3 Interface Application
3.1 Power Supply
Pin 19 and pin 20 are VBAT power input.
On VBAT pads, when module works on CAT-M1 or NB-IoT mode, the ripple current is up to 0.5A typically.
For steady voltage, the power supply capability must be up to 0.5A.
Table 6: VBAT pins electronic characteristic
Symbol
Description
VBAT
Module power voltage
Module power peak current in CAT-M1 and NB-IoT
I
VBAT(peak)
emission mode.
I
Module power average current in normal mode
VBAT(average)
I
Power supply current in sleep mode
VBAT(sleep)
I
Module power current in power off mode.
VBAT(power-off)
I
Module power current in PSM mode.
VBAT(PSM)
3.1.1 Power Supply Design Guide
In the user's design, special attention must be paid to the design of the power supply to ensure that the drop
of VBAT is not less than 2.5V even when the module's current consumption reaches the instantaneous
maximum. If the voltage drop is less than 2.5V, the module may shut down due to the low voltage.
The following figure shows the recommended circuit.
www.simcom.com
SIM7090G User Manual V1.01
Min.
Typ.
Max.
2.7
3.8
4.8
-
0.5
-
Please refer to the chapter 5.4
-
-
15
-
3
-
Unit
V
A
uA
uA
22 / 77
