SIM7090G User Manual V1.01
6.3 Typical SMT Reflow Profile
SIMCom provides a typical soldering profile. Therefore the soldering profile shown below is only a generic
recommendation and should be adjusted to the specific application and manufacturing constraints.
Figure 33: The ramp-soak-spike reflow profile of SIM7090G
NOTE
For more details about secondary SMT, please refer to the document [19].
www.simcom.com
65 / 77
