Axopar 29 XC CROSS CABIN 2024 Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
OWNER'S
MANUAL
AXOPAR 29 XC CROSS CABIN
MODEL YEAR 2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the 29 XC CROSS CABIN 2024 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Axopar 29 XC CROSS CABIN 2024

Summary of Contents for Axopar 29 XC CROSS CABIN 2024

  • Page 1 OWNER’S MANUAL AXOPAR 29 XC CROSS CABIN MODEL YEAR 2024...

  • Page 2: Table Of Contents

    4.1.2 Openings in the hull and deck....................30 4.1.3 Bilge system.......................... 33 4.1.3.1 Bilge pumps......................34 4.2 Technical systems..........................34 4.2.1 Electrical system........................34 4.2.2 12 V system.......................... 35 Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 1...
  • Page 3 6.1.6 Starting the engine........................ 57 6.2 Swivel seat - Driver and passenger seats..................58 6.3 Inspecting the boat.......................... 59 6.3.1 Checklist: Regular inspection before leaving harbor.............59 Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...
  • Page 4 7.10.1 Deposits..........................74 7.10.2 Scratches and nicks......................74 7.10.3 Stains........................... 75 7.10.4 Deep marks, gouges and holes..................75 8 Environment......................76 8.1 Requirements for North America.....................76 Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 3...
  • Page 5 10.2 Fuel system: USA (EPA)....................... 84 11 Appendix III: Electrical diagrams................85 12 Appendix IV: AIS Decontamination – North America..........86 13 Appendix V: Strapping and transport..............87 Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 6: Introduction

    Hazard is defined as a source of potential injury to a person. All abnormal use is forbidden, including disregarding information on safety. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 7: Document Conventions

    1.4 Copyright Copyright ©2024 Axopar Boats. All rights reserved. This Owner's Manual is protected by copyright controlled by Axopar Boats. This manual cannot be wholly or partly reproduced without prior written authorization by Axopar Boats. This material also contains confidential information, which may not be disclosed to others without the prior written consent of Axopar Boats.

  • Page 8: Warranty

    1 Introduction Axopar Boats makes no representations and warranties with respect to this manual, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. 1.6 Warranty The Limited Warranty for the boat and the relevant contact information are enclosed as a separate document.

  • Page 9: Safety

    The boat must always be operated at speeds that will not put people or property in danger. • The captain must constantly be aware of conditions surrounding the boat when underway and especially before sharp turns. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...
  • Page 10 Do not go out boating in severe weather conditions as this might lead to serious DANGER injuries or death. Always get back to shore before the weather turns bad. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 11: Safety Diagram

    Always put down the fire by depriving the fire of oxygen. WARNING Do not use water! Using water in fire involving flammable liquids can spread the liquid and make the fire worse. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 10...

  • Page 12: Fire Control Equipment

    2.3.2 Boat owners' and users' responsibilities It is your responsibility as the boat owner and user to ensure that the fire control equipment is accessible at all times. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 13: Checklist: Fire In The Engine

    If you can smell engine or generator exhaust, you are inhaling CO. CO can also be present without the smell of exhaust fumes. If the CO alarm is activated, make sure all persons onboard exit the closed spaces. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 14: Carbon Monoxide Monitor

    With regular intervals, check that the monitor system is functioning. For instructions, see the equipment manufacturer's manual. • It is not possible to turn the CO monitor off when the boat is in use. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 15: Audible Signal

    If smoke density increases during hush or silence period, the device will automatically return to alarm mode. Smoke alarms should be replaced at minimum every 5 years. Figure 2.1 Smoke alarm Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 16: Life Raft

    Follow the life raft manufacturer’s instructions. 2.8 Safety labels on board The following picture and table present the location and description of the safety labels on board. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...
  • Page 17 Caution If switch is turned off while engine is running the alternator will be damaged. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 16...
  • Page 18 - Electrical equipment (Lights, horn, pump, etc?) - Emergency gear (Fire extinguisher, bailer, paddle, anchor & line, signaling device, tool kit, etc.?) Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 17...
  • Page 19 No ventilation is provided. Fuel vapors are a fire and explosion hazard. To avoid injury and death, do not store fuel or flammable liquids here. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...
  • Page 20 Emergency exit Danger Fore and aft sun pads should not be used when vessel is under way. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 19...
  • Page 21 (E-85). Open flame appliances can ignite gasoline vapors causing death or injuries from the fire or explosion. Turn off all open flame appliances when refueling. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...
  • Page 22 -Shut off engines while people are in the water near the boat, on the swim platform, or on the boarding ladder. -Never operate in reverse toward a person in the water. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 21...
  • Page 23 Avoid personal injury. Stay inside deck rails (and gates) when boat is underway. Warning Keep hands out of machinery. Follow up instructions for remote control enabling. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 22...

  • Page 24: Product Overview

    Manufacturing month • A = January • B = February • C = March • etc. Last digit of the manufacturing year Model year Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 23...

  • Page 25: Builder's Plate

    Maximum engine power • Maximum engine weight 3.4 CE certification The category is determined according to the maximum number of persons allowed onboard. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 24...

  • Page 26: Dimensions And Weight

    US units Maximum recommended engine 298 kW 400 hp power Maximum recommended power with 2 x 148 kW 2 x 200 hp twin engines Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 25...
  • Page 27 1488 lb persons Personal luggage 80 kg 176 lb 80 kg 176 lb Life raft weight 50 kg 110 lb 50 kg 110 lb Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 26...

  • Page 28: Boat Layout

    The standard boat has a flat aft deck with stowage underneath. The stowage can be replaced with optional extra equipment such as an aft cabin, a storage bench or a wetbar. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 29 Optional fender box wetbar Optional seatbase refridgerator and sink Multicabin or optional toilet Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 28...

  • Page 30: Product Description

    The deck of the boat has been designed to allow the water to drain straight into the sea via the water gullies. Do not close the drain holes when using the boat. CAUTION Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 31: Openings In The Hull And Deck

    In certain conditions and speeds, it is possible that water is sprayed inside through canopies, hatches or other openings, due to negative pressure or other effects. Risk for this can be minimized by closing the canopies, hatches or other openings. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 32 Inspection hatches Fuel tank compartment inspection hatch (10) Multicabin The location and number of these components depend on the level of the equipment on the boat. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...
  • Page 33 Black water tank seacock Manual front bilge pump outlet Fresh water and black water tank vents Electric front bilge pump outlet Heater exhaust Transducer Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 32...

  • Page 34: Bilge System

    Water can flow through the strainer, and there is no muck or material restricting the water flow. Clean the strainer by pushing the lock tabs in the pump motor and lifting the motor unit off. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 35: Bilge Pumps

    Risks of fire, explosion and electric shock! WARNING Improper use of electric DC and AC systems may result in fire, explosion or electric shock. Follow the instructions carefully. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 34...

  • Page 36: System

    Never leave the boat unattended with the electrical system energized, except automatic bilge pump, fire protection, and alarm circuits. • Maintain any damaged equipment before taking it back to use. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 37: Main Switches

    Aux switch to the On position. Main switch panel Start batteries Service battery Optional second engine main switch Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 36...

  • Page 38: Direct Supply Fuses

    The fuses are in the form of trip switches that break the circuit and spring up when tripped. Do not reset the switch before you have found out the reason for the breaker tripping. After that press the switch back down. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 39: Heavy Duty Fuses

    If the metal strip is damaged, contact a qualified nautical electrician. If it is necessary to open the cover, make sure that all the current cables from the batteries are disconnected. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 40: Batteries

    The top of the batteries needs to be cleaned regularly to avoid current leakage between the cells. If the battery is located in a separate area, it is normally sufficient to clean it in the spring and autumn. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 41: 110/230 V System

    If the earth fault breaker is tripped, disconnect the shore power cable immediately. In such a case contact a qualified electrician for repairs before the system is used again. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 42: Fuel System

    EPA fuel system is equipped with an automatic fuel valve. • The inlet pipe for fuel is located in the starboard side of the deck. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 43: Refueling The Boat

    Never use a wrong type of fuel in the heater or cooker as this may damage them. • Never use an open flame when detecting leaks. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 44: Maintaining The Fuel System

    Switch the system off when leaving the boat. Do not forget to check filter in the pump regularly. The dealer is responsible for disinfecting the fresh water tank before sale. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 45 The water pump has air release valve which should be slightly opened to facilitate priming when starting the pump or emptying the tank. Once the pump operates normally, the valve should be closed. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 46 Water pump inlet filter is recommended to be checked and cleaned annually. Running the system regularly helps keep the water pump’s impellers in working order. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 47: Septic System

    Using the electrical toilet The electrical toilet is used with a separate operating switch. For more information on the device, see the manual for the toilet. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 48: Septic Tank

    The heater unit is located port side, midship, under the deck. It is accessible through the hatch from inside the wheelhouse. There are closable heating vents in the wheelhouse aft area and in multicabin. The operation panel is located in the pilothouse port wall. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 49: Navigation System

    The bow thruster is powered by the Aux battery. The batteries must be disconnected from the electronic circuit before changing a fuse. For more information, see the manufacturer’s manual. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 50: Anchor Windlass

    The anchor and the chain cannot damage the boat when lowered. • The anchor and anchor chain cannot hit any person. For more information, see the manufacturer’s manual. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 51: Roof Racks

    Load limit of roof racks is 25 kg / 55 lbs per roof half. Max. load of roof racks is 40 kg / 88 lbs. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 52: Transportation

    Risk of damage to the hull. CAUTION Do not lift the boat with a forklift. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 51...

  • Page 53: Transporting And Storing The Boat

    Make sure that there is a sufficient number of supports to distribute the weight properly without excessive point loads, and the capacity and dimensions of the trailer are sufficient to carry the boat and its engine, Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 54 A hood or other cover flapping in the wind during trailering can damage the boat surface. ◦ Keep the hood in its dedicated storage compartment during trailering, or remove the hood completely, if necessary. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 55: Operation

    The controllers are situated so that the driver can easily manage them from the steering console. The location and quantity of the devices depend on what optional equipment and engine models have been chosen. See the device manuals for further information on the devices. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 56 Heater control (optional) (Moved to port side) VHF radio Audio remote (optional) Trim tabs control Bow thruster control Remote main switches (10) Engine remote control Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 55...

  • Page 57: Steering Console Switch Panel

    Check the oil level in the pump before casting off. • For detailed instructions and the steering system oil recommendation, see the manufacturer's documentation. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 56...

  • Page 58: Steering Maintenance

    1. Set the engine lever in neutral. 2. Turn the ignition on and check the fuel level. 3. Start the engine by turning the ignition key. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 59: Swivel Seat - Driver And Passenger Seats

    The locking handles must be in the locked position before the boat speed exceed DANGER 5 knots. Rotation locking handle Moving locking handle Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 58...

  • Page 60: Inspecting The Boat

    The specified tank capacity is not necessarily fully available, depending on the WARNING trim and load on board. The tank must always be kept at least 20% full. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...
  • Page 61 A big leak may cause the boat to sink quickly. Do not go or stay in and WARNING wear a life jacket. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 62: Leaving The Jetty

    Gather in all lines and fenders while you are still in sheltered water. A rope around CAUTION the propeller can disable a boat. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 63: Driving The Boat

    6.4.3.2 Driving at high speed Although the boats have passed the CE requirements for swerve tests at full speed, Axopar Boats does not recommend making sharp turns at high speed. When exceeding a certain speed limit any hull construction might lose its grip.

  • Page 64: Driving In Rough Seas

    In difficult wind and current conditions, more revs might be necessary to make full use of the power of the engine. In these conditions, it is important that maneuvers are made quickly and precisely to prevent the boat from drifting into trouble for example. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 65: Using The Trim Tabs

    Lowering the trim tab on the windward side brings the boat back into normal attitude. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 66 A revolving propeller is life-threatening to a swimmer or a person who has fallen DANGER overboard. • Use the dead man’s switch. • Turn off the engine when someone is climbing on board. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 65...
  • Page 67 Then the boat can be maneuvered straight ahead since the wind helps hold the boat on a straight course. It is good to have Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 68 • Always remember that the stability of the boat may decrease when being towed. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 67...

  • Page 69: Maintenance

    Severe scratches, discoloration or oxidation may require wet sanding before buffing, polishing and vaxing. Wet sanding is recommended to be performed by an Axopar dealer or a trained professional. • When the boat is not in use, keep the gelcoat surface out of the sun or cover the boat with a canvas tarpaulin.
  • Page 70 Buff in circular motions until the surface is glossy. 3. Wax the surface. Wet sanding Wet sanding is recommended to be performed by an Axopar dealer or a trained NOTICE professional. Axopar 29 XC Cross Cabin 2024...
  • Page 71 If different antifouling paints are used, there is a risk that the composition of the paints are incompatible, preventing the antifouling paint from working. Contact your nearest Axopar dealer in antifouling repainting and condition inspection related matters. Axopar 29 XC Cross Cabin 2024...
  • Page 72 New covers may leak initially, as the seams need to swell. During use To prevent quick deterioration of the cover, secure it tightly in a folded-up position to prevent flapping. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 73: Cleaning The Cover

    All underwater metal parts need to be inspected annually for signs of corrosion. Additionally, underwater thru-hulls and seacocks are recommended to be replaced every 5 years. Please refer to chapter for more details. Preventing corrosion Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 72...

  • Page 74: Preventing Corrosion

    • Make sure that there is no water beneath the fuel tank. Any water present can be extracted using the suction pipe that is attached to the tank's exterior. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 75: Corrective Maintenance

    For the best result, wax the surface after treating it with the rubbing compound. 7.10.2 Scratches and nicks Most scratches and nicks can be removed by using a rubbing compound followed by waxing. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 76 NOTICE water or chemicals should be avoided. Failure to observe this precaution may result in extensive and potentially costly damage to the underlying laminate structure. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...
  • Page 77 They also state that waters where a Coast Guard-certified marine sanitation device permitting discharge is allowed include coastal waters and estuaries, the Great Lakes and interconnected waterways, Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 78 8 Environment freshwater lakes and impoundments accessible through locks, and other flowing waters that are navigable interstate by vessels subject to this regulation (40 CFR 140.3). Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...

  • Page 79: Appendix I: Checklists

    If the leak is small, the boat is detached and at least one of the engines is functioning, drive to the nearest shore to prevent the boat from sinking. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 80 The specified tank capacity is not necessarily fully available, depending on the WARNING trim and load on board. The tank must always be kept at least 20% full. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats...
  • Page 81 7. Let out the anchor line equal to at least three times the depth of the water. 8. Put the engine in astern to check that the anchor has taken hold (only when bow anchoring). Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 82 4. If there are small scratches on the hull or if some of the surface gelcoat has lost its shine, use a rubbing compound on these areas before polishing. 5. Paint the bottom with antifouling paint. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...
  • Page 83 11. Check that the seacocks are tight and in order, check for any frost damage. 12. Check all pipes, hoses and cocks. 13. Make a note of any frost damage. Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual ©...

  • Page 84: Appendix Ii: Fuel System

    10 Appendix II: Fuel system 10 Appendix II: Fuel system 10.1 Fuel system: EU Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 83...
  • Page 85 1300 This document and the information contained in it is proprietary and confidential information of Axopar Boats Oy. Neither this document nor any of the information contained herein may be reproduced, disclosed to others, or used for any purpose other than for the purpose it has been provided without the prior written permission of Axopar Boats Oy.
  • Page 86 1/2") This document and the information contained in it is proprietary and confidential information of Axopar Boats Oy. Neither this document nor any of the information contained herein may be reproduced, disclosed to others, or used for any purpose other than for the purpose it has been provided without the prior written permission of Axopar Boats Oy.

  • Page 87: Section A-Ascale

    AXO0000270 This document and the information contained in it is proprietary and confidential information of Axopar Boats Oy. Neither this document nor any of the information contained herein may be reproduced, disclosed to others, or used for any purpose other than for the purpose it has been provided without the prior written permission of Axopar Boats Oy.
  • Page 88 10 Appendix II: Fuel system 10.2 Fuel system: USA (EPA) Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 84...
  • Page 89 0.27 This document and the information contained in it is proprietary and confidential information of Axopar Boats Oy. Neither this document nor any of the information contained herein may be reproduced, disclosed to others, or used for any purpose other than for the purpose it has been provided without the prior written permission of Axopar Boats Oy.
  • Page 90 1/2") This document and the information contained in it is proprietary and confidential information of Axopar Boats Oy. Neither this document nor any of the information contained herein may be reproduced, disclosed to others, or used for any purpose other than for the purpose it has been provided without the prior written permission of Axopar Boats Oy.

  • Page 91: Section B-Bscale

    AXO0000270 This document and the information contained in it is proprietary and confidential information of Axopar Boats Oy. Neither this document nor any of the information contained herein may be reproduced, disclosed to others, or used for any purpose other than for the purpose it has been provided without the prior written permission of Axopar Boats Oy.

  • Page 92: Appendix Iii: Electrical Diagrams

    11 Appendix III: Electrical diagrams 11 Appendix III: Electrical diagrams Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 85...
  • Page 93 26895 - Galvanic Isolator 30A, 120/240 VAC - ProSafe FS30 39018 - AC GROUNDING CABLE EURO - 1000CM 6mm2 WITH TUBE 38696 - Axopar 28 SHORE POWER CENTER EU - 4pcs VKL500-O2P - CONNECTION CABLE 500CM IP68 1,5 mm2 WITH TUBE -...
  • Page 94 26895 - Galvanic Isolator 30A, 120/240 VAC - ProSafe FS30 39017 - AC GROUNDING CABLE US - 1000cm AWG 10 WITH TUBE 38697 - Axopar 28 SHORE POWER CENTER US - 39015 - 10m RST CONNECTION CABLE, AWG14 - USA -...
  • Page 95 -PE_SHIP -PE_SHIP -PE_SHIP -PE_SHIP YELLOW/GREEN_2.5 PE_SHIP CABLE3 CABLE4 CABLE5 CABLE2 -AC_X2 -AC_X3 -AC_X4 -AC_X5 Axopar 11.4.2023 Date Drawing by Boat Sub-product code Product code Project ID SHORE POWER Sheet rev. CENTER EU Copyright by Date of modification Modified by Description Project rev.
  • Page 96 50MM 27161 -AC_X1 SHRINKTUBE 50MM 27161 22981 SHRINKTUBE -AC_X2 -AC_X3 -AC_X4 -AC_X5 22980 22980 22980 22980 Axopar 11.4.2023 Date 38696 Drawing by Boat Sub-product code Product code Project ID SHORE POWER Sheet rev. CENTER EU Copyright by Date of modification...
  • Page 97 AC_F2 AC_F3 AC_F4 ADD TEXTS WITH DYMO INCLUDE LABEL REVERSE POWER MAIN RCBO BATT CH OUTLET STOVE POLARITY Axopar 11.4.2023 Date 38696 Drawing by Boat Sub-product code Product code Project ID SHORE POWER Sheet rev. CENTER EU Copyright by Date of modification...
  • Page 98 Axopar 27.4.2023 Date 38696 Drawing by Boat Sub-product code Product code Project ID SHORE POWER Sheet rev. CENTER EU Copyright by Date of modification Modified by Description Project rev. Boat model Title Sheet...
  • Page 99 AWG12 UL 1426 Green PE_SHIP AWG14 UL 1426 Green PE_SHIP -AC_X2 -AC_X3 -AC_X4 -AC_X5 35778 35778 35778 38605 Axopar 11.4.2023 Date Drawing by Boat Sub-product code Product code Project ID SHORE POWER Sheet rev. CENTER US Copyright by Date of modification...
  • Page 100 35778 38605 23345 2300 mm 2000 mm 24625 24625 50MM 27161 50MM 27161 SHRINKTUBE SHRINKTUBE -AC_X1 38207 Axopar 11.4.2023 Date 38697 Drawing by Boat Sub-product code Product code Project ID SHORE POWER Sheet rev. CENTER US Copyright by Date of modification...
  • Page 101 AC_RCD1 AC_F2 AC_F3 AC_F4 ADD TEXTS WITH DYMO INCLUDE LABEL REVERSE POWER MAIN BATT CH OUTLET STOVE POLARITY Axopar 11.4.2023 Date 38697 Drawing by Boat Sub-product code Product code Project ID SHORE POWER Sheet rev. CENTER US Copyright by Date of modification...
  • Page 102 Axopar 27.4.2023 Date 38697 Drawing by Boat Sub-product code Product code Project ID SHORE POWER Sheet rev. CENTER US Copyright by Date of modification Modified by Description Project rev. Boat model Title Sheet...
  • Page 103 BPF_AUTO -M3:- YELLOW_2.5 RED_2.5 -X.7B:3 Auto. 800 mm 1200 mm INPUT- 2634610 YELLOW_2.5 -X.7B:5 (6N BACK VIEW) 2634610 Axopar 6.4.2023 Date 38689 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 HULL HARNESS Sheet rev. Copyright by...
  • Page 104 -X.D1:2 -A12d TRIM_IG_KEY TRIM_IG_KEY -D2:2, -D1:2 BLUE/YELLOW_1.5 BLUE/YELLOW_1.5 Shrink tube 2634310 2635310 (3NT BACK VIEW) Shrink tube (3UT BACK VIEW) Axopar 24.4.2023 Date 38690 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 DECK HARNESS Sheet rev.
  • Page 105 -H23:+ WHITE/GREY_1.5 1700 mm INPUT- -H23:- YELLOW_1.5 -A8B#1 USB OUTLET -X.2B:6 RED_1.5 2200 mm INPUT- -XJGND3.2:3.1 YELLOW_1.5 Axopar 24.4.2023 Date 38690 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 DECK HARNESS Sheet rev. Copyright by Date of modification...
  • Page 106 INPUT- -H27:- YELLOW_1.5 DECK LIGHT -H27#1 DECK_LT -H26:+, -H28:+ WHITE/GREY_1.5,WHITE/GREY_1.5 700 mm 500 mm INPUT- -H26:-, -H28:- YELLOW_1.5,YELLOW_1.5 Axopar 24.4.2023 Date 38690 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 DECK HARNESS Sheet rev. Copyright by...
  • Page 107 2634310 HA_MS_IND RED_1.5 -X5C:2 -H29#1 DECK LIGHT 2634310 DECK_LT WHITE/GREY_1.5 -X.2D:5 700 mm INPUT- YELLOW_1.5 -XJGND3.1:10.2 Axopar 24.4.2023 Date 38690 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 DECK HARNESS Sheet rev. Copyright by Date of modification...
  • Page 108 -SIG1#1 PORT_IG TRIM_IG_KEY TRIM_IG_KEY -X.D1:2 BLUE/YELLOW_1.5 BLUE/YELLOW_1.5 -A12d -D2#1 P600G 2635310 2634310 (3NT BACK VIEW) (3UT BACK VIEW) Axopar 24.4.2023 Date 38690 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 DECK HARNESS Sheet rev. Copyright by...
  • Page 109 -H33#1 DECK LIGHT DECK_LT -H32:+ WHITE/GREY_1.5 1600 mm 1100 mm 1200 mm 600 mm INPUT- -H32:- YELLOW_1.5 /29.F1 Axopar 24.4.2023 Date 38690 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 DECK HARNESS Sheet rev. Copyright by...
  • Page 110 -LS6:1 PURPLE_1.5 -X.9A:6 YELLOW_4 Z2_R- -LS6:2 PURPLE/BLACK_1.5 (6N BACK VIEW) 2635310 2635410 100 mm 500 mm 2634610 Axopar 22.3.2023 Date 38691 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 ROOF HARNESS XC Sheet rev. Copyright by...
  • Page 111 1000 mm 1000 mm (3UT BACK VIEW) AC_LT_OUT BILGE_ALM_IN 38911 LIGHT SWITCH -H16:+, -H17:+ RED_1.5,RED_1.5 RED_1.5 -X.8:8 2635310 2637810 2635310 Axopar 27.3.2023 Date 38692 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 AFT CABIN HARNESS Sheet rev.
  • Page 112 -SH:1 -X.SH:1 LT_IN RED_1.5 RED_1.5 300 mm LT_OUT -SH:3 -X.SH:2 LT_OUT YELLOW_1.5 YELLOW_1.5 (2NT BACK VIEW) 2637710 Axopar 26.4.2023 Date 38911 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 LIGHT SWITCH Sheet rev. Copyright by Date of modification...
  • Page 113 -Q1:GND -XJGND1:1 INPUT- -XJGND3.1:1 -XJGND1:1 INPUT- YELLOW_2.5 YELLOW_2.5 YELLOW_50 YELLOW_50 3560.02 RSB 7901 50/10 50/6 Axopar 20.3.2023 Date 38677 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 BATTERY CABLES Sheet rev. Copyright by Date of modification...
  • Page 114 -XJGND1#1 -Q2#1 MAIN NEG BUSBAR STB ISOLATOR 2000 mm INPUT- INPUT- -Q2:GND -XJGND1:1 YELLOW_2.5 YELLOW_2.5 3560.02 RSB 7901 Axopar 20.3.2023 Date 38678 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 DUAL ENGINE Sheet rev. BATTERY CABLES...
  • Page 115 16/8 -A32#1 -XJGND1#1 BATTERY CHARGER MAIN NEG BUSBAR 800 mm INPUT- -XJGND1:1 -A32:GND INPUT- YELLOW_16 YELLOW_16 16/6 16/10 Axopar 20.3.2023 Date 38679 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 CHARGER CABLES Sheet rev. Copyright by...
  • Page 116 -XJGND2#1 MAIN NEG BUSBAR BTH NEG BUSBAR 95/10L 95/10 10000 mm INPUT- -XJGND2:1 -XJGND1:1 INPUT- YELLOW_70 YELLOW_70 70/10 70/10L Axopar 22.3.2023 Date 38680 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 BOW THRUSTER Sheet rev. CABLES...
  • Page 117 RED_6 WOOF+ WOOFER- -LS9:2 BLACK_6 WOOF- WOOFER -LS9#1 WOOFER+ -A29:WOOF+ RED_6 4000 mm WOOFER- -A29:WOOF- BLACK_6 Axopar 23.3.2023 Date 38681 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 AUDIO UPGRADE Sheet rev. CABLES Copyright by Date of modification...
  • Page 118 NOTICE! CABLES WITH STICKER FOR EXAMPLE POINT -A- LABEL 23655 Battery Combiner 80A, 2 batteries Victron BCD 802 INPUT OUTPUT INPUT Axopar 3.4.2023 Date 38698 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 POWER STEER Sheet rev.
  • Page 119 -KM9:OUT- WINCH_NEG YELLOW_35 YELLOW_35 YELLOW_35 YELLOW_35 OUT- 35/10 35/8 35/8 35/6 INCLUDED, CUSTOMER INSTALLS TO BOW THRUSTER UNIT Axopar 3.4.2023 Date 38699 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 BOW ANCHOR Sheet rev. WINCH CABLES...
  • Page 120 RED_1.5 2638010 300 mm (11U BACK VIEW) 2638010 -S101#1 -S102#1 -S103#1 701-MD 701-MD 701-MD S101 S102 S103 Axopar 23.3.2023 Date 38682 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 MAIN SWITCH UNIT Sheet rev. REMOTE Copyright by...
  • Page 121 3. 6pcs 6440 - HOLKKI NAVIX PÄÄKYTKIMEEN - halk. 8/6mm pituus 16mm 4. 6pcs VMI31540 - Spring Lock Washer M5 DIN127 5. 3pcs 14002110K Remote Controlled Battery Switch 6. 6pcs VMI31538 - HEX Nut M5 DIN934 16.05.-22 / TE Axopar 23.3.2023 Date 38682 2004468...
  • Page 122 S101 S102 S103 -S101#1 -S102#1 -S103#1 701-PM 701-PM 701-PM Axopar 23.3.2023 Date 38683 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 MAIN SWITCH UNIT Sheet rev. MANUAL Copyright by Date of modification Modified by Description Project rev.
  • Page 123 1. 6pcs VMI31807 - Countersunk head Screw HEX socket M5X25 DIN7991 2. 1pc 39053_AXOPAR_28_MSU_PANEL 3. 3pcs 701-PM - Battery Main Switch 275A, Panel Mounted - Bep 701B-PM 4. 6pcs VMI31539 - Self-locking HEX Nut M5 DIN985 16.05.-22 / TE Axopar 23.3.2023 Date 38683 2004468...
  • Page 124 -S102:GN SERV_MS_IND -S102:RD -X1A 2638010 300 mm (11U BACK VIEW) 2638010 -S101#1 -S102#1 701-MD 701-MD S101 S102 Axopar 25.4.2023 Date 38909 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 MAIN SWITCH UNIT Sheet rev. REMOTE SE...
  • Page 125 6. 4pcs VMI31540 - Spring Lock Washer M5 DIN127 7. 2pcs VMI31539 - Self-locking HEX Nut M5 DIN985 8. 2pcs 14002110K Remote Controlled Battery Switch 9. 4pcs VMI31538 - HEX Nut M5 DIN934 16.05.-22 / TE Axopar 25.4.2023 Date 38909 2004468...
  • Page 126 S101 S102 -S101#1 -S102#1 701-PM 701-PM Axopar 25.4.2023 Date 38910 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 MAIN SWITCH UNIT Sheet rev. MANUAL SE Copyright by Date of modification Modified by Description Project rev. Boat model...
  • Page 127 2. 2pcs VMI31796 - Countersunk head Screw HEX socket M5X16 DIN7991 3. 1pc 39053_AXOPAR_28_MSU_PANEL 4. 2pcs 701-PM - Battery Main Switch 275A, Panel Mounted - Bep 701B-PM 5. 1pc 39054_NAVIX_MS_PLUG_BEP_HPL 6. 6pcs VMI31539 - Self-locking HEX Nut M5 DIN985 16.05.-22 / TE Axopar 25.4.2023 Date 38910 2004468 Drawing by...
  • Page 128 1pc VMI32011 SPRING LOCK WASHER M8 DIN127 16.05.-23 / TE 3. 3pcs VMI30917 COUNTERSUNK HEAD SCREW HEX SOCKET M4X16 DIN7991 4. 1pc VMI32019 - HEX Bolt Full thread M8X30 DIN933 5. 1pc 39047_NAVIX_LINE_CUBE_FUSE_HOLDER_SINGLE Axopar 3.4.2023 Date 38684 2004468 Drawing by...
  • Page 129 F111 From Q1 port isolator F112 OPT From Q2 stb isolator F113 OPT From battery charger F114 OPT APS or POWER STEERING PUMP F115 OPT APS or POWER STEERING PUMP F116 OPT APS Axopar 23.3.2023 Date 38684 2004468 Drawing by...
  • Page 130 FRONT VIEW Axopar 4.4.2023 Date 38685 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 FUSE UNIT Sheet rev. Copyright by Date of modification Modified by Description Project rev. Boat model Title Sheet...
  • Page 131 1 PC VMI32011 SPRING LOCK WASHER M8 DIN127 2 PCS VMI30944 - HEX socket Head Cap Screw M4X12 DIN912 2 PCS VMI30906 - Flat Washer for HEX bolts and nuts M4 DIN125A 23.05.2023 / TE (2004468) Axopar 8.5.2023 Date 38685...
  • Page 132 INPUT- YELLOW_1.5 -X2D:4, -X2D:5 DECK_LT WHITE/GREY_1.5,WHITE/GREY_1.5 -F228:2 DECK_LT_IN WHITE/GREY_1.5 -X11B:1 DECK_LT_C WHITE_1.5 19734 19734 -K205 Axopar 24.3.2023 Date 38685 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 FUSE UNIT Sheet rev. Copyright by Date of modification...
  • Page 133 (8U BACK VIEW) (8U BACK VIEW) 2635810 2635810 2638010 2638010 2638010 2638010 (11U BACK VIEW) (11U BACK VIEW) (11U BACK VIEW) (11U BACK VIEW) Axopar 17.4.2023 Date 38685 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 FUSE UNIT Sheet rev.
  • Page 134 (3UT BACK VIEW) 2635310 (8N BACK VIEW) (8N BACK VIEW) 2638010 -XJGND6.1#1 -XJGND6.2#1 -XJGND6.3#1 12743 12743 12743 (11U BACK VIEW) Axopar 23.3.2023 Date 38686 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 SWITCH PANEL Sheet rev.
  • Page 135 4. 11PCS HALO SWITCH NUT 01.06.2023 / TE (2004468) -S301 -S302 -S303 -S304 -S305 -S306 -S307 -S308 -S309 -S310 -S311 Axopar 19.4.2023 Date 38686 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 SWITCH PANEL Sheet rev.
  • Page 136 GREY/BLACK_1.5 -X.5A ENG1_MS_C -S501:2 GREY/GREEN_1.5 ENG1_MS_IND 2634610 -S501:+8 RED_1.5 (6N BACK VIEW) INPUT- -S501:3 GREY/BLACK_1.5 2634610 Axopar 27.3.2023 Date 38687 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 MAIN SWITCH Sheet rev. CONTROL PANEL Copyright by...
  • Page 137 38687_AXOPAR_28_MAIN_SWITCH_CONTROL_PANEL 1. 1PC 39252_AXOPAR_28_MAIN_SW_CONTROL_PANEL_(WOC) 2. 2PCS VHP PLUG (as in diagram) 4. 1PC 29867_NAVIX_LINE_START_STB_LABEL_FOR_16756_SPDT 3. 1PC 24147_NAVIX_LINE_SERVICE_LABEL_FOR_16756_SPDT 5. 2PCS 16756_SWITCH_CONTURA_SPDT (as in diagram) 01.06.-23 / TE (2004468) Axopar 8.5.2023 Date 38687 2004468 Drawing by Boat Sub-product code Product code Project ID...
  • Page 138 HA_MS_IND -X.5C:2 RED_1.5 -X.5C (3NT BACK VIEW) 2634310 -X.5C#1 HA_MS_C -S504:2 HA_MS_IND -S504:+8 INPUT- -S504:3 2634310 Axopar 27.3.2023 Date 38688 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 BOW THRUSTER UNIT Sheet rev. Copyright by Date of modification...
  • Page 139 PLACEMENT OF ELECTRICAL COMPONENTS -S401#1 701-MD (HOLDER RESERVED FOR BOW WINCH FUSE) LABEL: -XJGND2 V2501 -XS401 (3UT BACK VIEW) 2635310 Axopar 8.5.2023 Date 38688 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 BOW THRUSTER UNIT Sheet rev.
  • Page 140 2PCS VMI32013 FLAT WASHER FOR HEX BOLTS AND NUTS M8 DIN125A 2PCS VMI32011 SPRING LOCK WASHER M8 DIN127 2PCS VMI32012 HEX NUT M8 DIN934 4. 1PC 39048_NAVIX_LINE_BOLT_BASE_1X 5. 1PC 39269_NAVIX_LINE_BUS_BAR_TYPE5_BEP_RIGHT_2X_V1 6. - (AS IN DIAGRAM) Axopar 1.6.2023 Date 38688 2004468 Drawing by...
  • Page 141 7. 1PC 39265_AXOPAR_28_BOW_THRUSTER_UNIT_BASE_V1 8. 4PCS 36824_NAVIX_LINE_ANL_HOLDER_TYPE_SERIES_RAISER_V1 9. 1PC 39266_NAVIX_LINE_BOLT_BASE_1X_RISER_V1 10. 6PCS VMI30918 - Countersunk head Screw HEX socket M4X20 DIN7991 11. 4PCS VMI31819 - HEX socket Head Cap Screw M5X30 DIN912 Axopar 1.6.2023 Date 38688 2004468 Drawing by Boat Sub-product code...
  • Page 142 13. 9PCS VMI30918 - Countersunk head Screw HEX socket M4X20 DIN7991 14. 2PCS VMI30918 - Countersunk head Screw HEX socket M4X20 DIN7991 2PCS VMI35429 - Extension Bolt M4 L-70 15. 1PC 39262_AXOPAR_28_BOW_THRUSTER_UNIT_SIDE_WALL_1_V1 16. 1PC 39264_AXOPAR_28_BOW_THRUSTER_UNIT_BOTTOM_V1 Axopar 1.6.2023 Date 38688 2004468...
  • Page 143 19. - (AS IN DIAGRAM) 20. 4PCS VMI31817 - HEX socket Head Cap Screw M5X16 DIN912 21. 4PCS VMI30946 - HEX socket Head Cap Screw M4X20 DIN912 22. - (AS IN DIAGRAM) 31.5.2023 TS Axopar 1.6.2023 Date 38688 2004468 Drawing by...
  • Page 144 -D311:+ BPF_AUTO RED_1.5 -X.D3 -D312:+ BPA_AUTO RED_1.5 1400 mm (3NT BACK VIEW) 2634310 -D312:-, -D311:- INPUT- YELLOW_1.5,YELLOW_1.5 2634310 Axopar 22.5.2023 Date 38693 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 BILGE POWER Sheet rev. AVAILABILITY PANEL...
  • Page 145 38693_AXOPAR_28_BILGE_POWER_AVAILABILITY_PANEL 1. 2 pcs Led Indicator ø3/6mm, 12V, Chrome frame (as in diagram) 2. 1 pc 39184_AXOPAR_28_BILGE_POWER_AVAILABILITY_PANEL_(WOC)_V1 22.05.2023 / TE ( project 2004468 ) Axopar 22.5.2023 Date 38693 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 BILGE POWER Sheet rev.
  • Page 146 -X.H20:1 250 mm -X.H20 INPUT- INPUT- -H20:- YELLOW_0.75 YELLOW_0.75 -X.H20:2 JL-RCOB-480-40K-12V (2NT BACK VIEW) 2637710 2637710 880mm Axopar 29.5.2023 Date 39236 2004468 Drawing by Boat Sub-product code Product code Project ID 28 MK3 SWITCH PANEL Sheet rev. EXTENDED Copyright by...
  • Page 147 5. 1PC LED (AS IN DIAGRAM) 6. 1PC 39241_AXOPAR_28_SWITCH_PANEL_EXT_COVER 7. 6PCS VMI30912 - Countersunk Screw HEX socket head M4X6 DIN7991 DO NOT OVER TIGHTEN 01.06.2023 / TE (2004468) NOTICE. LED WIRING OUT FROM THIS END OF GROOVE Axopar 30.5.2023 Date 39236 2004468 Drawing by Boat...

  • Page 148: Appendix Iv: Ais Decontamination - North America

    America According to ABYC T-32 Design and Construction in Consideration of Aquatic Invasive Species 7/21 © 2021 American Boat & Yacht Council, Inc Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 86...
  • Page 149 Table of Contents Table of Contents 1 Decontamination criteria based on UMPS III, Table 3..........3 2 Example of AIS Owner's Manual Information............4 3 Additional boat-specific recommendations..............6 © 2021 Axopar Boats Page 2...
  • Page 150 When flushing engines with a dedicated connection (not muffs), the pressure should be limited to less than 60 psi to prevent internal engine damage. The maximum input temperature during flushing should not exceed 140°F. NOTE: Engine flushing relies on the exit temperature as a guideline for decontamination duration. © 2021 Axopar Boats Page 3...
  • Page 151 Completely drain all water from the boat and its compartments, including but not limited to the bilge, wells, lockers, ballast tanks or bags, bait containers, engines, and outdrives. Allow the boat to completely dry before visiting any other bodies of water. © 2021 Axopar Boats Page 4...
  • Page 152 2 Example of AIS Owner's Manual Information NOTE: Some localities may require inspection or decontamination before and/or after launching. Check state and local laws and regulations for requirements prior to traveling to go boating. © 2021 Axopar Boats Page 5...
  • Page 153 • Clean hull, trailer, intake grate, and steering nozzle, etc before leaving the water access. • Run engine 5-10 sec to blow out excess water and vegetation from internal drive before leaving the waterbody. © 2021 Axopar Boats Page 6...

  • Page 154: Appendix V: Strapping And Transport

    13 Appendix V: Strapping and transport 13 Appendix V: Strapping and transport Axopar 29 XC Cross Cabin 2024 Document ID: 29XCMY24-202408EN Owner's Manual © 2024 Axopar Boats Page 87...
  • Page 155 SECTION A-A This document and the information contained in it is proprietary and confidential information of Axopar Boats Oy. Neither this document nor any of the information contained herein may be reproduced, disclosed to others, or used for any purpose other than for the purpose it has been provided without the prior written permission of Axopar Boats Oy.
