OWNER'S
MANUAL
AXOPAR 28 CABIN
MODEL YEAR 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 28 Cabin and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Axopar 28 Cabin

Summary of Contents for Axopar 28 Cabin

  • Page 1 OWNER’S MANUAL AXOPAR 28 CABIN MODEL YEAR 2021...

  • Page 2: Table Of Contents

    4.2. Technical systems...........................25 4.2.1. Electrical system........................25 4.2.2. 12 V system......................... 25 4.2.3. Main switches........................26 4.2.4. Direct supply switches......................27 4.2.5. Fuses............................ 27 4.2.6. Heavy duty fuses........................28 Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 1...
  • Page 3 6.4.3.2. Driving at high speed....................48 6.4.3.3. Driving in rough seas....................49 6.4.3.4. Maneuvering in narrow channels................50 6.4.4. Visibility from helming position..................... 50 6.4.5. Using the trim tabs....................... 50 Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 2...
  • Page 4 9.7. Checklist: Before winter lay-up.......................61 9.8. Checklist: Before launching......................62 10. Appendix II: Fuel system..................63 11. Appendix III: Electrical diagrams................64 12. Appendix IV: Warning label placement..............65 Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 3...

  • Page 5: Introduction

    WARNING result in death or serious injury. Caution indicates a potentially hazardous situation which, if not avoided, might CAUTION result in minor or moderate injury. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 4...

  • Page 6: Document Conventions

    1.4. Copyright Copyright ©2020 Axopar Boats. All rights reserved. This Owner's Manual is protected by copyright controlled by Axopar Boats. This manual cannot be wholly or partly reproduced without prior written authorization by Axopar Boats. This material also contains confidential information, which may not be disclosed to others without the prior written consent of Axopar Boats.

  • Page 7: Safety

    When out on the water, always use the seats intended for passengers. 2.1. Safety diagram Swim ladder Life raft storage CO monitor Fire extinguisher → Exit Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 6...

  • Page 8: Fire Protection And Control

    • The fire control equipment is accessible at all times. • The fire extinguishing equipment is checked regularly at the intervals specified for the equipment. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 7...

  • Page 9: Checklist: Fire In The Engine

    With regular intervals, check that the monitor system is functioning. For instructions, see the equipment manufacturer's manual. • When the boat is in use, do not turn the system switch off. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...
  • Page 10 Using canvas curtains. • Winds blowing exhaust toward boat occupants. • Operating engine or generator in a confined space. • Operating with the bow high. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 9...

  • Page 11: Life Raft

    In an emergency, the life raft is easiest and safest to board from the swimming deck. Switch off the engine before using the life raft. Follow the life raft manufacturer’s instructions. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 12: Product Overview

    The builder’s plate is always fitted close to the steering position in the boat. Eurofins Expert Services Oy has inspected that the boat fulfils the Recreational Boat Directive and related standards' requirements. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 13: Ce Certification

    ISO 10087:2006 Builder's plate RDC ANNEX I: A 2.2 Owner's manual EN ISO 10240:2004/A1:2015 Preventing falling overboard EN ISO 15085:2003/DAM 2.3.2 Life raft stowage RSG Guidelines Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 12...
  • Page 14 EN ISO 11812:2001 EN ISO 15083:2003 ISO 8849:2003 Handling characteristics Handling characteristics RSG Guidelines RFU 114 EN ISO 8665:2006 Visibility from the steering position EN ISO 11591:2011 Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 13...

  • Page 15: Dimensions And Weight

    Hull weight (excluding engine) 2383 kg 5254 lb Category B Category C Maximum number of persons Default weights: • Adult: 75 kg • Child: 37.5 kg Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 14...
  • Page 16 Fuel tank 300 l Fuel tank - North American Region 63 gal Fresh water tank 39 l 10 gal Septic tank 45 l 12 gal Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 15...

  • Page 17: Boat Layout

    The stowage can be replaced with optional extra equipment such as an aft cabin, a storage bench or a wetbar. Aft cabin Storage bench Wetbar Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 16...
  • Page 18 As an option, the cabin can be equipped with a pilothouse pentry. In the front part of the cabin, there is a separate storage room/toilet option with a door that opens to the front deck. Pilothouse pentry Storage room/toilet option Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 19: Product Description

    The system is built so as to drain the water from the deck in normal use. Do not close the taps when using the boat or when the boat is attached to the dock. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 20: Openings In The Hull And Deck

    Risk for this can be minimized by closing the canopies, hatches or other openings. All doors and hatches must be kept shut when under way. WARNING Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...
  • Page 21 Service hatch in the STB fender box Toilet door (10) Storage box hatches The location and number of these components depend on the level of the equipment on the boat. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 22: Bilge System

    The electric bilge pumps are equipped with a float which triggers them automatically if there is water in the bilge space. The pumps can also be controlled manually from the switches on the steering console. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...
  • Page 23 If seacocks are fitted in the fore and aft peak bulkheads, they shall be kept closed and shall only be opened to let water drain into the main bilges. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...
  • Page 24 4. Product description Handle bilge pump Aft electric bilge pump Front electric bilge pump Hull through valves Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 23...
  • Page 25 Septic tank draining seacock Sinks draining seacock (10) Toilet seat inlet seacock (11) Heater exhaust (12) Manual bilge pump outlet (13) Aft bilge pump outlet Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 24...

  • Page 26: Technical Systems

    Damaged equipment must be maintained before taking back to use. When the electronic circuit is switched on, the equipment can be operated from the main switch panel. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 27: Main Switches

    Service switch to the On position and feed to the bow thruster and windlasses is achieved by turning the Aux switch to the On position. Start batteries Service battery Aux battery Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 26...

  • Page 28: Direct Supply Switches

    Any damaged equipment must be maintained or changed before they are again taken into use. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 29: Heavy Duty Fuses

    The functioning of fuses can be checked from the holes in the fuse’s cover. If the metal strip visible in the hole is unbroken, the fuse is operational. If the metal strip is damaged, meaning that an overload has occurred, contact a qualified nautical electrician. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 30: Batteries

    When removing batteries, disconnect the negative pole first and make sure that there are no flammable or explosive materials or liquids nearby. When putting the batteries back in place, connect them in reverse order (positive pole first). Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 31: Cleaning The Batteries

    If the earth fault breaker is tripped, disconnect the shore power cable immediately. In such a case contact a qualified electrician for repairs before the system is used again. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 32: Fuel System

    The inlet pipe for fuel is located in the starboard side of the deck. If the boat has been equipped with an extra diesel tank, the inlet pipe and tank are located forward. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 33: Refueling The Boat

    Never use a wrong type of fuel in the heater or cooker as this may damage them. • Never use an open flame when detecting leaks. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 32...

  • Page 34: Optional Equipment

    The dealer is responsible for disinfecting the fresh water tank before sale. The fresh water system must be thoroughly emptied for winter storage. It is not NOTICE recommended to use any anti-freeze products in the fresh water system. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 35: Septic System

    Toilet tap Water tank and pump 4.3.2. Septic system The boat's septic system consists of the toilet seat, the septic tank and the related systems. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 34...

  • Page 36: Toilet Seat

    Close the cock after use. Using the electrical toilet The electrical toilet is used with a separate operating switch. For more information on the device, see the manual for the toilet. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 37: Septic Tank

    The operation panel is located in the steering console. The heater tank is located in the fore. The filling cap for the heater tank is in the bow of the boat. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 38: Bow Thruster

    The boat can be equipped with a fore anchor windlass as an optional extra. The windlass switches are located in the bow of the boat, and a remote control for the windlass can be found on the steering console. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...
  • Page 39 If the windlass loosens when the boat is moving at great speed, it may cause WARNING great damage to the boat, its passengers and outsiders. • Always fix the anchor windlass mechanically in place before getting under way. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 38...

  • Page 40: Transportation

    • Check the boat´s lift points, weights and other information. • Straddle lift operation is a highly technical area that requires trained and experienced operators. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 39...

  • Page 41: Transporting The Boat

    Protect the boat by placing suitable padding between the tie down straps and the boat, if necessary. • See the engine manual for any instructions on trailering. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...
  • Page 42 A hood or other cover flapping in the wind during trailering can damage the boat surface. ◦ Keep the hood in its dedicated storage compartment during trailering, or remove the hood completely, if necessary. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 43: Operation

    The controllers are situated so that the driver can easily manage them from the steering console. The location and quantity of the devices depend on what optional equipment and engine models have been chosen. See the device manuals for further information on the devices. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 44: Windscreen Wipers

    6.1.3.1. Checking and topping up oil Effective and properly working steering is crucial for the safety of the boat. Check the oil level in the pump before casting off. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 45: Steering Maintenance

    3. Start the engine by turning the ignition key. 4. Check that the gauges for oil pressure and volt meter show normal values. 5. Run the engine to operating temperature at idling speed. Never rev up a cold engine. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 46: Swivel Seat - Driver And Passenger Seats

    This allows you to rotate the seat on the post. The locking handle must be in the locked position before boat speed exceed 5 DANGER knots. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 45...

  • Page 47: Inspecting The Boat

    Make sure that: • The main switches are switched off. • The septic tank discharge valve is closed. • There is no water in the bilge. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 46...

  • Page 48: Handling The Boat

    Firmly fend off the bow from the jetty. • Take a line from the bow around a bollard or cleat, so that it can be easily let go. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 49: Driving The Boat

    International Regulations for Preventing Collisions at Sea). • Always make sure that you have the space needed for avoiding collisions and coming to a halt and for evasive maneuvers. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 50: Driving In Rough Seas

    Planing boats can be particularly exposed in rough following seas. The stern of the boat rises and the rudder does not answer, so the boat broaches while the bow cuts down into the sea. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 51: Maneuvering In Narrow Channels

    6.4.5. Using the trim tabs A boat does not need trim tabs to get up on the plane or to give good performance. However, trim tabs are a very useful aid when used correctly. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 52: Preventing Falling Overboard

    If the sun deck cushions of the fore deck table are in place, observe the maximum speed of 15 knots to avoid the cushions or table detaching at speed or in high waves. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 53: Anchoring, Docking And Mooring

    It is good to have someone on the foredeck that can go ashore and quickly turn the bow in the desired direction after the boat has stopped completely. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 54: Checklist: Before Anchoring

    • Always remember that the stability of the boat may decrease when being towed. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 53...

  • Page 55: Maintenance

    Remove grease with a brush or a sponge and window cleaner. 3. Clean the surface afterwards with sponge and water. 4. Wipe dry with a piece of cloth. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 56: Fabrics

    4. Rinse thoroughly with freshwater. We recommend mixing 12% vinegar in the final rinsing water to neutralize the soap residues. 5. Hang the cover to drip dry. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 57: Preventing Frost Damage

    8. Check the steering before launching. 9. Check the instrumentation. 10. Close all water drain plugs. 11. Check that the seacocks are tight and in order, check for any frost damage. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 58: Corrective Maintenance

    NOTICE water or chemicals should be avoided. Failure to observe this precaution may result in extensive and potentially costly damage to the underlying laminate structure. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 57...

  • Page 59: Environment

    Great Lakes and interconnected waterways, freshwater lakes and impoundments accessible through locks, and other flowing waters that are navigable interstate by vessels subject to this regulation (40 CFR 140.3). Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 60: Appendix I: Checklists

    There is no water in the bilge. • All the bilge pumps are functional. • The bilge has no signs of fuel or oil leaks. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 59...

  • Page 61: Checklist: After Using The Boat

    For safe navigation under all weather conditions, proper sound signaling equipment in compliance with regulations (COLREG, 1972) must be carried on board. Make sure that the sound signaling equipment on the boat is compliant with these regulations. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual ©...

  • Page 62: Checklist: Before Anchoring

    Store the carpets and cushions indoors in a dry place. ◦ If this is not possible, make sure that the cushions are dry and position them on their side. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 63: Checklist: Before Launching

    11. Check that the seacocks are tight and in order, check for any frost damage. 12. Check all pipes, hoses and cocks. 13. Make a note of any frost damage. Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats...

  • Page 64: Appendix Ii: Fuel System

    10. Appendix II: Fuel system 10. Appendix II: Fuel system Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 63...
  • Page 65 Designed by General tolerances Date 22.08.2017 Axopar S.Sundfors SFS-EN 22768-1, SFS-EN ISO 13920 Mass Product / Project Approved by Date Axopar 28 EU S.Sundfors 22.08.2017 Scale Quantity manufactured 3/8" plug (PLUGGED STD) 1:10 Description Drawing number 3/8 shutoff valve Fueltank AX28...

  • Page 66: Appendix Iii: Electrical Diagrams

    11. Appendix III: Electrical diagrams 11. Appendix III: Electrical diagrams Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 64...
  • Page 67 INPUT- -/20 INPUT- INPUT- /11.D8 /3.B2 6 BLACK 4102 INPUT- INPUT- INPUT- /1.F4 -XG1b INPUT- Axopar 9.11.2017 C4: NOT MODIFIED. 29.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 START BT/MAIN SW 5.2.2018...
  • Page 68 1 BLACK INPUT- /7.B5 1 BLACK INPUT- /10.B5 95 BLACK 1 BLACK INPUT- INPUT- /1.D3 /10.E6 Axopar 9.11.2017 C4: HEATER MOVED, AFTER MAIN SWICTH TO DIRECT+. 29.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID...
  • Page 69 2.5 BLUE MACERATOR 2.5 BLACK INPUT- -/20 INPUT+ /15.E1 2634810 2635810 4102 INPUT- /1.F4 INPUT+ /11.B1 Axopar 9.11.2017 C4: NOT MODIFIED. 29.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 TOILET, RADAR, FRIDGE, 5.2.2018...
  • Page 70 -X.4G INPUT- /2.D8 -/20 1.5 RED ANCH_LT R3K32_0.5W 4102 CONNECTED TO X40b. USED IN T-TOP VERSION. INPUT- /1.F4 Axopar 9.11.2017 C4: NOT MODIFIED. 29.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 NAVIGATION LIGTHS 5.2.2018...
  • Page 71 READING LT WITH USB TOILET DN LT TOILET DN LT -H51 -H52 -H46 READING LT 1.5 YELLOW/BLACK 1.5 YELLOW/BLACK Axopar 9.11.2017 C4: CIRCUIT CHANGES AND ADDED H44, H45, H46 30.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code...
  • Page 72 /6.F7 2635210 2634210 2634210 2635210 1.5 WHITE/GREY 1.5 BLACK LOGO LT. PRT. 2635210 2635210 LOGO LT. STB. Axopar 9.11.2017 C4: CIRCUIT CHANGES, H18 AND H41 30.6.2017 Date 31.1.2018 C5: ADDED H38_39 CONNECTOR Drawing by Boat Sub-product code Product code Project ID...
  • Page 73 2634210 2635210 1 RED EL_INV_OUT_2 R3K32_0.5W 1 RED EL_INV_OUT_2 -A15 -A15 1 BLACK INPUT- INPUT- /2.E6 -A52 -A52 Axopar 9.11.2017 C4: NOT MODIFIED. 30.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 SEARCH LTS/ UW LTS/ 5.2.2018...
  • Page 74 INPUT- -X.4a -X4a 4102 WIPER STB WIPER_IN/C 1.5 RED WIPER_IN/C INPUT- /1.F4 INPUT- /5.E6 OPEN Axopar 9.11.2017 C4: NOT MODIFIED. 29.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 WIPERS/ W. WASH C6: NOT MODIFIED 5.2.2018...
  • Page 75 -H34 /7.A1 INPUT+ 1.5 BROWN 1.5 BLACK /12.B1 4422.02 HORN_OUT INPUT- /12.B1 /12.D1 /12.E1 /14.E4 Axopar 9.11.2017 C4: NOT MODIFIED. 29.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 HORN, CO MONITOR 5.2.2018...
  • Page 76 BILGE_P_IN 1.5 GREY BILGE_CTRL INPUT+ INPUT- /2.F8 /14.D4 -S11 -S11 -R11 INPUT- /2.F8 R3K32_0.5W 2.5 GREY Axopar 9.11.2017 C4: NOT MODIFIED. 29.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 BILGE PUMPS 5.2.2018...
  • Page 77 -X1a TRIM 7/11 7/11 4 RED 4 RED TRIM 4 RED TRIM 4 BLACK INPUT- /2.E4 /1.E3 Axopar 9.11.2017 C4: NOT MODIFIED. 29.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 PUMPS, TRIM 5.2.2018...
  • Page 78 1.5 GREY/GREEN SPKR_LR+ -A7b -LS4 1.5 GREEN/BLACK SPKR_LR- RADIO -A7a -LS.4 1.5 BLACK INPUT- INPUT- /11.C8 Axopar 9.11.2017 C4: NOT MODIFIED. 29.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 NAV EQ., RADIO 5.2.2018...
  • Page 79 1.5 GREY/RED PLOTTER 1.5 GREY/RED PLOTTER 1.5 BLACK INPUT- -/20 INPUT+ /2.B8 4102 INPUT- /1.F4 INPUT- /12.B4 Axopar 9.11.2017 C4: NOT MODIFIED. 29.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 OUTLET, PLOTTER, 5.2.2018...
  • Page 80 2.5 GREY TRIM_C3 -T_S2 -A36 -A37 -A23 -A24 2.5 BLACK TRIM_C4 2.5 YELLOW/GREEN FUEL_GND 2.5 RED TRIM_INPUT Axopar 9.11.2017 C4: NOT MODIFIED. 29.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 BOW TH, ANCH W 5.2.2018...
  • Page 81 2.5 BLUE SUMP_P 2.5 BLACK INPUT- INPUT+ INPUT- /1.F2 /14.D4 2634410 2635410 2635410 2634410 Axopar 9.11.2017 C4: MODIFIED ROOF CANVAS CIRCUIT, ADDED A64, A65 30.6.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 ROOF CANVAS/ 5.2.2018...
  • Page 82 -ARC 1.5 BROWN BROWN -ARC -A.63 -A.64 1.5 YELLOW/BLACK YELLOW -ARC 1.5 RED -ARC 1.5 BLACK BLACK Axopar 22.9.2017 B2: INTRODUCED DRAWING. 30.8.2017 Date 31.1.2018 C5: NOT MODIFIED Drawing by Boat Sub-product code Product code Project ID 28 MY18 TARGA/ SOFT 5.2.2018...
  • Page 83 CABLE CABLES (8U BACK VIEW) INPUT- -XG1b (8N BACK VIEW) 1000 mm INPUT- -XG1b 13447_2635810 Axopar 29.6.2017 19.9.2017 A1: INTRODUCED DRAWING. Date 23589 22.9.2017 B2: TRIM & PENTRY HARNESS ADDED; LOGO LIGHTS & -X5G ADDED Drawing by Boat Sub-product code...
  • Page 84 INPUT- TRIM_C1 -X.32:1, -X5G:3 -A35 (3NT BACK VIEW) 2800 mm 2.5 BLACK TRIM_C2 -A35 2634310 Axopar 29.6.2017 A1: INTRODUCED DRAWING. 29.6.2017 Date 23589 22.9.2017 B2: TRIM & PENTRY HARNESS ADDED; LOGO LIGHTS & -X5G ADDED Drawing by Boat Sub-product code...
  • Page 85 WEDGE LOCK: W4S 3000 mm SUMP_P 1.5 BLACK INPUT- -X4d:4 -X4G:- 2635410 Axopar 9.11.2017 C4: CHANGED WIRE SIZE ROOF CNVS, INTERIOR LTS. 29.6.2017 Date 23590 5.2.2018 C5: 2 x TOILET DN LT ADDED & TOILET LT CONN. CABLE LENGTH CHANGED...
  • Page 86 -A.26, -H17 1600 mm 1.5 BLACK 1.5 BLACK INPUT- INPUT- -H11 -A.26, -H17 Axopar 9.11.2017 C4: CHANGED WIRE SIZE ROOF CNVS, INTERIOR LTS. 30.6.2017 Date 23590 5.2.2018 C5: 2 x TOILET DN LT ADDED & TOILET LT CONN. CABLE LENGTH CHANGED...
  • Page 87 B2: -H38 & -H39 LOGO LT. MOVED TO HULL HARNESS; NAME CHANGED Drawing by Boat Sub-product code Product code Project ID 28 Cabin MY18 CABIN ROOF HARNESS 9.11.2017 C3: ADDED H44, H45; CHANGED ROOF CANVAS WIRE SIZE 2,5 TO 6 MM2; NAME CHANGES Sheet rev. Date of modification...
  • Page 88 -G3b:1 35/10 35/8 125A -BT_CF.1#1 8267 FUSE ANL 125A -K.9#1 17019 Axopar 5.2.2018 C4: BOW TH FUSE LUGS CHANGED 35/8->35/10, G3f CHANGED 6R10->PR10 Date 23594 22.9.2017 B2: LENGHTS CHANGED; BOW TH. FUSE CHANGED TO ENGBO. Drawing by Boat Sub-product code...
  • Page 89 35 BLACK INPUT- -G3c:1 -A38b:1 INPUT- 35/10 35/10 INCLUDED -M_S.5#1 AES-1211-28A 4487 Axopar 5.2.2018 C4: CABLE LENGTHS CHANGED, FUSE REMOVED 29.6.2017 Date 23596 22.9.2017 B2: LENGHTS CHANGED; ANCH W. CONNECTED TO BATT. & MS. Drawing by Boat Sub-product code Product code...
  • Page 90 1 RED AUX_IN -A33 -A.25b:1 NAV_LT 1000 mm 1 BLACK -A.25b:2 INPUT- DT044P-E004 WEDGE LOCK: W4S DT044P-E004 WEDGE LOCK: W4P Axopar 29.6.2017 A1: INTRODUCED DRAWING. 29.6.2017 Date 23597 22.9.2017 B1: NOT MODIFIED. Drawing by Boat Sub-product code Product code Project ID...
  • Page 91 -K.3#1 4487 4487 17019 AES-1211-28A AES-1211-28A START MS SERV MS MAIN SWITCH HOLE PLUG Axopar 29.6.2017 A1: INTRODUCED DRAWING 29.6.2017 Date 23875 23598 22.9.2017 B2: FUSES RENAMED; -M_F.10 CHANGED DD -> 88-SERIES; BATTERY CABLES AND HEATER FUSES ADDED Drawing by...
  • Page 92 95/10 95/10 INCLUDED INCLUDED 70/10 -G1h -C1#1 -XG.1 DELIVER -G1h SEPARATELY V02504 V4100 Axopar 29.6.2017 A1: INTRODUCED DRAWING 29.6.2017 Date 23875 23598 22.9.2017 B2: FUSES RENAMED; -M_F.10 CHANGED DD -> 88-SERIES; BATTERY CABLES AND HEATER FUSES ADDED Drawing by Boat...
  • Page 93 1.5 RED HEATER_CTRL -F11:2 4 RED FW_PUMP -F32:2 (4N BACK VIEW) 2634410 Axopar 9.11.2017 29.6.2017 C4: CHANGED ROOF CANVAS FUSE -F26 TO 20A AND WIRE SIZE TO 6MM2. Date 23860 23600 22.9.2017 B2: FUSES RENAMED, REORGANIZED & ADDED; SUMP P. FUSE DD -> 88-SERIES...
  • Page 94 50 mm 50 mm 100 mm -A29 50 mm 50 mm 50 mm 50 mm Axopar 9.11.2017 29.6.2017 C4: CHANGED ROOF CANVAS FUSE -F26 TO 20A AND WIRE SIZE TO 6MM2. Date 23860 23600 22.9.2017 B2: FUSES RENAMED, REORGANIZED & ADDED; SUMP P. FUSE DD -> 88-SERIES...
  • Page 95 -S6:NO 2639010 -X.6c#1 1.5 WHITE/YELLOW UW_LTS_IN -S5:C 1.5 WHITE/YELLOW UW_LTS_OUT -S5:NO (4N BACK VIEW) 2634410 Axopar 9.11.2017 C3: NOT MODIFIED. 29.6.2017 Date SEE EXP. VIEW 23601 22.9.2017 B2: WIPER CTRL. CHANGED TO ROCA AND WIPER RELAY REMOVED. Drawing by Boat...
  • Page 96 -S7:C, -K4:30 INVERTER WIRE 4 RED SEARCH_L_OUT -K4:87 INVERTER WIRE (2NT BACK VIEW) 2 INVERTER WIRE 2637710 Axopar 9.11.2017 C3: NOT MODIFIED. 29.6.2017 Date SEE EXP. VIEW 23601 22.9.2017 B2: WIPER CTRL. CHANGED TO ROCA AND WIPER RELAY REMOVED. Drawing by...
  • Page 97 2PCS M3 X 10 BH HEX BOLT A4 2PCS M3 SPRING WASHER A4 2PCS M3 BOLT A4 13. 1PCS 23718_AXOPAR_28_SWITCH_PANEL_GASKET GLUE WITH 2-SIDED TAPE TO THE BACKSIDE OF 23178 JS 06.07.2017 Axopar 9.11.2017 C3: NOT MODIFIED. 6.7.2017 Date SEE EXP. VIEW 23601 22.9.2017...
  • Page 98 Date 23786 22.9.2017 B2: NAME CHANGED. Drawing by Boat Sub-product code Product code Project ID 28 Cabin MY18 SEARCH LT/ 9.11.2017 C3: ADDED -X405, -X406 AND SEARCH LT CONTROL WIRES. Sheet rev. ROOF HARNESS Date of modification Modified by Description Project rev.
  • Page 99 BILGE_MA BILGE_MAN GREY GREY BILGE_A_FORE -X.8:1 4700 mm INPUT- BLACK BLACK INPUT- -X.8:3 (6N BACK VIEW) 2634610 Axopar 29.6.2017 A1: INTRODUCED DRAWING. 29.6.2017 Date 23787 22.9.2017 B1: NOT MODIFIED. Drawing by Boat Sub-product code Product code Project ID 28 MY18 FORE BILGE 9.11.2017...
  • Page 100 2.5 RED FISH_T_P_OUT -FT_X1:2 -FT_X1#1 2.5 RED FISH_T_P_IN -FT_S1:2 250 mm 2.5 RED FISH_T_P_OUT -FT_S1:3 (2UT BACK VIEW) 2637810 Axopar 30.6.2017 A1: INTRODUCED DRAWING. 30.6.2017 Date 23863 23802 22.9.2017 B1: NOT MODIFIED. Drawing by Boat Sub-product code Product code Project ID...
  • Page 101 -ARC -T_ARC INCLUDED DELIVER CONNECTORS SEPARATELY -X403 -X404 DT04-6P-E004 DT06-6S-P012 14044 14046 W6S-P012 14045 14047 Axopar 22.9.2017 B1: INTRODUCED DRAWING. 30.8.2017 Date 24162 9.11.2017 C2: ADDED -X403 AND -X404. Drawing by Boat Sub-product code Product code Project ID 28 MY18 TARGA ARC Sheet rev.
  • Page 102 BROWN -S_TOP -T_S_TOP 1.5 RED 1.5 RED -S_TOP -T_S_TOP 1.5 BLACK 1.5 BLACK BLACK -S_TOP -T_S_TOP BLACK Axopar 22.9.2017 B1: INTRODUCED DRAWING. 30.8.2017 Date 24163 9.11.2017 C1: NOT MODIFIED. Drawing by Boat Sub-product code Product code Project ID 28 MY18 ELECTRICAL SOFTTOP Sheet rev.
  • Page 103 1.5 WHITE/GREY -X3b#1 -F13:2 DECK_LT_IN 1500 mm 1.5 WHITE/GREY -X6a:3 DECK_LT_IN 6434.01 2637810 (2UT BACK VIEW) Axopar 22.9.2017 B1: INTRODUCED DRAWING. 29.8.2017 Date 24165 9.11.2017 C2: RENAMED H18, H41 TO DECK LT COCKPIT, CHANGED MEASUREMENTS. Drawing by Boat Sub-product code...
  • Page 104 Axopar 22.9.2017 B1: INTRODUCED DRAWING. 29.6.2017 Date 24166 9.11.2017 C1: NOT MODIFIED. Drawing by Boat Sub-product code Product code Project ID 28 Cabin MY18 RADIO HARNESS Sheet rev. Date of modification Modified by Description Project rev. Boat model Title Sheet...
  • Page 105 2637810 (2UT BACK VIEW) -D_S1#1 300 mm 2.5 YELLOW/BLACK INTERIOR_LTS -H12, -X10:1 1.5 YELLOW/BLACK DOWN_LT_OUT 2637810 (2UT BACK VIEW) Axopar 22.9.2017 B1: INTRODUCED DRAWING. 29.6.2017 Date 24173 9.11.2017 C2: ADDED READING LT, CHANGED MEASUREMENTS. Drawing by Boat Sub-product code Product code...
  • Page 106 2637810 (2UT BACK VIEW) -H37#1 UNDER W. LT 3200 mm 1.5 WHITE/YELLOW -H36 UW_LTS_OUT 1.5 BLACK -H36 INPUT- Axopar 22.9.2017 B1: INTRODUCED DRAWING. 29.8.2017 Date 24174 9.11.2017 C2: CHANGED UNDER W.LT. WIRE MEASUREMENT. Drawing by Boat Sub-product code Product code...
  • Page 107 -H.39_H40#1 WHITE WHITE WHITE/RED DECK_LT_OUT -H.38 WHITE/RED WHITE/RED WHITE INPUT- -H.38 (2N BACK VIEW) 2634210 150mm Axopar 31.1.2018 C1: INTRODUCED DRAWING 31.1.2018 Date 25779 24398 Drawing by Boat Sub-product code Product code Project ID 28 MY18 CABIN LOGO Sheet rev.
  • Page 108 24398_AXOPAR_28_CABIN_LOGO_ILLUMINATION_UNIT_(WOC)_ASSEMBLY_V2 1. 3x M3 NUT A4 2. 3x 16704 TL3-W65K LED-MODUULI VALK 3. 25779_AXOPAR_28_CABIN_LOGO_ILLUMINATION_UNIT_PLATE_(WOC) 4. 3x M3 X 20 BOLT A4 Axopar 31.1.2018 C1: INTRODUCED DRAWING 31.1.2018 Date 25779 24398 Drawing by Boat Sub-product code Product code Project ID 28 MY18 CABIN LOGO Sheet rev.

  • Page 109: Appendix Iv: Warning Label Placement

    12. Appendix IV: Warning label placement 12. Appendix IV: Warning label placement Axopar 28 Cabin MY2021 Document ID: 28CMY21202012EN Owner's Manual © 2020 Axopar Boats Page 65...
  • Page 110 15. Dashboard panel....................18 16. Main cabin, STBD under cabin window............... 21 17. Fire extinguisher....................22 18. Main cabin, PS - main switch................23 19. Wetbar lid - grill option..................25 20. Deck STBD, fuel inlet...................26 © 2020 Axopar Boats Page 2...
  • Page 111 This document presents the positions and the pictures of the warning labels that are placed on the boat. The position numbers in the picture below correspond the numbering of the chapters to guide you in finding the correct warning label. © 2020 Axopar Boats Page 3...

  • Page 112: Port Fwd Storage

    1. Port fwd storage 1. Port fwd storage © 2020 Axopar Boats Page 4...

  • Page 113: Cabin Roof Inner

    2. Cabin roof inner 2. Cabin roof inner © 2020 Axopar Boats Page 5...

  • Page 114: Main Cabin Port Door

    3. Main cabin port door 3. Main cabin port door © 2020 Axopar Boats Page 6...

  • Page 115: Front Seats

    4. Front seats 4. Front seats © 2020 Axopar Boats Page 7...

  • Page 116: Co2 Sensor - Port - Main Cabin

    5. CO2 sensor - port - main cabin 5. CO2 sensor - port - main cabin © 2020 Axopar Boats Page 8...

  • Page 117: Aft Cabin Hatch And Skylights

    6. Aft cabin hatch and skylights 6. Aft cabin hatch and skylights © 2020 Axopar Boats Page 9...

  • Page 118: Switch Panel In Aft Cabin

    7. Switch panel in aft cabin 7. Switch panel in aft cabin © 2020 Axopar Boats Page 10...

  • Page 119: Ski Pole

    8. Ski pole 8. Ski pole © 2020 Axopar Boats Page 11...

  • Page 120: Aft Deck Folding Seat

    9. Aft deck folding seat 9. Aft deck folding seat © 2020 Axopar Boats Page 12...

  • Page 121: Bow Thruster Option

    10. Bow thruster option 10. Bow thruster option © 2020 Axopar Boats Page 13...

  • Page 122: Shore Power - Fwd Locker

    11. Shore power - fwd locker 11. Shore power - fwd locker © 2020 Axopar Boats Page 14...

  • Page 123: Stb Above Speaker

    12. STB above speaker 12. STB above speaker © 2020 Axopar Boats Page 15...

  • Page 124: Switch Panel In Toilet Compartment

    13. Switch panel in toilet compartment 13. Switch panel in toilet compartment © 2020 Axopar Boats Page 16...

  • Page 125: Panel In Toilet Compartment

    14. Panel in toilet compartment 14. Panel in toilet compartment © 2020 Axopar Boats Page 17...

  • Page 126: Dashboard Panel

    15. Dashboard panel 15. Dashboard panel © 2020 Axopar Boats Page 18...
  • Page 127 15. Dashboard panel © 2020 Axopar Boats Page 19...
  • Page 128 15. Dashboard panel © 2020 Axopar Boats Page 20...

  • Page 129: Main Cabin, Stbd Under Cabin Window

    16. Main cabin, STBD under cabin window 16. Main cabin, STBD under cabin window © 2020 Axopar Boats Page 21...

  • Page 130: Fire Extinguisher

    17. Fire extinguisher 17. Fire extinguisher © 2020 Axopar Boats Page 22...

  • Page 131: Main Cabin, Ps - Main Switch

    18. Main cabin, PS - main switch 18. Main cabin, PS - main switch © 2020 Axopar Boats Page 23...
  • Page 132 18. Main cabin, PS - main switch © 2020 Axopar Boats Page 24...

  • Page 133: Wetbar Lid - Grill Option

    19. Wetbar lid - grill option 19. Wetbar lid - grill option © 2020 Axopar Boats Page 25...

  • Page 134: Deck Stbd, Fuel Inlet

    20. Deck STBD, fuel inlet 20. Deck STBD, fuel inlet © 2020 Axopar Boats Page 26...

Table of Contents

Save PDF
