Version #1.1
May 3, 2023
Stock Code:
SM63-TG-METAL
Thank you for purchasing a
6x3 Space Master. Please
take the time to identify all
the parts prior to assembly.
Important Information:
- It is the sole responsibility of the customer to check with your local municipal or county by-laws before
ordering this product to confirm it complies with building codes in your area.
- If the product is elevated, any structural and building code requirements are solely the customer's
responsibility, and should be abided by.
- Snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it is advisable to sweep
snow off roof frequently.
- In areas with high or gusty wind conditions, it is advisable to install the structure securely to the ground.
- Have a regular maintenance plan to ensure screws, doors, windows and parts are tightly affixed.
- All structures purchased from Outdoor Living Today are covered for a period of one year for defects in
manufacturing and workmanship. Costs incurred for customer installations are not included.
- Failure to use supplied parts included in this kit could result in poor product performance and may void your
warranty. Please contact Outdoor Living Today's Customer Toll Free Line if you plan to deviate from our
written instructions.
Customer agrees to hold Outdoor Living Today and any Authorized Dealers free of any liability for improper
installation, maintenance and repair.
In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line
@ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our commitment to you to courier
replacement parts, free of charge, within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Outdoor Living Today
6x3 SPACE
MASTER
WITH METAL ROOF
ASSEMBLY MANUAL
www.outdoorlivingtoday.com
Page 1
sales@outdoorlivingtoday.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Outdoor living today 6x3 SPACE MASTER
Summary of Contents for Outdoor living today 6x3 SPACE MASTER
- Page 1 - Have a regular maintenance plan to ensure screws, doors, windows and parts are tightly affixed. - All structures purchased from Outdoor Living Today are covered for a period of one year for defects in manufacturing and workmanship. Costs incurred for customer installations are not included.
- Page 2 You can find the footprint for your shed on Page 3 of your Assembly Manual. • If doing the assembly yourself, have all the necessary tools ready to go and in working condition. A list of required tools can be found after the parts list. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 2...
- Page 3 - 8 patio pavers (8” x 8” or larger). - Center patio paver stones underneath floor runners and underneath seams in floor joists. Patio paver stones are widely available from most landscape stores. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 3...
- Page 4 Thank you for purchasing our 6x3 Space Master with Metal Roof. Please take the time to identify all the parts prior to assembly. Parts List Steps D. - Trim / Misc. Section Cont. Steps 53 - 63 Outer Wall Trim and Fascia A.
-
Page 5: Hardware Kit
Plywood Spacer x 2 pcs Tools Required (Not Provided) Screw Gun/Drill Wood Clamp 3/8” Wrench Hammer Tape Measure Pliers 1/8” & 3/8” Drill Bits Level Ladder Safety Equipment Required (Not Provided) Safety Glasses Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 5... - Page 6 - Consult your local paint store for the best paint or stain for cedar. - Optional: stain the inside of your shed. (Note: this will remove the fresh cedar smell.) Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
-
Page 7: Floor Section
(35” x 73”) x 1 make excellent foundations. (See Page 3 for more information Hardware on foundations). Use a level to confirm and shim Floor Joist as 2 1/2” Brown Screws required. x 4 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 7... - Page 8 Parts Hardware Rear/Side Wall Panels 2 1/2” Brown Screws (35” x 63 1/4”) x 4 x 8 total Top Wall Plates (1 1/2” x 1 1/2” x 35”) x 4 Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 8...
- Page 9 Floor at both front and rear of shed. Make sure Wall frame is flush x 25 total with outside of Floor on the side. When Wall is positioned correctly, secure Bottom Wall Plate to Floor with 4 - 2 1/2” Brown Screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 9...
- Page 10 When Side and Rear Walls are aligned in corner correctly, Wall framings will be flush. Attach Wall framings together with 3 - 2 1/2” Brown Screws. Secure Bottom Wall Plate to Floor with 4 - 2 1/2” Brown Screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 11 In the corner, align and attach Right Side Wall framing to Rear Wall framing with 3 - 2 1/2” Brown Screws as per Step 6. Secure Bottom Wall Plate of Side Wall to Floor with 4 - 2 1/2” Brown Screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 12 Bottom Wall Plate to Floor with 2 - 2 1/2” Brown Screws. Attach vertical Wall framings together at top, middle and bottom with 3 - 2 1/2” Brown Screws. Front Header Align and attach the second Front Narrow Wall Panel as per Step 10. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 12...
- Page 13 Front Header, secure using 6 - 2 1/2” Brown Screws screwing down from the top of Front Top Plate down into Front Header. Parts Front Top Plate (1 1/2” x 1 1/2” x 70”) Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 13...
- Page 14 Top Plates are angle cut down the length. Attach Side Wall Top Plate to Side Wall framing with 4 - 3” Brown Screws. 2 1/2” Brown Screws Rear Wall Top Plate 3” Brown Screws Complete opposite Side Wall Top Plate positioning and attachment as per Step 17. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 14...
- Page 15 Rear Top Wall Plate and Wall Framing. Complete Gable positioning and attachment on the other side. Note: Gable Framing may overhang Top Plate on the inside by approximately 1/8”. Hardware 2” Brown Screws x 4 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 15...
- Page 16 Side Wall Storage Shelf Support Storage Shelf Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 16...
- Page 17 Exploded view of all parts necessary to complete the Rafter and Roof Section. Identify all parts prior to starting. Batten Spacers (8) Foam Enclosure (4) Battens (6) Roof Ridge Boards (2) Rafters (6) 41 3/4” Long Rafters 3/4” thick Ridge Board 1/2” thick Soffit Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 17...
- Page 18 Important: Pilot Hole Ridge Board and Soffit prior to screwing to prevent splitting! Ridge Board Soffit Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 18...
- Page 19 Gable framing and soffit will sit approximately 1/4” away from Soffit should sit wall panels. approx. 1/4” away from wall panel Rafter should rest Gable Notch on gable framing. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 19...
- Page 20 Attach middle Rafter to Side Wall Top Plate inside of shed using 1 - 2 1/2” Brown Screws angled upward. Complete attachment of oppposite middle Rafter. Hardware 2 1/2” Brown Screws x 2 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 20...
- Page 21 Important: Pre-drill Batten Spacers with 1/8” bit before fastening. 1/4” from front edge of Rafter Hardware (Step 35 - 39) 1 1/4” Brown Screws x 34 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 21...
- Page 22 Battens. Overhang bottom of Metal Roof Panels approximately 2” past the edge of the Batten. Overhang the Metal Roof Panels past the Battens on the sides by approximately 1”- 3” depending on your personal preference. Panels will overlap. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 22...
- Page 23 Insert Foam Enclosures between Metal Roof Panels and Battens at Foam Enclosures the side. Enclosures may need to be snipped down in length to fit. Enclosures will prevent moisture and unwanted bugs, etc. from entering your shed through here. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 23...
- Page 24 Complete the opposite side of the Roof with 2 remaining Metal Roof Panels and 2 Foam Enclosures, following Steps 40 - 43. Parts Hardware Metal Roof Panel (44”) x 2 2” Metal Roof Screws x 6 Foam Enclosures x 2 1/4” Nut Driver x 1 Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 24...
-
Page 25: Miscellaneous Section
Check the wall seams for visible gaps prior to attaching Filler Trim and apply caulk where needed. Caulking gaps will help prevent moisture from entering and will help the longevity of your shed. Caulking not included in kit. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 25... - Page 26 Lower Side Skirting (1/2” x 2 1/2” x 33”) x 2 Lower Rear Skirting (1/2” x 2 1/2” x 35”) x 2 Hardware (Step 47 - 48) 1 1/2” Finishing Nails x 24 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 26...
- Page 27 (5/8” x 1” x 69 1/2”) Locate Front Top Plate Filler Strip. Position Front Top Plate Filler Strip onto Front Top Plate. Evenly space from side to side. Secure with 6 - 1 1/2” Finishing Nails into Front Top Plate. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 28 Parts Upper Horizontal Side Wall Filler Trims (5/8” x 1” x 32”) x 2 Hardware 1 1/4” Screws x 12 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 28...
- Page 29 3 1/2” wide. Align bottoms of both Corner Trim pieces flush. Front Side Corner Trim 2 1/2” Wide. Hardware 1 1/2” Finishing Nails x 12 total Hardware 1 1/2” Finishing Nails x 4 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 29...
- Page 30 Side Corner Trim will cap Rear Wide Corner Trim Rear Wide Corner Trim Hardware 1 1/2” Finishing Nails x 6 total Tight Underneath Upper Rear Hardware Rear Center Trim Horizontal Trim 1 1/2” Finishing Nails x 6 total Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 30...
- Page 31 (3/4” x 3 1/2” x 39”) x 2 Front Fascia caps Side Fascia. Attach remaining Front and Rear Fascia to Nailing Strips and attach remaining Side Fascia to Rafter ends as per Step 60. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 31...
- Page 32 Front Header Filler Strip. Attach with 6 - 1 1/2” Finishing Nails. Butt Locate Door Threshold and position on Floor at the opening. Align tip of the bevel flush with the outside of Bottom Wall Plate. Attach with 4 - 1 1/4” Brown Screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 32...
- Page 33 If out slightly, make sure top horizontal trim and Flange are even. Pre-drill with 1/8” bit to prevent wood from splitting. Attach with 6 - 1” Silver Screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 34 Choose desired Handle height. completely secure Hinges to Vertical Door Frame Trim with two more 2” Black Headed Screws per Hinge. Drill pilot holes to prevent wood from splitting. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 34...
- Page 35 Stop Position the Interior Silver Barrel Bolt on the Plywood Spacer and attach with 4 - 3/4” Silver Screws. Tap Silver Barrel Bolt with hammer on underside of Interior Door Header to mark location. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 35...
- Page 36 Wall Framing Parts (Step 75 - 76) Interior Vertical Door Stops (3/4” x 3/4” x 29 7/8”) x 4 Interior Door Stops Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 36...
- Page 37 6 - 2” Metal Screws, using 1/4” Nut Driver as per Step 41. Screw into top most Batten on each side. Metal screws are self-tapping, do not overtighten! Parts Metal Roof Ridge Cap (44 1/2”) Foam Enclosures x 4 Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 37...
- Page 38 Locate Metal Roof Edge Trim and fit along the lower edge of the Metal Roof. When the edging is in place, use pliers to cut the end to the desired length. Complete on both sides. Parts Metal Roof Edge Trim (54”) x 2 Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 38...
- Page 39 6x3 Space Master! We hope your experience constructing our 6x3 Space Master has been both positive and rewarding. We value your feedback and would like to hear back from you on how well we are doing in the following areas: 1.
