- Page 1 USB-C to USB-A PD Adapter Model Number: CG-UCUSBPD Installation Guide Coolgear, Inc. Version: 1.0 Date: 04/02/2024...
-
Page 2: Table Of Contents
First Release 1. Introduction Thank you for purchasing Coolgear’s CG-UCUSBPD. The Product complies with the USB3.1 Gen1 (compatible with Gen 2), USB2.0/1.1 host and acts as a PD source for its upstream USB-C port. It provides a downstream facing port with standard USB-A connector which works with USB3.1 Gen 1 (5Gbps) devices and backward compatible... -
Page 3: Connector Layout
CG-UCUSBPD – Installation Guide 2. Connector Layout 3. Input and Output Power The required input power for the Product is 18~20V DC. It can be connected to either the DC Jack or Terminal Blocks (but not simultaneously). If the Product comes with the 20V/3.25A (65W) standard power supply, it must be connected to the DC Jack. -
Page 4: Installing The Product
CG-UCUSBPD – Installation Guide 4. Installing the Product NOTE: If the supplied power supply along with the Product is 65W (20V/3.25A), then the maximum power output to the USB-C PD port is 65W instead of 100W. The Product needs a 100W supply if the PD sink really needs 100W. -
Page 5: Specifications
CG-UCUSBPD – Installation Guide 6. Specifications Type Specifications Connectors Upstream: Type-C USB3.1 Gen 1/2.0/1.1 Downstream: Type-A USB3.1 Gen 1/2.0/1.1 Speed USB3.1 Gen 1 at 5Gbps USB Signals SSRX+/-, SSTX+/-, D+/- Input Power 18~20V DC Supported Power PDOs 20V/5A(3A), 14.5V/2A, 12V/3A and 5V/3A. - Page 6 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
