  • Page 1 Unicare Xcel Floorline Nursing Bed USER MANUAL Low Profile Bed Please read this user manual before using the Xcel Floorline Nursing Bed. XcelFloorlineManual.indd 1 XcelFloorlineManual.indd 1 10/11/2022 1:08:28 PM 10/11/2022 1:08:28 PM...
  • Page 2: Table Of Contents

    Contents General Information 2 - 3 Standard Symbols and Warning Labels Intended Use Safety Precautions Technical Specification Low Bed Equipment Assembly 7 - 8 Unpacking the Bed Equipment Operation Operating the Bed Maintenance & Cleaning 14 - 18 Maintenance Schedule Detecting Wear and Damage Lubrication Replacing the electric actuator...
  • Page 3: General Information

    1.0 General Information 1.1 Standard Symbols and Warning Labels 1.2 Intended Use The Floorline Bed suits institutional healthcare environments, i.e. nursing Warnings homes, rehabilitation care, assisted living. Signal words with symbols are used in this manual to highlight hazards or unsafe practices which could result in personal injury or property damage.
  • Page 4: Performing Maintenance

    1.3.3 Performing Maintenance 1.3.5 Disposal WARNING WARNING ONLY qualified personnel should carry out the bed maintenance. This product has been supplied from an environmentally aware manufacturer. DO NOT attempt to open the pre-sealed actuator or obtain local service, for Where backup battery is used, DO NOT dispose of batteries in normal it will VOID the warranty and might result in damage.
  • Page 5: Technical Specification

    3.0 Equipment Assembly 2.0 Technical Specification 2.1 Low Bed 3.1 Unpacking the Bed WARNING Single Standard King Single Small Double Bariatric Bariatric To avoid injury, DO NOT attempt to remove the bed from the carton without assistance Bed Height 110mm - 735mm I.
  • Page 6: Assembling The Bed

    3.2.2 Assembling the Footboard frame to the Bed IMPORTANT Store the repackaged bed in a dry area. Do not place other objects on top of the repackaged bed. Unless the bed is to be used immediately, retain boxes, containers, and packing materials for use in storing until use of bed is required.
  • Page 7: Equipment Operation

    3.2.4 Installing the mattress retaining system 4.1.2 Extending the Bed The built-in extension system accomodates taller patients. The 2000mm bed platform can be extended by up to 200mm. The steps are as follows. Loosen the two black knobs located on the underside of the bedframe securing the footboard frame.
  • Page 8 4.1.3 Using the Controller 4.1.4 Leveling the Leg Rest WARNING The end foot section can be adjusted manually to further alter the kneebreak angle. Whist operating the bed, the rear castors of the bed shall be locked to ensure stability during bed adjustments. Grasp the edge of the bed platform end section.
  • Page 9: Maintenance & Cleaning

    5.0 Maintenance & Cleaning 5.1 Maintenance Schedule 5.2 Detecting Wear and Damage When examining the equipment, attention should be paid to all stressed parts, such as Items for Inspection Initially Health Care Facility In-Home Inspect castors and any pivot points cracking, deformation or deterioration. Replace any defective Inspect &...
  • Page 10: Replacing The Electric Actuator

    5.4 Replacing the Electric Actuator 5.4.1 Replacing the Electric Actuators controlling the back and footrest 5.4.2 Replacing the Electric Actuators controlling the bed height WARNING Whist operating the bed, the rear castors of the bed shall be locked to ensure stability during bed adjustments.
  • Page 11: Accessories

    6.0 Accessories 5.6 Replacing Castors 6.1 Timber Side Panels Timber side panel on each side of the bed covers the edge of the bed platform. To install the timber panel: Align the mounting holes of the panel to the ones on the bed frame. Secure the panel with bolts from the bed frame side.
  • Page 12: Side Rail Operation

    6.3 Bumper Bar 6.2.1 Side Rail Installation To install the bumper bar: Align the bumper bar with the mounting holes on the castor legs. Compress the bumper bar lengthwise and fit the ends of the bumper bar into the mounting holes. Release the bumper bar.
  • Page 13: Backup Battery Pack

    6.5 Backup Battery Pack 6.7 Bed Transfer Trolley The battery pack will provide power backup in the event The Bed Transfer Trolley system allows the bed to be easily transported through spatially of mains failure. The pack is equipped with a low battery restricted areas such as doorways.
  • Page 14: Troubleshooting Guide

    7.0 Troubleshooting Guide Appendix 1 - Risk Assessment Symptoms Faults Solutions Hazard Likelihood of Severity of Harm Control Measures and Suggested Actions Harm (High/Medi- (High/Medium/Low) um/Low) Bed idle when hand Power not connected or damaged. Ensure power cable properly connected to the electri- Entrapment High The bed and side rails have been designed in accordance...
  • Page 15: Appendix 2 - Service Record

    Appendix 2 - Service Record Date Performed By Condition Report Did you know? Regular servicing & maintenance is the key to extending the life of your bed. Call us on 1800 656 654 to discuss your needs XcelFloorlineManual.indd 26-27 XcelFloorlineManual.indd 26-27 10/11/2022 1:08:31 PM 10/11/2022 1:08:31 PM...
  • Page 16 Visit our showroom Scan for directions to our showroom Call, email or visit us online unicare.au info@unicare.au 25-29 Alexandra Place, 1800 656 654 Bentley, WA 6102 ISO 9001:2021 Certified Registered Provider XcelFloorlineManual.indd 28 XcelFloorlineManual.indd 28 10/11/2022 1:08:31 PM 10/11/2022 1:08:31 PM...
