Sony XR-1300R Service Manual
Hide thumbs
Also See for XR-1300R:
- Operating instructions manual (80 pages) ,
- Installation/connections (4 pages) ,
- Installation/connections (4 pages)
Table of Contents
Advertisement
Quick Links
XR-1300R/C2300R
SERVICE MANUAL
Cassette player section
Tape track
Wow and flutter
Frequency response
Signal-to-noise ratio
Tuner section
FM
Tuning range
Aerial terminal
Intermediate frequency
Usable sensitivity
Selectivity
Signal-to-noise ratio
Harmonic distortion at 1 kHz
Separation
Frequency response
MW/LW
Tuning range
Aerial terminal
Intermediate frequency
Sensitivity
Power amplifier section
Outputs
Speaker impedance
Maximum power output 45 W × 4 (at 4 ohms)
MICROFILM
Photo: XR-C2300R
SPECIFICATIONS
General
4-track 2-channel stereo
Outputs
0.13 % (WRMS)
30 – 15,000 Hz
55 dB
Tone controls
Power requirements
87.5 – 108.0 MHz
External aerial connector
Dimensions
10.7 MHz
9 dBf
Mounting dimensions
75 dB at 400 kHz
65 dB (stereo),
Mass
68 dB (mono)
Supplied accessories
0.7 % (stereo),
0.4 % (mono)
35 dB at 1 kHz
30 – 15,000 Hz
Design and specifications are subject to change
without notice.
MW: 531 – 1,602 kHz
LW: 153 – 279 kHz
External aerial connector
10.7 MHz/450 kHz
MW: 30 µV
LW: 50 µV
Speaker outputs
(sure seal connectors)
4 – 8 ohms
FM/MW/LW CASSETTE CAR STEREO
Model Name Using Similar Mechanism
Tape Transport Mechanism Type
Audio output (XR-C2300R)
Power aerial relay control
lead
Power amplifier control
lead
Bass ±8 dB at 100 Hz
Treble ±8 dB at 10 kHz
12 V DC car battery
(negative earth)
Approx. 188 × 58 × 182 mm
(w/h/d)
Approx. 182 × 53 × 163 mm
(w/h/d)
Approx. 1.2 kg
Parts for installation and
connections (1 set)
Front panel case (1)
AEP Model
UK Model
NEW
MG-36SZ10-32
Advertisement
Table of Contents
Related Manuals for Sony XR-1300R
Summary of Contents for Sony XR-1300R
- Page 1 XR-1300R/C2300R SERVICE MANUAL AEP Model UK Model Photo: XR-C2300R Model Name Using Similar Mechanism Tape Transport Mechanism Type MG-36SZ10-32 SPECIFICATIONS Cassette player section General Audio output (XR-C2300R) Tape track 4-track 2-channel stereo Outputs Wow and flutter 0.13 % (WRMS) Power aerial relay control Frequency response 30 –...
-
Page 2: Table Of Contents
GENERAL • Do not touch the soldering iron on the same conductor of the Location of Controls (XR-1300R) ........3 circuit board (within 3 times). Setting the Clock ............. 3 • Be careful not to apply force on the conductor when soldering Locations of Controls (XR-C2300R) ...... -
Page 3: General
SECTION 1 This section is extracted from instruction manual. GENERAL (XR-1300R) Location of controls Setting the clock The clock uses a 24-hour digital indication. Example: To set the clock to 10:08 Press (MENU), then press either side of (PRST) repeatedly until “CLOCK”... -
Page 4: Locations Of Controls (Xr-C2300R)
(XR-C2300R) -
Page 5: Installation
Installation Instalación Montering Instalação Precautions Precauciones Att observera Precauções •Choose the installation location carefully so that •Elija cuidadosamente el lugar de montaje de •Var noga när du väljer var i bilen du monterar •Escolha com cuidado um local apropriado para the unit will not interfere with normal driving forma que la unidad no interfiera las funciones bilstereon, så... -
Page 6: Connections
Connections Conexiones Anslutning Ligações Cautions Precauciones Att observera Advertência • This unit is designed for negative earth 12 V DC • Esta unidad ha sido diseñada para alimentarse •Denna bilstereo är endast avsedd för anslutning •Este aparelho foi projectado para funcionar operation only. - Page 7 Connection example XR-C2300R only Supplied with the XA-C30 Conexiones de ejemplo Sólo para XR-C2300R Suministrado con el XA-C30 Exempel på Kopplingsschema Medföljer XA-C30 endast XR-C2300R Fornecido com o XA-C30 Ligações de exemplo Apenas para o modelo XR-C2300R Source selector Supplied with the CD/MD changer Selector de fuente Suministrado con el cambiador CD/MD BUS AUDIO IN...
- Page 8 Conection diagram (XR-C2300R only) Caution Cautionary notice for handling the bracket 1. Diagrama de conexiones (sólo para XR-C2300R) Handle the bracket carefully to avoid injuring your fingers. Kopplingsschema (endast XR-C2300R) Precaución Diagrama de ligações (Apenas para o modelo XR-C2300R) Advertencia sobre la manipulación del soporte 1. Tenga mucho cuidado al manipular el soporte para evitar posibles Equipment used in illustrations (not supplied) lesiones en los dedos.
-
Page 9: Sub Panel
SECTION 2 DISASSEMBLY Note: Follow the disassembly procedure in the numerical order given. SUB PANEL 1 three claws 1 two claws 2 sub panel MECHANISM DECK (MG-36SZ10-32) 2 two screws 2 two screws (PTT2.6 × 6) (PTT2.6 × 6) 1 connector (CN350) 3 mechanism deck 1 connector... -
Page 10: Main Board
MAIN BOARD 3 two screws 2 two ground point screws (PTT2.6 × 6) 4 main board 3 screw (PTT2.6 × 6) 1 claw BRACKET (MD) 1 claw 1 claw 3 bracket (MD) 1 claw 2 four screws (B2.6 × 4) - Page 11 HEAT SINK 1 five screws (PTT2.6 × 10) 1 two screws (PTT2.6 × 10) (XR-C2300R) 2 heat sink MOTOR ASS’Y (CAPSTAN/REEL) (M901) 2 belt 3 belt 1 two screws (P2 × 2.5) 4 motor ass’y (capstan/reel) (M901) Note : When installing motor, adjust the screw and screw hole of motor.
-
Page 12: Mechanical Adjustments
SECTION 3 SECTION 4 MECHANICAL ADJUSTMENTS ELECTRICAL ADJUSTMENTS 1. Clean the following parts with a denatured-alcohol-moistened TEST MODE swab: This set have the test mode function. In the test mode, FM Auto playback head pinch roller Seek/Stop Level, FM RDS S-Meter adjustments and MW Auto rubber belt capstan Seek/Stop Level check can be performed easier than it in ordinary... -
Page 13: Tape Deck Section
Adjustment Location: PB head TAPE DECK SECTION 0 dB= 0.775 V 1. The adjustments should be performed in the order given in this service manual. 2. The adjustments should be performed for both L-CH and R-CH. adjustment Test Tape screws ... -
Page 14: Tuner Section
FM Stereo Separation Adjustment TUNER SECTION Setting: [TUNER] [SOURCE] (1300R) or (C2300R) button: FM 0 dB=1 µV FM RF signal level meter generator antenna jack (CN100) Cautions during repair 0.01 µ F When the tuner unit is defective, replace it by a new one be- 10 k Ω... - Page 15 FM RDS S-Meter Adjustment MW Auto Seek/Stop Level Adjustmant Setting: Make this adjustment after “FM Auto Seek/Stop Level Adjust- [TUNER] [SOURCE] (1300R) or (C2300R) button: FM ment”. Setting: [TUNER] [SOURCE] FM RF signal (1300R) or (C2300R) button: MW generator antenna jack (CN100) 0.01 µ...
- Page 16 Adjustment Location: Tape Speed Adjustment TU100 RV1 MW Auto Seek/Stop Level Adjustment RV2 FM Auto Seek/Stop Level Adjustment VR100 FM RDS S-Meter Adjustment CN901 RV4 FM Stereo Separation Adjustment...
-
Page 25: 5-8. Ic Pin Function Description
Tuner system power supply on/off control signal output terminal “H”: tuner power on — Power supply terminal (+5V) Not used (open) Bus on/off control signal output to the SONY bus interface (IC800) “L”: bus on BUSON Used for the XR-C2300R only Reset signal output to the SONY bus interface (IC800) “L”: reset... - Page 26 Key input terminal (A/D input) (S909 to S920) 2 (XR-1300R), 2 SHUF (XR-C2300R), 1 (XR-1300R), 1 REP (XR-C2300R), ENTER, MODE, DSPL PTY, SEEK +/– (XR-1300R), SEEK/AMS + > M – . m (XR-C2300R), KEYIN1 PRST +/– (XR-1300R), PRST DISC +/– (XR-C2300R), TUNER (XR-1300R),...
- Page 27 Pin No. Pin Name Description Battery detect signal input from the SONY bus interface (IC800) and battery detect circuit BU-IN “L” is input at low voltage IC800: Used for the XR-C2300R only ILL IN Not used Telephone muting signal input terminal At input of “H”, the signal is attenuated by –20 dB...
-
Page 28: General Section
SECTION 6 EXPLODED VIEWS NOTE: • Items marked “*” are not stocked since they • -XX and -X mean standardized parts, so they may have some difference from the original are seldom required for routine service. Some one. delay should be anticipated when ordering these items. -
Page 29: Front Panel Section
(2) FRONT PANEL SECTION not supplied (CONTROL board) LCD900 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 3-041-597-01 BUTTON (1-6) (1. 2. 3. 4. 5. 6) 3-041-582-01 BUTTON (EJECT) (Z) 3-041-594-01 BUTTON (D/M/E) (DSPL. MODE. ENTER) 3-029-327-01 SPRING (EJECT) * 63 3-041-591-01 PLATE (LCD), GROUND... -
Page 30: Mechanism Deck Section
(3) MECHANISM DECK SECTION (MG-36SZ10-32) supplied supplied HP901 supplied supplied M901 supplied S902 S903 supplied supplied S901 not supplied supplied not supplied not supplied supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark * 101 3-041-579-01 BRACKET (MD) 3-045-906-01 ADJUSTER SHIM (X) 3-045-943-01 MAIN BELT 3-045-952-01 +MACHINE SCREW M1.7X4... -
Page 31: Electrical Parts List
SECTION 7 CONTROL ELECTRICAL PARTS LIST NOTE: When indicating parts by reference • Due to standardization, replacements in the • Items marked “*” are not stocked since they number, please include the board. parts list may be different from the parts speci- are seldom required for routine service. - Page 32 CONTROL MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R926 1-208-449-61 RES, CHIP 3.3K 1/10W S909 1-771-882-21 SWITCH, TACTILE (WITH LED) (1300R: 2/C2300R: 2 SHUF) (AMBER) R927 1-208-453-61 RES, CHIP 4.7K 1/10W S909 1-771-609-11 SWITCH, TACT (WITH LED) R928 1-216-671-11 METAL CHIP 6.8K...
- Page 33 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C101 1-163-133-00 CERAMIC CHIP 470PF C220 1-104-760-11 CERAMIC CHIP 0.047uF C102 1-126-157-11 ELECT 10uF C221 1-164-004-11 CERAMIC CHIP 0.1uF C222 1-126-154-11 ELECT 47uF 6.3V C103 1-163-009-11 CERAMIC CHIP 0.001uF C300 1-163-009-11 CERAMIC CHIP...
- Page 34 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C510 1-104-942-11 ELECT D501 8-719-200-82 DIODE 11ES2-TA1B C511 1-109-982-11 CERAMIC CHIP D502 8-719-200-82 DIODE 11ES2-TA1B D503 8-719-200-82 DIODE 11ES2-TA1B C512 1-104-760-11 CERAMIC CHIP 0.047uF D504 8-719-200-82 DIODE 11ES2-TA1B C513 1-163-021-11 CERAMIC CHIP 0.01uF...
- Page 35 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < TRANSISTOR > 1-216-097-00 RES, CHIP 100K 1/10W 1-216-097-00 RES, CHIP 100K 1/10W 8-729-043-32 TRANSISTOR PDTA114EK-115 1-216-097-00 RES, CHIP 100K 1/10W 8-729-043-32 TRANSISTOR PDTA114EK-115 Q101 8-729-043-27 TRANSISTOR PDTC114EK-115 1-216-097-00 RES, CHIP 100K...
- Page 36 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R707 1-216-081-00 METAL CHIP 1/10W R311 1-216-073-00 METAL CHIP 1/10W R708 1-249-421-11 CARBON 2.2K 1/4W R312 1-247-807-31 CARBON 1/4W R709 1-216-097-00 RES, CHIP 100K 1/10W R400 1-216-065-00 RES, CHIP 4.7K 1/10W R710...
- Page 37 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark S903 1-771-927-11 SWITCH (LEAF) (TAPE DETECT) 3-868-293-31 MANUAL, INSTRUCTION (GERMAN) (C2300R: German) ************************************************************ 3-868-293-41 MANUAL, INSTRUCTION (ENGLISH, CZECH, ************** HARDWARE LIST POLISH, TURKISH, RUSSIAN) (C2300R: South European) ************** X-3378-453-1 CASE (PANEL) ASSY (for FRONT PANEL) 7-685-782-09 SCREW +PTT 2X5 (S) ************************************************************...
- Page 38 XR-1300R/C2300R Sony Corporation 9-870-024-11 2000A057524-1 Mobile Electronics Division Company Printed in Hungary C 2000. 1 Published by General Engineering Dept.
