SIROCCO SC25

SOLID FUEL CATALYTIC STOVE

OPERATION & INSTALLATION MANUAL

U.S. EPA CERTIFIED TO COMPLY WITH 2020 PARTICULATE EMISSION STANDARDS USING CRIB WOOD

Installer: Please complete the details on the back cover

and leave this manual with the homeowner.

Homeowner: Please SAVE THESE INSTRUCTIONS for future reference.

0142WN020E

0142WN017S

MANUFACTURED BY

Valley Comfort Systems Inc., 1290 Commercial Way, Penticton BC, Canada, V2A 3H5

web: www.blazeking.com email: info@blazeking.com

ATTENTION: The authority having jurisdiction (municipal building department, ﬁ re department, etc.) should be

consulted before installation to determine the need to obtain a permit.

Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com

180-SC25 v2.50

April 4, 2024

Table of Contents

Troubleshooting

Need help?

Do you have a question about the SIROCCO SC25 and is the answer not in the manual?

Questions and answers

Summary of Contents for Blaze King SIROCCO SC25

Page 1 SIROCCO SC25 SOLID FUEL CATALYTIC STOVE OPERATION & INSTALLATION MANUAL U.S. EPA CERTIFIED TO COMPLY WITH 2020 PARTICULATE EMISSION STANDARDS USING CRIB WOOD Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please SAVE THESE INSTRUCTIONS for future reference.
Page 2: Table Of Contents
SC25 TABLE OF CONTENTS Page 2 CERTIFICATION LABEL ________________________________________________________ 4 PREFACE ____________________________________________________________________ 5 EPA CERTIFICATION TEST DATA ....................5 SPECIFICATIONS _____________________________________________________________ 6 PARTS INCLUDED .......................... 6 REQUIRED KIT ..........................6 REQUIRED KIT (MUST INSTALL ONE OPTION) ................. 6 APPLIANCE DIMENSIONS ______________________________________________________ 7 SAFETY CLEARANCES _________________________________________________________ 10...
Page 3 SC25 TABLE OF CONTENTS Page 3 CATALYTIC COMBUSTOR ______________________________________________________ 25 COMBUSTOR MONITORING ......................25 COMBUSTOR TESTING ......................... 25 COMBUSTOR CLEANING ......................26 COMBUSTOR REPLACEMENT ...................... 26 COMBUSTOR WARRANTY ......................28 COMBUSTOR TROUBLESHOOTING .................... 29 MAINTENANCE ______________________________________________________________ 31 RECOMMENDED MAINTENANCE ....................31 THERMOSTAT or THERMOMETER MAINTENANCE ..............
Page 4: Certification Label
AUX ÉTATS-UNIS ET AU CANADA Install and use this appliance in accordance with Blaze King’s installation and operation instructions. Contact local building or ﬁ re oﬃ cials about restrictions and installation inspection in your area. Not to be installed in any factory built ﬁ...
Page 5: Preface
PREFACE Page 5 The content within this manual describes the installation EPA CERTIFICATION TEST DATA and operation of the Blaze King SC25. It is against Burn Category CO Ave Emission Rate federal regulations to operate this appliance in a manner Low Burn 0.21 g/min...
Page 6: Specifications
SC25 SPECIFICATIONS Page 6 SIROCCO 25, SC25 SPECIFICATIONS Flue Collar Opening 6” I.D. (152.4 mm) Firebox Door Opening 25 1/4” x 10 5/8” (642 mm x 270 mm) Firebox Depth 16 3/4” (426 mm) brick to brick, 18” (457 mm) brick to glass Firebox Width 18”...
Page 7: Appliance Dimensions
SC25 APPLIANCE DIMENSIONS Page 7 SC25 WITH 27 1/8” SHROUD (S.Z2045) 180-SC25 v2.50 April 4, 2024...
Page 8 SC25 APPLIANCE DIMENSIONS Page 8 SC25 WITH 29 1/8” SHROUD (S.Z2070) 180-SC25 v2.50 April 4, 2024...
Page 9 SC25 APPLIANCE DIMENSIONS Page 9 SC25 WITH 32 1/8” SHROUD (S.Z2075) 180-SC25 v2.50 April 4, 2024...
Page 10: Safety Clearances
SC25 SAFETY CLEARANCES Page 10 MINIMUM CLEARANCES Side of door ﬂ ange to combustible wall 13.5” (343 mm) Top of door ﬂ ange to bottom of mantel / combustible facing 20” (508 mm) Side of door ﬂ ange to combustible facing 10”...
Page 11: Chimney Connections
Inadequate draft can also lead to low heat output and the inability for the combustor to remain active at low burn rate settings. Your Blaze King heater is a high eﬃ ciency appliance and will require ﬁ ne tuning of your chimney system in order to maximize draft performance.
Page 12: Venting System
ﬁ replace insert and should be inspected by a qualiﬁ ed person prior to re-use as a conventional ﬁ replace.” Blaze King recommends the use of a stainless steel liner, preferably insulated, inside a masonry chimney. This is to help maintain a proper draft to achieve optimal performance of the appliance.
Page 13: Recommended Chimney Heights
As previously mentioned, Blaze King recommends a minimum vertical chimney height of 15 feet (from stove top to termination) when installing an appliance at sea level (and up to 1000 feet of elevation). If...
Page 14: Installation Instructions
AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA. ELECTRICAL CONNECTION Your Blaze King fan kit is equipped with a three-prong (grounded) plug to decrease shock hazard. This plug should be inserted directly into a properly grounded, three hole receptacle. DO NOT CUT OR REMOVE THE GROUNDING PRONG FROM THIS PLUG.
Page 15: Thermostat Rod Installation
SC25 INSTALLATION INSTRUCTIONS Page 15 THERMOSTAT ROD INSTALLATION First, ensure the fans are in their correct position and have not shifted during transport. Ensure the thermostat is in the fully open position with the set screw making contact with the stop (see below). Slide the thermostat rod in from the left side of the ﬁ...
Page 16: Fireplace Levelling
SC25 INSTALLATION INSTRUCTIONS Page 16 FIREPLACE LEVELLING Before sliding the appliance into the ﬁ replace opening, determine how much levelling will be required to ensure a proper installation. Working through the opening of the lower shroud, locate the x4 levelling bolts at the front and rear corners of the appliance which must be adjusted accordingly to insure a level installation.
Page 17: Flue Collar Installation
SC25 INSTALLATION INSTRUCTIONS Page 17 FLUE COLLAR INSTALLATION Once the liner has been dropped down the chimney, it must be securely attached to the ﬂ ue collar assembly (refer to CHIMNEY CONNECTIONS” the “ section Note: Ensure the ﬂ ue collar assembly will hang roughly 2’ (607 mm) above the ﬂ oor of the ﬁ replace once attached to the chimney liner as this will ease the connection to the appliance once it is pushed into the ﬁ...
Page 18: Operating Instructions
FAN OPERATION Fans are an optional item for most Blaze King appliances. If fans are installed on your appliance, they should be turned oﬀ until the stove reaches normal operating temperatures. Approximately 30 minutes after a ﬁ re has been established within the appliance, the fan speed should match the thermostat control setting.
Page 19: Selecting Wood
SC25 OPERATING INSTRUCTIONS Page 19 SELECTING WOOD It takes a great deal of energy to evaporate the moisture contained in green or wet wood and that energy will not be heating your home. Green or wet wood will also greatly increase creosote issues. To ensure that your wood fuel has a moisture content of 20% or lower, only use seasoned wood that has been split, stacked, and protected from rain or snow for at least 24 months.
Page 20: Bypass Door & Bypass Handle
SC25 OPERATING INSTRUCTIONS Page 20 BYPASS DOOR & BYPASS HANDLE This catalytic wood burning appliance is ﬁ tted with a bypass door which allows exhaust from the ﬁ re to temporarily bypass the catalytic combustor. The bypass door is located inside the dome of the ﬁ rebox at the top of the appliance.
Page 21: Thermostat
SC25 OPERATING INSTRUCTIONS Page 21 THERMOSTAT The thermostat is located below the ash lip of the appliance and is controlled by the thermostat knob which is located on the lower left side of the front assembly. When the knob is positioned at the HIGH setting, the appliance will operate at its highest burn rate and deliver its maximum heat output.
Page 22: Lighting The Fire
ﬁ re going until the next reloading time. Don’t be afraid to ﬁ ll it completely if necessary. With the Blaze King thermostat, the wood will only burn at the rate set on the thermostat. Once the ﬁ...
Page 23: Reloading Procedure
SC25 OPERATING INSTRUCTIONS Page 23 RELOADING PROCEDURE WHEN PREPARING TO RELOAD, IF THE NEEDLE ON THE CATALYTIC THERMOMETER IS STILL IN THE ACTIVE ZONE, FOLLOW THE PROCEDURE BELOW; IF THE NEEDLE HAS DROPPED INTO THE INACTIVE ZONE, REFER BACK TO THE “LIGHTING THE FIRE” PROCEDURE ON THE PREVIOUS PAGE.
Page 24: Optimal Low Burn Thermostat Setting
OPTIMAL LOW BURN THERMOSTAT SETTING TESTED LOW BURN SETTING Your Blaze King appliance was tested and certiﬁ ed in accordance to the New Source Performance Standards for Residential Wood Heaters. During this test series, the low burn rate of the unit was determined by setting the thermostat knob to a position that yielded the lowest burn rate achievable.
Page 25: Catalytic Combustor
6. If, after cleaning the combustor and reburning, the thermometer needle is still not reaching the ACTIVE zone, your combustor may need replacing. Contact your Blaze King dealer for a replacement combustor. Note - It is also possible that the catalytic thermometer itself may not be functioning properly. Before deeming the combustor “dysfunctional”, please refer to the “CATALYTIC THERMOMETER”...
Page 26: Combustor Cleaning
If the catalytic combustor has been deemed “dysfunctional” per the guidelines in “COMBUSTOR TESTING”, discontinue use of the appliance until the combustor is replaced. Follow the steps below to complete the replacement (BLAZE KING RECOMMENDS THAT YOUR DEALER OR CERTIFIED INSTALLER PERFORM THIS PROCEDURE): 1.
Page 27 SC25 CATALYTIC COMBUSTOR Page 27 3. There are metal tabs across the bottom and on either side of the combustor. Using a ﬂ at blade screwdriver or pocket knife blade, slide the tip in between the metal tab on the left side of the combustor and the steel dome of the stove (the dome is the housing that encases the combustor).
Page 28: Combustor Warranty
It is against federal regulations to operate this appliance if the catalytic combustor is deactivated or removed. The catalytic combustor supplied with this appliance is OEM Blaze King part #S.CAT2425. Please consult the catalytic combustor warranty info also supplied with this appliance. Warranty claims should...
Page 29: Combustor Troubleshooting
Solution: Burn good quality, dry, seasoned wood. If proper burning procedures have been followed and this problem persists, replace the combustor with an OEM Blaze King combustor (failure to do so will void your warranty). Severe Peeling 180-SC25 v2.50...
Page 30 Solution: Avoid ﬂ ooding a hot, active combustor with cool room air when reloading. If cracking causes large pieces of the combustor to separate, replace the combustor with an OEM Blaze King combustor (failure to do so will void your warranty). PROBLEM: MECHANICAL CRACKING Possible Cause: Mishandling the combustor or operating the appliance without the proper gasket installed.
Page 31: Maintenance
SC25 MAINTENANCE Page 31 TO PREVENT SERIOUS BURNS, DO NOT PERFORM ANY MAINTENANCE UNTIL THE APPLIANCE IS COOL. APPLIANCE SURFACES, INCLUDING THE GLASS AND ANY ATTACHED COMPONENT, WILL REMAIN HOT FOR EXTENDED PERIODS OF TIME AFTER THE FIRE HAS BEEN PUT OUT. RECOMMENDED MAINTENANCE It is strongly recommended to complete the following tasks on a regular basis throughout the heating season: Visually inspect Catalytic Combustor and clean as required (see “COMBUSTOR CLEANING”)
Page 32: Loading Door Gasket Inspection
LOADING DOOR GASKET REPLACEMENT If door gasket replacement is required, only replace with OEM door gasket ordered through your Blaze King dealer. This gasket will be properly sized and ready to install. Do not stretch or cut the gasket at any time during this installation.
Page 33: Door Gasket Paper Test
If door glass gasket replacement is required, only replace with OEM door glass gasket ordered through your Blaze King dealer. The OEM gasket will be ordered to size and ready to re-install. Do not stretch or cut the gasket at any time during this installation. Blaze King recommends that your dealer perform this task: 1.
Page 34: Bypass Door Gasket Inspection
SC25 MAINTENANCE Page 34 BYPASS DOOR GASKET INSPECTION Visually note the amount of smoke exiting the chimney while the bypass door is both OPEN and CLOSED. There should be signiﬁ cantly less smoke when the door is in the CLOSED position. If this is not the case, the bypass gasket may need to be replaced.
Page 35 SC25 MAINTENANCE Page 35 3. Remove the two 1/4-20 bolts and washers that hold the dome guard in place, be sure to support the dome guard during this process is it will come loose. Once the dome guard is removed, unthread the two 1/4-20 coupling nuts that spaced the dome guard from the dome bottom.
Page 36: Venting System Maintenance
SC25 MAINTENANCE Page 36 5. Once the inner dome surface has been cleared, insert the new bypass door gasket retainer assembly and follow the above instructions in reverse to ensure complete install. Ensure that 1/8” ceramic paper is in between the gasket retainer assembly and inner dome surface. Also ensure that all nuts are completely fastened up to the dome bottom.
Page 37: Troubleshooting
Page 37 Your Blaze King is designed to allow a wide selection of heat output levels. If you begin to lose control of the amount of heat the stove is emitting, determine the cause early so that major problems may be avoided.
Page 38 ﬁ rebox. INSPECTION” Excessive draft in the chimney. Measure draft with a Manometer. See “DRAFTS”. Consult your Blaze King dealer or a chimney sweep. Install a cap. Thermostat not operating properly. Consult your Blaze King dealer. Wood is too small.
Page 39 Consult your blaze King Dealer. Bypass door leaking or not closing completely. Inspect and clean area around bypass doors. Adjust or replace gasket if necessary. Consult your Blaze King Dealer. PROBLEM: Spots of creosote accumulation in ﬂ ue pipe or chimney. CAUSE SOLUTION Air leaks in ﬂ...
Page 40: Replacement Parts
SC25 REPLACEMENT PARTS Page 40 Part # Description S.Z2019 BYPASS DOOR ASSEMBLY S.Z2022 BYPASS DOOR GASKET RETAINER ASSEMBLY S.Z2029 THERMOSTAT ROD ASSEMBLY S.Z2051 CATALYTIC THERMOMETER ASSEMBLY S.CAT2425 COMBUSTOR ASSEMBLY S.2030 FLAME SHIELD S.155.0254.6 DOOR GLASS GASKET - 7ft 130-0270 DOOR GLASS S.Z2044 DOOR HANDLE S.155.0186.6...
Page 41 SC25 REPLACEMENT PARTS Page 41 Brick Layout ITEM NO. PART NUMBER QTY. A Size Brick AA Size Brick KT Size Brick PP Size Brick SI Size Brick 180-SC25 v2.50 April 4, 2024...
Page 42: Warranty
Blaze King and Valley Comfort’s respective brands extend the following warranty for wood ﬁ red appliances purchased from an authorized Blaze King / Valley Comfort dealer and installed in the United States of America or Canada. Warranty starts with date of purchase by the original owner (End User) except as noted for replacement parts.
Page 43 If you are not satisﬁ ed with the service provided by the Blaze King dealer, write to Blaze King at the address listed on the last page of the Owner’s Manual. Include a copy of the original purchase invoice and a description of the problem.
Page 44 Blaze King The use of such products may nullify the Limited Warranty on this stove. If unsure as to the extent of this Limited Warranty, contact your authorized Blaze King dealer before installation.
Page 45 For parts of the Blaze King wood stove or ﬁ replace insert warranted beyond the ﬁ rst year, the ﬁ ve year limited warranty will have the same obligations as described in this document, provided, however that the purchaser shall pay the following percentage of the then current retail cost of the repair or the replacement, according to the year after purchase in the which the defect is brought to the attention of Blaze King.*** During the 2nd year----purchaser pays...
Page 46: Installer Notes
SC25 INSTALLER NOTES Page 46 180-SC25 v2.50 April 4, 2024...
Page 47 SC25 INSTALLER NOTES Page 47 180-SC25 v2.50 April 4, 2024...
Page 48 SC25 INSTALLER NOTES Page 48 Installer - Please complete the following information: Dealer Name & Address:________________________________________________________ ____________________________________________________________________________ Installer Name (print): _________________________________________________________ Installer Signature: ___________________________________________________________ Installer Phone #: ____________________________________________________________ Date Installed:________________________________________________________________ Appliance Serial No.: __________________________________________________________ 180-SC25 v2.50 April 4, 2024...
