________________________ Simplified EU Declaration of Conformity Hereby Musikhaus Kirstein GmbH declares that the radio equipment type [Pronomic MOVE 112MA-A Akku-Aktivbox 12" and Pronomic MOVE 115MA-A Akku-Aktivbox 15"] complies with the directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following Internet address available: http://www.kirstein.de/docs/Konformitaetserklaerung/CE_Konformitaetserklaerung_...
