SERVICE MANUAL
Ver. 1.2 2008.07
• STR-KS1300 is the receiver section in HT-SF1300/SS1300.
This receiver incorporates Dolby* Digital and Pro
Logic Surround and the DTS** Digital Surround
System.
* Manufactured under license from Dolby
Laboratories.
Dolby, Pro Logic and the double-D symbol are
trademarks of Dolby Laboratories.
** Manufactured under license under U.S. Patent
#'s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;
6,487,535 & other U.S. and worldwide patents
issued & pending. DTS and DTS Digital
Surround are registered trademarks and the DTS
logos and Symbol are trademarks of DTS, Inc.
© 1996-2007 DTS, Inc. All Rights Reserved.
Amplifier section
1)
Power Output
Stereo mode (rated) 108 W + 108 W
(3 ohms at 1 kHz,
THD 1%)
Surround mode (reference)
RMS Output
(3 ohms at 1 kHz,
THD 10%)
2)
FRONT
: 143 W/ch
2)
CENTER
: 143 W
2)
SUR
: 143 W/ch
(1.5 ohms at 80 Hz,
THD 10%)
2)
SUBWOOFER
1)
Measured under the following conditions:
Area code
Power requirements
CEL, CEK
230 V AC, 50 Hz
2)
Reference power output for front, center, surround
speakers and sub woofer. Depending on the sound
field settings and the source, there may be no
sound output.
Inputs
Analog
Sensitivity: 1 V/50 kohms
Digital (Coaxial) Impedance: 75 ohms
Tone
Gain levels
±10 dB, 0.5 dB step
Reproduction frequency range:
28 – 20,000 Hz
Sony Corporation
9-889-016-03
2008G05-1
Audio&Video Business Group
©
2008.07
Published by Sony Techno Create Corporation
This receiver incorporates High-Definition
Multimedia Interface (HDMI™) technology.
HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
"x.v.Colour" and "x.v.Colour" logo are trademarks
of Sony Corporation.
"BRAVIA" and
Corporation.
SPECIFICATIONS
FM tuner section
Tuning range
Antenna
Antenna terminals
Intermediate frequency
AM tuner section
Tuning range
Models of area code CEL, CEK
With 9-kHz tuning scale:
Antenna
Intermediate frequency
: 285 W
General
Power requirements
Area code
CEL, CEK
Power output (DIGITAL MEDIA PORT)
DC OUT:
Power consumption
Area code
CEL, CEK
STR-KS1300
are trademarks of Sony
87.5 – 108.0 MHz
FM wire antenna
75 ohms, unbalanced
10.7 MHz
531 – 1,602 kHz
Loop antenna
450 kHz
Power requirements
230 V AC, 50/60 Hz
5 V, 700 mA
Power consumption
165 W
MULTI CHANNEL AV RECEIVER
AEP Model
UK Model
Power consumption (during standby mode)
0.3 W (When "CONTROL
FOR HDMI" in VIDEO
menu is set to "CTRL
OFF")
Dimensions (w/h/d) (Approx.)
430 × 66.5 × 335 mm
including projecting parts
and controls
Mass (Approx.)
3.6 kg
Design and specifications are subject to
change without notice.
About area codes
The area code of the receiver you purchased is
shown on the lower portion of the rear panel
(see the illustration below).
FRONT R
FRONT L
SUR R
SUR L
CENTER SUBWOOFER
Area code
Any differences in operation, according to the area
code, are clearly indicated in the text, for example,
"Models of area code AA only".
