Page 2: Please Read Carefully
They must be given to the installer and kept by the user. If you lose the manual, please refer to the website: www.poolex.fr The instructions and warnings contained in this manual must be read carefully and understood, as they provide important information on the safe handling and operation of the filter. -
Page 3: Table Of Contents
Troubleshooting and maintenance ......................... 10 Exploded views and spare parts lists ........................11 Guarantee ................................12 Packing Your TONICLINE filtration pump is made up of 1 box, the components of which are listed below: TONICLINE Pump Filtration pump Power supply cable with... -
Page 4: Safety Instructions
English Safety instructions These instructions contain general warning information to be used when installing pool and spa pumps. The specific function of the pump model should be consulted in the particular manual. Components such as the filtration system, pumps and heater must be positioned in such a way as to prevent them being used as a means of access to the pool by young children. -
Page 5: Principle Of Operation
English Principle of operation The filtration pump is the dynamic heart of a swimming pool's water treatment system, playing a crucial role in keeping the water clear and healthy. Its operating principle revolves around the constant circulation of water through the filtration system. The first step in this process is to draw water from the pool through the skimmer and the bottom drain. -
Page 6: Installation
English Installation Preamble Before starting installation, check that your equipment is compatible with each other (flow rates and working pressure) and that it is sized for the volume of water to be treated. ■■· · · · 11 111111m m Power Height (m) Dimension connections... -
Page 7: Installation Steps
English Installation steps Hydraulics - Piping 1. Install the pump as close to the pool as possible, preferably in a dry, well-ventilated area away from direct sunlight. Protect the pump from excessive COUDE moisture. 2. Position the pump as close as possible to the water source so that the suction pipe is short, straight and Ha�teur vertlcale <... -
Page 8: Commissioning
Socket European Type “F”... -
Page 9: Periodic Maintenance
Limits of use TONICLINE filtration pumps are designed for and compatible with swimming pools equipped with a salt chlorinator type water treatment system. Maximum permissible values are 9000 ppm (9 g/1). The maximum water temperature for use is SQQC. -
Page 10: Troubleshooting And Maintenance
English Troubleshooting and maintenance Description of the problem Possible causes 1. Switch or circuit breaker disconnected in "off" position. 2. Fuses blown or thermal protection tripped. 3. Motor shaft jammed. Engine won't start 4. Burnt motor windings. 5. Faulty starting switch inside the single-phase motor. 6. -
Page 11: Exploded Views And Spare Parts Lists
English Exploded view and spare parts for the pump 1 1041043 Transparent lid 1111008 Pump flange 2 2021088 O-ring for cover 1021014 Clamping ring on pump body 3 1111076 Basket 15 42059059919 PF-TNC075 motor (220V/50Hz) 4 89280105 Union 1.5" 15 42059059920 PF-TNClO0 motor (220V/50Hz) 5 89021307 Drain plug with O-ring 15 42059059921 PF-TNC150 motor (220V/50Hz) 6 1111006 Pump body... -
Page 12: Guarantee
English Guarantee Poolstar guarantees the original owner against material and manufacturing defects in the TONICLINE filtration pump for a period of three (3) years and seals/O-rings/capacitors for one (1) year, excluding wearing parts. The guarantee comes into effect on the date of the first invoice and on presentation of the purchase invoice.
