ROBOfiber LFC Series User Manual

Technical Specifications
Standards IEEE 802.3, 802.3u, 802.3z, 802.3ab, 802.3ae,
802.3an
Connectors SFP/SFP+ slot and RJ45 UTP ports – available
on the LFC converters, AC power receptacle,
DC power plug for installed power supplies
Power Requirements AC 100-240V or DC 36~72V, 40W max. power
consumption
Dimensions 485mm x 270mm x 44.5mm
Weight 3.2Kgs (~7lbs) with dual PS installed
Chassis material Black PVD painted steel
Mounting 19" rack direct installation
Environmental Conditions Operating Ambient Temperature: 0 to 50℃
Operating Humidity: Maximum 85%, Non-
condensing
Storage Temperature: -20 to 70℃
Storage Humidity: Maximum 90%, Non-
condensing
Indoor rated operating device
MTBF 80,000 hours
Warning
1. Use only indoors in climate-controlled environment.
2. Always load first the bottom row of media converters before occupying
the top row. Installation on bottom row is difficult if a top row unit has
been already installed.
3. Use only the AC 100-240V input or DC 36~72V input power supplies
intended for the LFC-CH12 chassis
FCC and CE markings
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
This is a CE class B device, intended to be used in residential, commercial or
industrial applications.
LFC series
Fiber Media Converter Chassis
4
Fiber Media Converter Chassis
High density chassis for LFC series converters
LFC-CH12-AC
LFC-CH12-AD
LFC-CH12-DD
www.robofiber.com
User's Manual
