JMC Elite 801 Series Installation And Operation Instruction Manual

Clamp less headset component upper cord pigtail assy only

Advertisement

JMC Elite 801 Series Clamp-
Less Headset Component Upper-
Cord Pigtail Assy Only
#HSCP-UC25
Installation and
Operation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elite 801 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for JMC Elite 801 Series

  • Page 1 JMC Elite 801 Series Clamp- Less Headset Component Upper- Cord Pigtail Assy Only #HSCP-UC25 Installation and Operation Instructions...
  • Page 2: Installation

    Component Upper Cord Pigtail Assy ONLY # HSCP-UC25 Use this alternate component pigtail assembly when moving an existing JMC clamp-on headset to a type of helmet that will not accept the older style clamp or older integrated style socket connection assembly.
  • Page 3 3. Drill the hole from the outside, using a small hand drill and it is recommended to drill the hole to 1/8” size first, before stepping up to the 5/32” drill bit. 4. Using the included #8-32X1/2” socket screw, washer, clamp assembly and #8-32 nut, tighten assembly into place using a 3/32”...
  • Page 4 5. Position the boom-mike assembly on the inside bottom right portion of the helmet as shown, mark position, then secure using the pre-gummed Velcro pad. 6. Peel the backing off the large Velcro pads and place them into the bottom of each speaker pocket indent for both left and right-side styrene pads as shown.
  • Page 5 7. Now place each speaker onto the Velcro pad for both sides. 8. Reinstall both left and right-side styrene cheek-pads and while sliding them back into place, plug both speakers and the microphone into the main wiring harness of the headset. Use the supplied wooden tool to slide each wire under the main neck-roll and cheek pad interior padding, out of site.
  • Page 6: Operation

    9. Now reinstall both left and right-side interior padding pieces and secure to complete the installation. Operation 1. Plug in the LOWER-Section Z-Series hook-up cord that corresponds to your specific motorcycle audio system and test all functions. (Z-series lower hook-up cord chart below) LOWER SECTION HOOK-UP CORDS Choose "Z"...
  • Page 7: Two-Year Limited Warranty

    HONDA® AUDIO SYSTEMS HC-ZB - 1980–2017 w/5-pin system HC-ZC - 1980–2017 w/5-pin system HC-ZB-S - 1980–2017 5-pin system w/integrated aux speaker jack HARLEY® AUDIO SYSTEMS HC-ZYH - 2014–2023 w/7-pin system HC-ZHD - 1998–2013 w/7-pin system HC-ZHD-S - 1998–2023 7-pin system w/integrated aux spkr jack HC-ZC - 1989–1997 w/5-pin system J&M AUDIO SYSTEMS HC-ZJM - 1999–2023 w/6-pin system...
  • Page 8: Warranty Registration Form

    WARRANTY AND REPAIR INFORMATION TWO YEAR LIMITED WARRANTY In order to facilitate the servicing of this warranty, the Warranty Registration Form should be filled out and returned within 10 days of the date of purchase. However, return of the Warranty Registration Form is not a precondition of this warranty, and this Warranty will be observed by J&M CORPORATION whether or not the Warranty Registration Form is returned, on the condition that other satisfactory evidence of the date of the original purchase is provided to J&M CORPORATION.
