- Page 1 Mangar Airflo Plus Instruction & Safety Manual Please read this manual before operation, for maintenance instructions and safe usage The enabling power of applied knowledge...
-
Page 2: Table Of Contents
Mangar Airflo Plus, Instruction & Safety Manual Introduction The Airfl o Plus by Mangar International, is a low pressure air compressor, which has been designed for use with Mangar International pneumatic lifting equipment. WARNINGS • BE SURE that you have read and understood these instructions and those provided with any other mangar international product, before operating the equipment. -
Page 3: Standard Package Contents
Standard Package Contents - Fig 1 1 x Airfl o Plus compressor fi tted with two 12v - 2.3Ah batteries (A) 1 x Battery charger (B) 1 x User instructions Battery Status Indicator - Fig 2 Before use, check that the battery is suffi ciently charged. If the battery is fully charged, the indicator light (A) will show a steady Green light. -
Page 4: Battery Charging
Mangar Airflo Plus, Instruction & Safety Manual Battery Charging - Fig 3 The Airfl o Plus is fi tted with a quick release battery pack. The batteries can either be re-charged whilst in the Airfl o Plus or easily removed and re-charged in the optional charging cradle. -
Page 5: Auto' Function
‘Auto’ Function - Fig 5 The ‘Auto’ function is designed for use with the pneumatic 4-Way hand control - fi g. 6 To switch on, press and hold the ‘Power’ button (A) until the light (B) comes on. The light will stay on while the ‘Auto’... -
Page 6: Cleaning & Storage
Mangar Airflo Plus, Instruction & Safety Manual Cleaning • Unplug the Airfl o Plus from the battery charger. Clean the external surfaces using a damp cloth and allow to dry thoroughly before reconnecting to the battery charger. Do not allow moisture to enter any part of the compressor. -
Page 7: Trouble Shooting Guide
Trouble Shooting Guide Compressor does not run when Compressor keeps stopping when the 4 way hand control buttons are trying to infl ate the lifting aid. pressed. Check that there are no kinks in the Ensure that the ‘Auto Function’ has air hose. -
Page 8: Symbols Used On Airfl O Plus And Charger
Mangar Airflo Plus, Instruction & Safety Manual Symbols used on Airfl o Plus and Charger Labels Attention consult instructions Class ll Double Insulated equipment Type B equipment (protection against electric shock) Danferous Voltage Alternating current (AC) Duty Cycle Fuse (with rating) -
Page 9: Symbols Used On Packaging
Symbols used on Packaging Keep packaging dry Recycle packaging Handle with care Do not dispose of in household waste Max/Min storage temperature Max/Min humidity when Net & gross weights transporting in pressurised aircraft hold Stack no more than fi ve high Max/Min pressure when transporting in pressurised aircraft hold... - Page 10 Mangar Airflo Plus, Instruction & Safety Manual 08 9351 7500 info@unicarehealth.com.au www.unicarehealth.com.au...
- Page 11 08 9351 7500 info@unicarehealth.com.au www.unicarehealth.com.au...
- Page 12 PO Box 82 Bentley WA 6982 Authorised Distributor T 08 9351 7500 F 08 9350 5299 info@unicarehealth.com.au www.unicarehealth.com.au...
