- Page 1 Belong Assembly Instructions Monitor Arm Single Monitor Arm Dual Monitor Arms Single Monitor Arm Single Monitor Arm Dual Monitor Arm For assembly assistance, visit haworth.com, call 800 426 8562, or email support@haworth.com...
- Page 2 Belong Assembly Instructions Tools Required 4mm Hex Wrench (Mounted to Arm) (S412) M4 - 10mm Spacer (S411) M4 - 18mm Pan Head Screw S411 S412 Grommet Mount Base Standard C Clamp Dual Adaptor Bracket Customer Service: 800 426 8562 E.C.O. No 500000077628...
- Page 3 Belong Assembly Instructions (A) Monitor Arm (Upper) - Qty. 1 (C) Monitor Arm (Lower) - Qty. 1 (D) Magnetic Cover - Qty. 4 (B) Monitor Mounting Pad - Qty. 1 (G) Dual Base Mount Adaptor - Qty. 1 (S411) Pan Head Screw - Qty. 4 (S411) Spacer - Qty.
- Page 4 Belong Assembly Instructions BOLT THROUGH CLAMP BASE OPTION Insert bolt through bracket (E2) and into base (E) (S408) M12 X 60mm Button Head Grommet Hole Specs Average Power Cable Diameter 0.31in Hole Size (in) Aprox # of cables Max Hole Size 3.0in...
- Page 5 Belong Assembly Instructions CLAMP BASE OPTION Remove cover (E2) Locate base (E) and insert clamp brackets (E3) TIGHTEN 4mm Hex Wrench (Mounted to Arm) Install cover (E2) Customer Service: 800 426 8562 E.C.O. No 500000077628 Part No 6100-0320 Rev 1...
- Page 6 Belong Assembly Instructions FOR SINGLE AND DUAL POST OPTION Turn knob on base (E) to UNLOCK position then insert lower arm (C) Single Monitor Arm Single Monitor Arm Dual Monitor Arm SINGLE ARM ASSEMBLY DUAL ARM ASSEMBLY NOTE: Make sure icon symbols face towards user when installed.
- Page 7 Belong Assembly Instructions CLAMP BASE OPTION Install upper arm (A) Install mounting pad (B) to monitor Install monitor to arm (A) and lock (B2) NOTE: Spaces (S412) are S411 S412 available only if needed. S411 (S412) (S411) M4 - 10mm Spacer...
- Page 8 Belong Assembly Instructions Route cords (J) throught cable managers (H) REMOVE INSTALL Customer Service: 800 426 8562 E.C.O. No 500000077628 Part No 6100-0320 Rev 1 Page 8 of 9...
- Page 9 Belong Assembly Instructions Adjust arm (A) tension REMOVE HEX TOOL ADJUST 11kg 4mm Hex Wrench (Mounted to Arm) ADJUST Adjust monitor tilt - Front to Back. Customer Service: 800 426 8562 E.C.O. No 500000077628 Part No 6100-0320 Rev 1 Page 9 of 9...
