- Page 1 Translation of the Original Operating Manual Drill Chuck SUPRA-SK Store for reference Version 1.0 • 24.07.2024...
-
Page 3: Table Of Contents
Disassembly/assembly of the drill chuck.......... 13 With spindle stop.................. 13 Without spindle stop ................ 17 Operation of the drill chuck .............. 21 Maintenance .................... 24 Cleaning .................... 24 Troubleshooting .................. 24 Disposal .................... 24 Notes ...................... 25 Drill Chuck SUPRA-SK... -
Page 4: About This Operating Manual
– even in part – as well as use and/or communication of the content without the permission of RÖHM are prohibited (except for internal pur- poses). Infringements will lead to claims for compensation. We reserve the right to assert further claims. 4 / 28 Drill Chuck SUPRA-SK... -
Page 5: Warranty And Liability
▪ if the operator or third parties carry out modifications or repairs to the services / products without prior permission of RÖHM. Excepted from this are damage or defects which have occurred and which were demonstrably not due to these modifications or repairs. Drill Chuck SUPRA-SK 5 / 28... -
Page 6: Conventions Of Presentation
Ø Marks an intermediate result of an operating instruction ü End result of an operating instruction List ▪ Marks elements of a list Marks comments within a list Contains useful information or further information. 6 / 28 Drill Chuck SUPRA-SK... -
Page 7: Display Of Safety And Warning Instructions
Ø List of all measures which must be taken to prevent con- sequences. NOTICE Indicates a possible danger which may lead to damage to property if not avoided. Ø List of all measures which must be taken to prevent con- sequences. Drill Chuck SUPRA-SK 7 / 28... -
Page 8: Safety
▪ clamping of rotating workpieces with a great imbalance; ▪ Assembly of the drill chuck and accessory parts with incorrect torque (see Disassembly/assembly of the drill chuck [} 13]). ▪ Operation with modifications not approved by the manufacturer. 8 / 28 Drill Chuck SUPRA-SK... -
Page 9: Obligations Of The Operator
Wear safety goggles Wear ear protection Work on and with the drill chuck may only be carried out by qualified oper- ating and specialist personnel (see Qualification of Operating and Spe- cialist Personnel [} 9]). Drill Chuck SUPRA-SK 9 / 28... -
Page 10: General Dangers
2. Call a doctor. Ø Do not make any changes to the accident site. 3. Administer first aid. Ø Stop any bleeding. Ø Cool burns. 4. Report all accidents to a superior. 10 / 28 Drill Chuck SUPRA-SK... -
Page 11: Product Description
Product Description About this drill chuck The drill chuck SUPRA-SK is a manually operated drill chuck for use with hand-held corded drills and cordless drills with and without a spindle stop. The drill chuck SUPRA-SK is also suitable for anti-clockwise rotation with radial locking. -
Page 12: Technical Specifications
Pollution of the machine’s surroundings caused by the machine itself is per- mitted. However, perfect operation of the drill chuck must be ensured and checked regularly. In addition, the drill chuck must be cleaned in case be- comes excessively dirty. 12 / 28 Drill Chuck SUPRA-SK... -
Page 13: Disassembly/Assembly Of The Drill Chuck
1. Grasp the drill chuck by the holding ring and unscrew it from the ma- chine spindle (right-hand thread) (B, C). 2. You can insert a pin into the hole in the holding ring for added force (B). ü drill chuck disassembled. Drill Chuck SUPRA-SK 13 / 28... - Page 14 4 | Disassembly/assembly of the drill chuck Fig. 1: Disassembling a drill chuck (with spindle stop) 14 / 28 Drill Chuck SUPRA-SK...
- Page 15 2. Screw/place the drill chuck onto the machine spindle (F). 3. You can insert a pin into the hole in the holding ring for added force (G). ü drill chuck mounted. Drill Chuck SUPRA-SK 15 / 28...
- Page 16 4 | Disassembly/assembly of the drill chuck Fig. 2: Mounting a drill chuck (with spindle stop) 16 / 28 Drill Chuck SUPRA-SK...
-
Page 17: Without Spindle Stop
2. Grasp the drill chuck by the holding ring and unscrew it from the ma- chine spindle (right-hand thread) (A, C). 3. You can insert a pin into the hole in the holding ring for added force (B). ü drill chuck disassembled. Drill Chuck SUPRA-SK 17 / 28... - Page 18 4 | Disassembly/assembly of the drill chuck Fig. 3: Disassembling a drill chuck (without spindle stop) 18 / 28 Drill Chuck SUPRA-SK...
- Page 19 2. Screw/place the drill chuck onto the machine spindle (F). 3. Hold the machine spindle with a spanner (F,G). 4. You can insert a pin into the hole in the holding ring for added force (G). ü drill chuck mounted. Drill Chuck SUPRA-SK 19 / 28...
- Page 20 4 | Disassembly/assembly of the drill chuck Fig. 4: Mounting a drill chuck (without spindle stop) 20 / 28 Drill Chuck SUPRA-SK...
-
Page 21: Operation Of The Drill Chuck
4. Hold the holding ring and tighten the tool by turning the cone sleeve. Ø On machines with a spindle stop, you do not need to hold the hold- ing ring. 5. Turn the retaining ring in the "LOCK" direction to engage the clamp lock. Drill Chuck SUPRA-SK 21 / 28... - Page 22 To avoid unintentionally high further tensioning, the following is re- commended: Ø Do not use tools with an uneven or blunt cutting edge. Ø Regularly open the drill chuck and re-tighten. 22 / 28 Drill Chuck SUPRA-SK...
- Page 23 Ensure central clamping of the tool and true running. If the tool is not clamped centrally, the clamping position must be corrected. In case of un- true running, the tool must not be used. Drill Chuck SUPRA-SK 23 / 28...
-
Page 24: Maintenance
Metals must be recycled. Disposal must be carried out in accordance with the applicable regulations and local regulations. ▪ Plastics They must be disposed of in accordance with the valid regulations and the applicable local provisions. Obtain relevant information from the authorities. 24 / 28 Drill Chuck SUPRA-SK... -
Page 25: Notes
Notes | 10 Notes Drill Chuck SUPRA-SK 25 / 28... - Page 26 10 | Notes 26 / 28 Drill Chuck SUPRA-SK...
- Page 27 Notes | 10 Drill Chuck SUPRA-SK 27 / 28...
- Page 28 10 | Notes 28 / 28 Drill Chuck SUPRA-SK...
