Conceptronic ZEUS51E6K User Manual

Hide thumbs Also See for ZEUS51E6K:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
ZEUS51E6K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZEUS51E6K and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Conceptronic ZEUS51E6K

Summary of Contents for Conceptronic ZEUS51E6K

  • Page 1 User Manual ZEUS51E6K...

  • Page 2: Table Of Contents

    CONTENT： 1. Safety .........................1 1.1. Installation ....................1 1.2. Operation ....................1 1.3. Maintenance, Servicing and Faults ............2 1.4. Transport ....................3 1.5. Storage ......................3 1.6. Standards ....................3 2. Descriptionof Commonly Used Symbols ............4 3. Introduction .......................4 3.1. Feature .......................5 3.2. Electrical Specifications ................6 3.3.
  • Page 3 9.1. USB Interface ................... 34 9.2. RS232 Interface ..................34 9.3. Intelligent slot ................... 34 10. Software Installation ..................35...

  • Page 4: Safety

    1. Safety Please read carefully the following user manual and the safety instructions before installing the unit or using the unit! 1.1. Installation ⚫ This is permanently connected equipment, and it must be installed by qualified maintenance personnel. ⚫ Condensation may occur if the UPS is moved directly from a cold to a warm environment.

  • Page 5: Maintenance, Servicing And Faults

    not connected to the building wiring terminal, for there is internal current source (batteries). ⚫ In order to fully disconnect the UPS, first turn the input breaker in the "OFF" position, then disconnect the mains lead. ⚫ Indiscriminate operation of switches may cause output loss or damage to equipment.

  • Page 6: Transport

    1.4. Transport Please transport the UPS only in the original packaging to protect against shock and impact. 1.5. Storage The UPS must be stockpiled in the room where is ventilated and dry. 1.6. Standards * Safety IEC/EN 62040-1 * EMI Conducted Emission........:IEC/EN 62040-2 Category C3 Radiated Emission........:IEC/EN 62040-2...

  • Page 7: Descriptionof Commonly Used Symbols

    Recycle with ordinary trash 3. Introduction The ZEUS51E6K is an uninterruptible power supply incorporating double-converter technology. It provides perfect protection specifically for computer equipments, communication servers, and data centers. The double-converter principle eliminates all mains power disturbances. A rectifier converts the alternating current from the mains power to direct current. On the basis of this DC voltage, the inverter generates an AC sinusoidal voltage, which constantly supplies the loads.

  • Page 8: Feature

    Fig.3-1 The rear view of ZEUS51E6K * EPO Port can be set to a ROO port in setting configuration EPO: Enable Power-Off in emergency from a remote location. ROO: Power ON/OFF from a remote location. Fig.3-2 The rearview of battery pack ①.

  • Page 9: Electrical Specifications

    ⚫ ECO mode with high efficiency ≥96%, save power expense for user. ⚫ Start-able without battery. 3.2. Electrical Specifications Model ZEUS51E6K Input Phase Single Voltage Range 80~300Vac(Depends on load level) Frequency Range (45~55)/(54~66)Hz...

  • Page 10: Operating Environment

    3.3. Operating Environment Temperature Humidity Altitude Storage temperature 0℃~40℃ <95% <1000m -15℃~50℃ Note: The load capacity should be derated 1% every 100m heightened on the basis of 1000m. 3.4. Dimensions and Weights Model Dimensions W×H×D(mm) Net Weight (kg) 438*261*680 59.4 ZEUS51E6K...

  • Page 11: Installation

    4. Installation The system must be installed and wired only by qualified electricians in accordance with applicable safety regulations! For safety, please cut off the mains power switch before installation! When installing the electrical wiring, please note the nominal amperage of your incoming feeder.
  • Page 12 Insert dust cover into the rackmount ear screw holes that are not being used. ： Step2.Install the power module on the rack Place the power module on a flat stable surface with the front of the unit facing toward you. Secure the power module to your rack with four M5X12L screws at the front of the rack.

  • Page 13: Vertical/Tower Installation

    4.3. Vertical/Tower Installation ： Step1.Rotate the multifunction LCD module Unscrew the right panel of the Power Module. Separate the right panel from Power Module. Unscrew the left panel of the Power Module. Separate the left panel from Power Module. Rotate the LCD module to the left. Reinstall it for a tower configuration .
  • Page 14 Last tighten the screws to fix the left panel and the right panel. ： Step2.Attach the base stands Connection#1: Power module without external battery pack Tighten the screws (M5X12*8pcs) of the base stands (rackmount ears) onto the bottom of Power Module. Insert dust cover into the rackmount ear screw holes that are not being used.
  • Page 15 Connection#2: Power module with external battery pack Tighten the screws (M5X12*8pcs) of the base stands (rackmount ears) onto the bottom of power module and battery pack. Insert dust cover into the rackmount ear screw holes that are not being used.

  • Page 16: Power Wires Installation

    Otherwise there are hazards of electric shock. 4.4.2. Installation ： Use cable cross section and protective device specification Model ZEUS51E6K Protective earthing conductor 6mm² Min cross section (UL1015 10AWG) Input L, N 6mm²...
  • Page 17 Fig.4-1 Typical external isolating device installation No matter the UPS is connected to the mains power or not, the output of the UPS may be electrically live. The parts inside the unit may still have hazardous voltage after turning off the UPS. To make the UPS have no output, turn off the UPS, and cut off the mains power supply, wait the UPS shut down completely, finally cut off the battery connection.
  • Page 18 Note: Make sure that the input and output wires and the input and output terminals are connected tightly. It is requested to use the accessorial terminal splices which can be compacted on the wires tightly, to ensure the connection between the wires and the terminal block is reliable.

  • Page 19: Externalbattery Packconnectingprocedure

    4.5. External Battery Pack Connecting Procedure The nominal DC voltage of external battery pack is 192Vdc. To achieve longer backup time, it is possible to connect multi-battery packs, but the principle of "same voltage, same type" should be strictly followed. Loosen the screws to remove the Battery Input Connector Cover of Power Module.

  • Page 20: Epo Connection

    Connect the battery cable to the Battery Pack. 4.6. EPO Connection EPO (Emergency power off): when the emergency occurs, such as the failure of load, the UPS can cut off the output at once by operating the EPO port manually. ：...

  • Page 21: Operation

    5. Operation 5.1. Display Panel 5.2. Button functions Button Operation Description Press this button to turn on UPS. In line mode, ECO mode, or converter mode, press the “ON” button for 5 seconds to activate the battery test. Press this button to turn off UPS.* Press this button for 5 seconds to get into setting mode while in bypass mode, or standby mode.

  • Page 22: Lcd Operation

    5.3. LCD Operation Operation mode Description LCD display Line mode Utility will provide energy to loads. It will also charge the battery at the same time. Battery mode The unit will provide output power from battery. ECO mode When the input voltage is within voltage regulation range, UPS will bypass voltage to output for energy saving.
  • Page 23 Bypass mode When the input voltage is within bypass voltage range, UPS will bypass voltage to output. When input frequency is within Converter mode 40Hz to 70Hz, the UPS can be set at a constant output frequency, 50Hz or 60Hz. Utility will charge the battery and Standby mode no output voltage until switch on...
  • Page 24 Fault mode The UPS goes to fault mode because output is short. ： LCD displays 6 pages in total Left: AC INPUT(Voltage) 1(default) Right: OUTPUT(Voltage) V Left: INPUT(Frequency) Hz Right: OUTPUT(Frequency) Hz Left: W load percent(%) Right: OUTPUTXXX W...
  • Page 25 Left: VA load percentage(%) Right: OUTPUTXXX VA Left: Battery capacity percentage(%) Right: Battery voltage(v) Left: Backup Time(Min) Right: Battery voltage(v)
  • Page 26 LCD SETTING CONFIGURATION There are 22 UPS settings that can be configured by the user. 1、Press and hold the “ENTER” button for 5 seconds to activate the setting mode. The first configuration parameter will be displayed on the LCD screen. Note: The manual settings programming mode can ONLY be invoked while UPS is in Bypass mode or Standby mode.
  • Page 27 0%: ECO mode disabled. When selected, ECO mode ECO mode is not allowed(default) 10%: ECO mode enabled. When selected, ECO mode is activated when the input voltage is within +/-10% of setting output voltage 15%: ECO mode enabled. When selected, ECO mode is activated when the input voltage is within +/-15% of setting output voltage...
  • Page 28 You may set the number of battery package in Number**** 07 setting as [0bP]~ [AbP] [1bP] is the default setting for long-run model Reserved Reserved DIS: Disabled the buzzer. When Buzzer selected, buzzer will be silent, but it will beep when alarm or fault occurs. ENA: Enabled the buzzer.
  • Page 29 ENA: Ambient temperature warning Ambient enabled. (default) temperatur DIS: Ambient temperature warning e warning disabled. ENA: DC start enabled. If selected, UPS DC start can be switched on when DC voltage is available. Utility power is not essential. (default) DIS: DC start disabled. If selected, UPS can’t be switched on when only DC voltage is available.
  • Page 30 ENA: Short circuit restart enabled. If Short selected, UPS will auto restart after short circuit circuit fault. restart DIS: Short circuit restart disabled. If selected, UPS will not auto restart after short circuit fault. (default) Left parameter: Set the acceptable low Bypass voltage for bypass.
  • Page 31 Set the automatic battery tests period. Automatic Setting range is from 0 to 45days and the battery default value is 7days. tests period 0~ 999: Set the maximum discharge time Battery from 0 to 999minutes.UPS will shut down maximum to protect battery after discharge time discharge arrives.

  • Page 32: Special Function

    **) When operating in Converter Mode, the frequency of output should be always 50Hz or 60Hz, but load capacity will be derated by 40%. *) This function would be set as 0% when Converter Mode is enabled. **) UPS has no bypass when Converter Mode is enabled. ***) ROO (Remote On/Off): If ROO is enabled, UPS can be turn on/off by the ROO port.

  • Page 33: Converter Function

    6.2. Converter Function ： Brief introduction of Converter function In converter mode, the UPS would free run with fixed output frequency (50Hz or 60Hz). Once the mains power is loss or abnormal, the UPS would transfer to Battery mode and the load is supplied continuously. The great virtue is the output frequency is fixed, which is required by some very sensitive loads.
  • Page 34 The UPS will turn off the Battery is over Over Charge charger until the battery charged voltage is normal Charger fail The charge fails Consult dealer Check the loads and remove Over Load Over Load some non-critical loads; Check if some loads are failed. EPO connector is Check the EPO connector EPO active...

  • Page 35: Trouble Shooting According To Fault Indication

    7.2. Trouble Shooting According to Fault Indication Warning Problem Possible cause Remedy code Displayed Remove all the loads. Turn off the Output UPS. Check if UPS output and loads is Output short circuit Short short circuit. Ensure short circuit is removed before turning on again.

  • Page 36: Trouble Shooting In Else Cases

    7.3. Trouble Shooting in Else Cases Problem Possible cause Remedy Check the building wiring No indication, no warning and input cable; tone even though system No input voltage is connected to mains Check if the input breaker is power supply closed.

  • Page 37: Battery Maintenance

    8. Battery Maintenance Battery replacement should be performed by qualified personnel. ⚫ This UPS only requires minimal maintenance. The battery used for standard models are value regulated sealed lead-acid maintenance free battery. These models require minimal repairs. The only requirement is to charge the UPS regularly in order to maximize the expected life of the battery.

  • Page 38: Software Installation

    Software Installation Power Master+ management software provides a user-friendly interface for your power systems. The graphic user-interface is intuitive and displays essential power information at a glance. Please follow procedure below to install the software. Installation procedure: Download Power Master+ from the website: https://www.powermonitor.software/ Double-click the file and follow the installation steps.
