- Page 1 Owner’s Manual Hip Thrust/ Glute Builder- Plate Loaded FL1844 Scan Here For Installation Video: Language: English OWNER’S MANUAL - FL1844...
-
Page 2: Table Of Contents
Table of Contents 1. Introduction 2. Important Safety Guidelines for Owners 3. FL1844 Components 4. Assembly Instructions 5. Assembly Guide 6. Daily Inspection 7. Weekly Inspection 8. Monthly Inspection 9. Warranty OWNER’S MANUAL - FL1844... -
Page 3: Introduction
1. Introduction This user manual is specific to your FL1844. This user manual contains important assembly, maintenance, and warranty information, which you should keep for reference. You should also read the entire Owner’s Manual, because it has additional important general information and instructions which you should follow. -
Page 4: Important Safety Guidelines For Owners
Whenever a weight can drop and hit a user, such as with an Olympic bench, We highly recommend that a helper or spotter be used. Do not place the equipment outdoors or on wet surfaces. OWNER’S MANUAL - FL1844... -
Page 5: Fl1844 Components
Dual sided safety catches and releases and support. mechanism for ease of use. Heavy reinforced padded waist harness Bottom dropout safety stop. provides optimal lifting application. Oversized angled foot platform to Extended lumbar support. accommodate users of all sizes. OWNER’S MANUAL - FL1844... -
Page 6: Assembly Instructions
4. Assembly Instructions Assembly of the FL1844 takes about 120 minutes to complete. If this is the first time you have assembled this type of equipment, plan on allowing more time. Be careful to open boxes and assemble components in the sequence presented in this manual. -
Page 7: Assembly Guide
5. Assembly Guide Step 1 Start with base frame. Step 2 Connect Back Bracket onto base frame. Connect bracket with (3) M10 Bolts with washer and nuts. Step 3 Connect Footplate Bracket with (2) M6 Bolts. OWNER’S MANUAL - FL1844... - Page 8 Connect footplate to foot- plate bracket with (2) M4 bolts and nuts. Last M4 bolt can bolt direct- ly to threaded hole on the bracket. Step 6 Connect Backpad to backrest frame using (4) M3 Bolts. OWNER’S MANUAL - FL1844...
- Page 9 Step 8 Connect both pivot handles together with connection beam and (4) M6 bolts. Step 9 Run weight bar through frame and secure with M2 bolt in the middle of the bar. OWNER’S MANUAL - FL1844...
- Page 10 5. Assembly Guide Step 10 Connect seat belt to backrest frame using (2) M8 bolts with washer and nuts. Completed Product OWNER’S MANUAL - FL1844...
-
Page 11: Daily Inspection
For chrome parts, use a commercial chrome cleaner to restore and maintain the luster. As you clean, inspect the frames for cracks, rust, or other damage. Make sure welds are solid and fasteners are properly secured. OWNER’S MANUAL - FL1844... -
Page 12: Weekly Inspection
Cleaning upholstery daily removes surface dirt and perspiration. IMPORTANT: To clean the upholstery, do not use cleaning products that have any of these ingredients: solvents, alcohol, ammonia, and petroleum. Use a mild detergent-based cleaner instead. OWNER’S MANUAL - FL1844... -
Page 13: Monthly Inspection
For removing heavier dirt and grease and for polishing, use a good car polish. For scuffs and marks that are not removed by the above methods, use a soft scrub cleanser. Do not use solvents, lacquer thinner, acetone, or finger nail polish remover. OWNER’S MANUAL - FL1844... -
Page 14: Warranty
(30) calendar days after date of discovery of any defects. Warranty claims can be submitted to warranty@bodykore.com. Defected product must be available for visual inspection by BodyKore or BodyKore dealer with proof of the original serial number that is on the original packaging.
