ASHFORD 30
SOLID FUEL CATALYTIC STOVE: AF30
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please save these instructions for future reference.
Report # 142-S-11d-2
Th e authority having jurisdiction (such a municipal building department, fi re department, etc.) should be
consulted before installation to determine the need to obtain a permit.
Manufactured By
Valley Comfort Systems Inc.
Blaze King Industries
1290 Commercial Way
146 A Street
Penticton, BC V2A 3H5
Walla Walla, WA 99362
CANADA
U.S.A.
Phone: 250-493-7444
Phone: (509) 522-2730
Fax: 250-493-5833
Fax: (509) 522-9803
Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com
OM-AF30 E V1.02
October 18, 2013
Advertisement
Table of Contents
Related Manuals for Blaze King ASHFORD 30
Summary of Contents for Blaze King ASHFORD 30
- Page 1 ASHFORD 30 SOLID FUEL CATALYTIC STOVE: AF30 Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please save these instructions for future reference. Report # 142-S-11d-2 Th e authority having jurisdiction (such a municipal building department, fi re department, etc.) should be consulted before installation to determine the need to obtain a permit.
-
Page 2: Table Of Contents
ASHFORD 30 Page 2 Table of Contents _____________________________________________________________ 3 INTRODUCTION _____________________________________________________________ 4 SPECIFICATIONS _____________________________________________________ 5 PRODUCT INFORMATION ................... 5 APPLIANCE DIMENSIONS—Ashford AF30 ________________________________________________________ 6 CERTIFICATION LABEL ________________________________________________________ 7 SAFETY PRECAUTIONS _________________________________________________ 10 INSTALLATION INSTRUCTIONS ............................10 GENERAL ........................10 FREIGHT DAMAGE ................... -
Page 3: Introduction
Disregarding inspection and code requirements may jeopardize your homeowner's insurance. Since some insurance carriers require notifi cation of a stove installation, contact your insurance agent. We want your Blaze King to give you a lifetime of trouble-free operation. -
Page 4: Specifications
ASHFORD 30 Page 4 SPECIFICATIONS Model Ashford 30 (catalytic) Height 32 7/8” (835mm) Width 29 1/2” (750mm) (without removable bypass handle) Depth 29 3/8” (746mm) (without optional fan kit) 31 1/8” (762mm) (with optional fan kit) Flue collar 6" I.D. -
Page 5: Product Information
ASHFORD 30 Page 5 PRODUCT INFORMATION APPLIANCE DIMENSIONS—Ashford AF30 " (w/ optional fan) " " " " " " " " " " " " OM-AF30 E V1.02 October 18, 2013... -
Page 6: Certification Label
CERTIFIED IN BOTH UNITED STATES AND CANADA / CERTIFIÉ POUR LES ÉTATS-UNIS ET LE CANADA PREVENT HOUSE FIRES- Install and use only in accordance with Blaze King’s installation and operation instructions. Contact local building or fi re offi cials about restrictions and installation inspection in your area. -
Page 7: Safety Precautions
Page 7 SAFETY PRECAUTIONS IF THIS BLAZE KING STOVE IS NOT PROPERLY INSTALLED OR OPERATED, A HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA. - Page 8 ASHFORD 30 Page 8 SAFETY PRECAUTIONS cont. Never try to repair or replace any part of this appliance Do not place clothing or other unless instructions are given fl ammable items on or near in this manual. All other work this appliance.
- Page 9 ASHFORD 30 Page 9 SAFETY PRECAUTIONS cont. Install at least one smoke This appliance is designed detector on each fl oor of your and approved for burning cord home to ensure your safety. It wood only. should be located away from...
-
Page 10: Installation Instructions
FREIGHT DAMAGE Th is product was carefully inspected before it left Blaze King. Inspect the unit thoroughly upon its arrival. If damage is found report it to the carrier and then immediately fi le a freight damage claim. -
Page 11: Minimum Clearances For Af30
ASHFORD 30 Page 11 INSTALLATION INSTRUCTIONS cont. MINIMUM CLEARANCES for AF30 Residential Installations 10.75” 6” 25.5” 16.375”* 4” 16.875”* 72” Roof exit, parallel and corner. No fan kit required. 273mm 153mm 648mm 416mm 102mm 429mm 1829mm 10.75” 6” 25.5” 16.375”* 4”... -
Page 12: Combustion Air
Th ey cannot properly withstand the extreme temperatures of a wood fi re. Th e chimney connector between the stove and the chimney should be as short and direct as possible. Blaze King recommends the use of double wall pipe and two 45° elbows instead of a single 90° elbow. A minimum 36” rise is recommended prior to any elbows being used. - Page 13 ASHFORD 30 Page 13 INSTALLATION INSTRUCTIONS cont. CONNECTION TO A METAL PREFABRICATED CHIMNEY When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed precisely. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass through and “T”...
- Page 14 If covers are to be used on both sides, each cover must be mounted on noncombustible spacers at least 1” clear of the wall. ***Blaze King recommends the use of a Stainless steel liner, preferably insulated, inside a masonry chimney. Th is to maintain proper draft and overall better operation of the unit.
-
Page 15: Mobile Home (And Residential Alcove Installations)
ASHFORD 30 Page 15 INSTALLATION INSTRUCTIONS cont. MOBILE HOME (AND RESIDENTIAL ALCOVE INSTALLATIONS) A fan kit is required for these installations (See next page for kit and part numbers). Mobile home installations also requires the Outside Air Kit: Z1726B. Th ey are easiest to mount before the stove is installed. See instructions packed with each kit. -
Page 16: Optional Accessories
2) screw driver and a 5/32” Allen wrench. ELECTRICAL CONNECTION Your Blaze King fan kit is equipped with a three-prong (grounded) plug to decrease shock hazard. THIS PLUG SHOULD BE INSERTED DIRECTLY INTO A PROPERLY-GROUNDED, THREE- HOLE RECEPTACLE. DO NOT CUT OR REMOVE THE GROUNDING PRONG FROM THIS PLUG. -
Page 17: Door Installation And Change-Out
ASHFORD 30 Page 17 INSTALLATION INSTRUCTIONS cont. DOOR INSTALLATION AND CHANGE-OUT (Z2810BK) To install the door assembly or to change it out, follow these steps: WARNING: CAST PARTS ARE HEAVY, PLEASE HOLD FIRMLY. INSTALLATION 1. Remove catalytic thermometer and cast top from stove. -
Page 18: Operating Instructions
ASHFORD 30 Page 18 OPERATING INSTRUCTIONS YOUR FIRST FIRE! Th e following pages contain information on the major components and operation of your stove. Please take time to read about them as it will give you a better understanding of how your stove works. Th is understanding will help you to operate your stove properly thus will extend the life of your stove and allow you to get the highest effi ciencies from your stove. - Page 19 OPERATING INSTRUCTIONS cont. FUEL Blaze King recommends using dry seasoned wood, split and stacked and protected from rain for at least 24 months with a moisture content of 13% or lower. It takes a great deal of energy to evaporate the moisture contained in green wood and that energy will not be heating your house.
- Page 20 Many new stove users hesitate to load enough wood to sustain a fi re. Put as much fuel into the stove as it will hold. Don’t be afraid to fi ll it completely*. With the Blaze King automatic thermostat, the wood will only burn at the rate set on the thermostat.
- Page 21 Th ank you again for purchasing a Blaze King catalytic wood stove. Be sure and tell your friends how you much less time and money you spent on obtaining wood for the winter because your new Blaze King uses wood so effi ciently.
- Page 22 ASHFORD 30 Page 22 OPERATING INSTRUCTIONS cont. FAN OPERATION If you have the Optional Fan Assembly installed, the fan should be off until the stove reaches normal operating temperatures. Aft er approximately 30 minutes, the fan speed adjustment should match the thermostat control setting, i.e.
-
Page 23: Creosote
ASHFORD 30 Page 23 CREOSOTE CREOSOTE — FORMATION AND NEED FOR REMOVAL When wood is burned slowly, it produces tar and other organic vapors, which combine with expelled moisture to form creosote. Th e creosote vapors condense in the relatively cool chimney fl ue of a slow-burning fi re. As a result, creosote residue accumulates on the fl ue lining. -
Page 24: Maintenance
Page 24 MAINTENANCE Your appliance has been manufactured in the Blaze King tradition of high quality. To ensure years of trouble free operation, have your stove serviced regularly by your Blaze King dealer. Periodically during the heating season thoroughly clean the chimney and fi rebox so your system is ready for next fall. Inspect all fi rebricks and replace any damaged bricks. -
Page 25: Catalytic Combustor, Cleaning
ASHFORD 30 Page 25 MAINTENANCE cont. CATALYTIC COMBUSTOR, CLEANING Under certain conditions, ash particles may become attached to the face of the combustor. Th ese may be seen while the combustor is in the glowing stage, or when the fi re is out. Any deposit on the visible face of the combustor should be removed. -
Page 26: Door Glass, Cleaning
( Blaze King recommends your dealer perform this task) Your BLAZE KING is equipped with a door which uses a strong, heat-resistant ceramic glass intended to withstand extremely high temperatures and tested for continuous use above 1200 degrees Fahrenheit. However, this glass can be broken through improper use. -
Page 27: Loading Door Gasket Replacement
LOADING DOOR GASKET REPLACEMENT (Blaze King recommends your dealer perform this task) 1. If the door gasket is to be replaced, be sure you have Blaze King 7/8” fi ber glass gasket material, ready to re-install. See your Blaze King dealer. -
Page 28: Chimney Drafts
Holding the probe with a pair of pliers, loosen the bolt on the top of the dial. Turn the dial to align the pointer with the bottom of the “Inactive” zone, then retighten the bolt. NOTE: IF YOUR BLAZE KING IS EQUIPPED WITH OPTIONAL FANS, TURN OFF FANS AND WAIT 10 MINUTES PRIOR TO READING CATALYTIC THERMOMETER INDICATOR. AIR MOVEMENT ACROSS THE TOP OF THE STOVE MAY PROVIDE FALSE READING. -
Page 29: Troubleshooting
TROUBLESHOOTING Your Blaze King is designed to allow a wide selection of heat output levels. If you begin to lose control of the amount of heat the stove is emitting, determine the cause early so that major problems may be avoided. - Page 30 fi rebox. INSPECTION” Excessive draft in the chimney. Measure draft with a Manometer. See “DRAFTS”. Consult your Blaze King dealer or a chimney sweep. Install a cap. Thermostat not operating properly. Consult your Blaze King dealer. Wood is too small.
- Page 31 Consult your blaze King Dealer. By-pass door leaking or not closing completely. Inspect and clean area around by-pass doors. Adjust or replace gasket if necessary. Consult your Blaze King Dealer. PROBLEM: Spots of creosote accumulation in chimney or chimney connector. CAUSE SOLUTION Air leaks in chimney or chimney connector.
-
Page 32: Replacement Parts
ASHFORD 30 Page 32 REPLACEMENT PARTS OM-AF30 E V1.02 October 18, 2013... - Page 33 ASHFORD 30 Page 33 REPLACEMENT PARTS cont. OM-AF30 E V1.02 October 18, 2013...
- Page 34 ASHFORD 30 Page 34 REPLACEMENT PARTS cont. Replacement Parts and Kit list for Ashford AF30 exploded Part # Description view H/Z0243 5 mm Thick Ceramic Glass 17 7/8” x 11” H/0254AS Glass Gasket 1/8 x 3/4 301B W/PSA - 5 ft H/0186 Door Gasket 7/8”...
-
Page 35: Brick Layout
ASHFORD 30 Page 35 REPLACEMENT PARTS cont. Brick Layout Number Brick Size Qty. CERAMIC BLANKET 0830I OM-AF30 E V1.02 October 18, 2013... -
Page 36: Warranty
Blaze King and its respective brands extend the following warranty for wood fi red appliances purchased from an authorized Blaze King dealer and installed in the United States of America or Canada. Warranty starts with date of purchase by the original owner (End User) except as noted for replacement parts. - Page 37 If you are not satisfi ed with the service provided by the Blaze King dealer, write to Blaze King at the address listed on the last page of the Owner’s Manual. Include a copy of the original purchase invoice and a description of the problem.
- Page 38 Blaze King The use of such products may nullify the Limited Warranty on this stove. If unsure as to the extent of this Limited Warranty, contact your authorized Blaze King dealer before installation.
- Page 39 For parts of the Blaze King woodstove or fi replace insert warranted beyond the fi rst year, the fi ve year limited warranty will have the same obligations as described in this document, provided, however that the purchaser shall pay the following percentage of the then current retail cost of the repair or the replacement, according to the year after purchase in the which the defect is brought to the attention of Blaze King.*** During the 2nd year----purchaser pays...
-
Page 40: Notes
ASHFORD 30 Page 40 NOTES OM-AF30 E V1.02 October 18, 2013...
