MDM SEQUENCE Colossus 750 DC Plus Installation And Operation Manual

®
XXXXSEQXX
S/N: XXXX-
XXXXXX
PUMP TYPE: ESCC (END SUCTION CLOSE-COUPLED)
MOTOR: BLDC, VARIABLE SPEED, 3150 RPM MAX
INLET: 2" FNPT
DISCHARGE: 1-1/2" FNPT
MATERIAL: 40% GLASS-FILLED POLYPROPYLENE
WITH NORYL
HARDWARE: 316 STAINLESS STEEL
DISCHARGE: 1-1/2" FNPT
MAX
SUCTION DISCHARGE
FLOW
2" FNPT 1.5" FNPT 120 GPM
@ 100%
Read this manual completely before you install or operate your new pump. This is an external "out-of-pond" pump.
It is not submersible. Do not allow this pump to become submerged. Never run dry. Maximum case pressure - 25 PSI.
PROUDLY MADE
IN THE USA
INSTALLATION AND OPERATIONS MANUAL
IMPELLER
®
MAX MAX MAX
HEAD POWER CURRENT
38.5 FEET 723 WATTS 6.3 @ 100%
@ 100%
Reliable. Efficient.
Colossus 750 DC Plus
®
@ MOTOR MOTOR
VOLTS HP ENCLOSURE
115 .97 BLDC / TEFC
FILL IN FOR FUTURE REFERENCE:
MODEL: ______________________________
SERIAL NUMBER: _______________________
DATE PURCHASED: ______________________
TO REGISTER YOUR PUMP
SCAN THIS QR CODE OR VISIT
MDMINC.COM/PUMP-REGISTRATION
PUMP CASE MECHANICAL
IMPELLER
MATERIAL SEAL
40% GLASS 316 SS CARBON
FILLED PP / GRAPHITE / COLOSSUS,
VITON CERAMIC, VITON
© MDM INCORPORATED
WWW.MDMINC.COM
FASTENERS
750. 316 SS
NORYL
®
P.1
