- Page 1 JMC Elite 801 Series Clamp- Less Helmet Headset for Open- Face or Flip-Front Style Helmets #HS-ECLS801-UNV-XHO Installation and Operation Instructions...
-
Page 2: Installation
P R O D U C T D E S C R I P T I O N JMC Elite 801 Series Clamp-Less Helmet Headset for most Open- Face or Flip-Front Modular Style Helmets # HS-ECLS801-UNV-XHO J&Ms elite 801 series helmet headset ,,,, THE VERY BEST performing helmet headset available! •... - Page 3 2. Hold the main headset cable with mounting clip attached in place on the inside bottom left portion of the helmet, using the photo below as a guide, and mark the position for the 5/32” hole to be drilled in the bottom edge shell of the helmet.
- Page 4 4. Using the included #8-32X1/2” socket screw, washer, clamp assembly and #8-32 nut, tighten assembly into place using a 3/32” allen tool. 5. Position the boom-mike assembly on the inside bottom right portion of the helmet as shown, mark position, then secure using the pre-gummed Velcro pad.
- Page 5 6. Peel the backing off the large Velcro pads and place them into the bottom of each speaker pocket indent for both left and right-side styrene pads as shown. 7. Now place each speaker onto the Velcro pad for both sides.
-
Page 6: Operation
8. Reinstall both left and right-side styrene cheek-pads and while sliding them back into place, plug both speakers and the microphone into the main wiring harness of the headset. Use the supplied wooden tool to slide each wire under the main neck-roll and cheek pad interior padding, out of site. 9. -
Page 7: Two-Year Limited Warranty
LOWER SECTION HOOK-UP CORDS Choose "Z" series lower-section hook-up cord for proper connection to your specific audio system. HONDA® AUDIO SYSTEMS HC-ZB - 1980–2017 w/5-pin system HC-ZC - 1980–2017 w/5-pin system HC-ZB-S - 1980–2017 5-pin system w/integrated aux speaker jack HARLEY®... -
Page 8: Warranty Registration Form
WARRANTY AND REPAIR INFORMATION TWO YEAR LIMITED WARRANTY In order to facilitate the servicing of this warranty, the Warranty Registration Form should be filled out and returned within 10 days of the date of purchase. However, return of the Warranty Registration Form is not a precondition of this warranty, and this Warranty will be observed by J&M CORPORATION whether or not the Warranty Registration Form is returned, on the condition that other satisfactory evidence of the date of the original purchase is provided to J&M CORPORATION.
