- Page 1 Single Port RS-232 USB Serial Adapter – Optical- ISO – Surge Protection Product Manual Coolgear, Inc. Version 1.1 March 2018 Model Number: USB-COM-Si-M www.coolgear.com...
- Page 2 Coolgear New Manual About this document This product manual outlines installation and features of the USB-COM-SI-M Single Port RS-232 USB Serial Adapter – Optical-ISO – Surge Protection. Scope The scope of this manual is to give the user of the product an understanding of its use with detailed diagrams and verbiage.
-
Page 3: Table Of Contents
USB-COM-Si-M – Product Manual Table of Contents 1. Introduction ......................4 Features ........................4 Optical Isolation and Surge Protection ..............4 Power Requirement ....................5 2. Windows 7 / Vista / 2003 / XP / 2000 Driver Installation ........6 3. -
Page 4: Introduction
USB-COM-Si-M – Product Manual 1. Introduction The USB-COM-SI-M USB to Serial Adapter is designed to make serial port expansion quick and simple. The USB Serial Adapter provides instant connectivity to RS-232 communication device for factory automation equipment, multi-drop data collection devices, barcode readers, time clocks, scales, data entry terminal and serial communication in harsh environment. -
Page 5: Power Requirement
USB-COM-Si-M – Product Manual surges and spikes cannot cross the optical link. Each RS-422/485 port is individually protected by surge protector to withstand electrostatic discharge and power surges up to 25KV ESD. Surge suppression on all signals prevent from damages caused by lightning or high voltage. -
Page 6: Windows 7 / Vista / 2003 / Xp / 2000 Driver Installation
USB-COM-Si-M – Product Manual 2. Windows 7 / Vista / 2003 / XP / 2000 Driver Installation You need to have administrator privileges to install any new drivers under Windows 7/ Vista / 2003 / XP / 2000. To install the driver or update the configuration please log onto Windows as "Administrator"... -
Page 7: Check Installation
USB-COM-Si-M – Product Manual 3. Check Installation You can now verify the installation has been completed successfully by looking under Device Manager of the System Properties screen. (Go there by Start-Setting- Control Panel-System Properties-Hardware-Device Manager. The device should have installed as a "USB Serial Port (COMx)" attached to "USB Serial Converter (A/B or A/B/C/D)". -
Page 8: Figure 2, 3, 4, 5 - Uninstalling 2003/Xp/2000 Windows Drivers
USB-COM-Si-M – Product Manual Figure 2 5. You need to disconnect all USB to Serial Adapters from your PC, when the message below appears. Double click “OK” to start uninstalling Windows 2003/XP/2000 USB to Serial drivers. Figure 3 6. Double click “Yes” to confirm it. -
Page 9: Figure 6, 7 - Uninstall 2003 / Xp / 2000 Drivers
USB-COM-Si-M – Product Manual 8. When the message “Status: System clean completed” appears, double click “Exit” to complete the USB to serial drivers uninstall. Figure 6 9. Press “Start” button and select “Control Panel”. 10. Open the Add or Remove program. -
Page 10: Uninstalling Windows 7 Or Vista Drivers
USB-COM-Si-M – Product Manual 4. Uninstalling Windows 7 or Vista Drivers Windows 7 and Vista have many new security features. You need to proceed with the following steps to uninstall the Vista driver: 1. The USB to serial devices must connect to the PC. -
Page 11: Figure 10, 11, 12 - Uninstall Win7 Or Vista Drivers
USB-COM-Si-M – Product Manual 6. Select uninstall and be sure to click the box for “Delete the driver software for this device” in the next window and press “OK”. Figure 10 Note: if you have more than one USB Serial Port (COMx) installed in your PC, you need to repeat from step 5 to step 6 to delete the driver software for each port. - Page 12 USB-COM-Si-M – Product Manual 8. Select uninstall and be sure to click the box for “Delete the driver software for this device” in the next window and press “OK”. Figure 12 Note: if you have more than one USB Serial Converter installed in your PC, you need to repeat step 7 and step 8 to delete the driver software for all devices.
-
Page 13: Rs-232 Signal Pin-Outs Of Db-9 Male
USB-COM-Si-M – Product Manual 5. RS-232 Signal Pin-outs of DB-9 Male Figure 13 Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6 Pin 7 Pin 8 Pin 9 www.coolgear.com... -
Page 14: Notes, Tips, And Warnings
USB-COM-Si-M – Product Manual 6. Notes, Tips, and Warnings Note: Sometimes, when operating in RS-422 or RS-485, it is necessary to configure termination and biasing of the data transmission lines. Generally this must be done in the cabling, since this depends on the installation of connections. - Page 15 USB-COM-Si-M – Product Manual electrical connections that must be followed for safe and proper operation. • Inspect the product closely for visual defects before putting it to use. • Keep away from areas where moisture builds, this product contains electrical components that can be damaged by moisture build up, this can adversely affect your equipment connected to it.
-
Page 16: Supporting References
© 2017 Coolgear, Inc. All Rights Reserved. All products and accompanying digital documentation including images are the property and / or trademarks of Coolgear Inc. Coolgear Inc. are continuously improving upon its products. Product specifications are subject to change without notice.
