PROPER USAGE AND ASSEMBLY INSTRUCTIONS
FMPRO3518CT 3 Drawer Cart
The following instructions will provide you with a guide for installation and usage
for the FMPRO Cart. If at any time you need guidance or help, please do not hesitate
to call us. Thanks again for choosing Champion Tool Storage.
Read all instructions before proceeding. Vital product information pertaining to
proper set-up and cautions are included. Failure to follow these instructions may
cause failure which may result in personal injury or property damage.
QUESTIONS
Champion Tool Storage
3070 Lower Mill Dr.
Hood River Oregon 97031
W: www.championbuilt.com
E-mail: info@championbuilt.com
Phone: 866-391-4200
8 AM - 5PM, PST, Monday-Friday
THIS DOCUMENT IS CONFIDENTIAL AND PROPRIETARY
FMP3518CT
Part No. 8001203
PART NO. 1000787
When upacking, make sure that the
product is intact and undamaged. If
any parts are missiing or broken,
please call as asoon as possible.
WARNING
Read this material before using
this product. Failure to do so can
result in serious injury.
SAVE THIS MANUAL
