Table 33: Recommended TVS
Package
Part Number
0201 LXES03AAA1-154
0402 LXES15AAA1-153
4.3 GNSS
SIM7090G merges GNSS (GPS/GLONASS/BD) satellite and network information to provide a
high-availability solution that offers industry-leading accuracy and performance. This solution performs well,
even in very challenging environmental conditions where conventional GNSS receivers fail, and provides a
platform to enable wireless operators to address both location-based services and emergency mandates.
4.3.1. GNSS Technical specification
Tracking sensitivity: -159 dBm (GPS+GLONASS)/-159 dBm (GPS+BD)

Cold-start sensitivity: -147 dBm

Accuracy (Open Sky): 1 m (CEP50)

TTFF (Open Sky) : Hot start < 1 s, Cold start< 31 s

Receiver Type: 16-channel, C/A Code

GNSS L1 Frequency: 1575.42±1.023MHz

GLONASS: 1597.5~1605.8 MHz

BD: 1559.05~1563.14 MHz

Galileo L1: 1575.42±1.023MHz

Update rate: Default 1 Hz

GNSS data format: NMEA-0183

GNSS Current consumption : 54mA (AT+CFUN=0,without USB)

GNSS antenna: Passive/Active antenna

NOTE
If the antenna is active type, the power should be given by main board because there is no power
supply on the GNSS antenna pad. If the antenna is passive, it is suggested that the external LNA
should be used.
www.simcom.com
SIM7090G User Manual V1.01
Vender
Murata
Murata
