ROBOfiber 10G LFC Series User Manual

Technical Specifications

Standards IEEE 802.3an (10GBase-T), 802.3ae(10GBase-
SR, LR, ER or ZR)
Connectors SFP+ slot, RJ45 TP port, DC power plug
RJ45 port Full duplex, 10G Base-T
SFP+ slot Supports 10G speed SFPs
Power Adapter Adapter with AC 100-240V input, 0.5A
AC frequency: 50-60Hz, Output DC 5V/1A
Power Requirements DC 5-12V, 5W max. power consumption
Dimensions 90mm x 60mm x 20mm (SFP not included)
Mounting Wall or shelf (optional bracket needed)
Environmental Conditions Operating Ambient Temperature: 0 to 50℃
Operating Humidity: Maximum 85%, Non-
condensing
Storage Temperature: -30 to 70℃
Storage Humidity: Maximum 95%, Non-
condensing
Indoor rated operating device
MTBF 65,000 hours

Warning

1. Use only indoors in climate-controlled environment.
2. Avoid looking directly into fibers or lasers while unit is powered.
3. Use only the AC adapter included with the unit (or with the LFC series
chassis available separately)

FCC and CE markings

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
This is a CE class B device, intended to be used in residential, commercial or
industrial applications.
LFC series 10G
Ethernet Fiber Media Converters
4
Fiber Media Converters
10G Ethernet LFC series
LFC-10GT-SFP
LFC-10G-SS
www.robofiber.com
User's Manual
