- Page 1 User manual netTAP NT 100 Gateway Devices Hilscher Gesellschaft für Systemautomation mbH www.hilscher.com DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 2: Table Of Contents
Device drawings: Right side (connector X3) .............. 34 Connectors and interfaces ..................... 35 4.6.1 X1 power supply ..................... 35 4.6.2 X2/X3 Front connectors .................. 35 netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 3 LEDs Serial ........................ 85 9.5.1 LED Modbus RTU................... 85 9.5.2 LED ASCII....................... 86 9.5.3 LED Serial with netSCRIPT ................ 87 netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
- Page 4 Table of contents 4/135 9.5.4 LED 3964R ..................... 88 10 Technical data ........................ 89 10.1 Technical data netTAP NT 100 Gateway............... 89 10.2 Technical data of Real-Time Ethernet protocols ............ 92 10.2.1 EtherCAT Master .................... 92 10.2.2 EtherCAT Slave .................... 93 10.2.3 EtherNet/IP Scanner ..................
-
Page 5: Introduction
Section LEDs [} page 60] updated. Section Technical data [} page 89] updated. 2021-03-30 Section Technical Data PROFINET IO-Device [} page 99]: MRP Client added. 2022-04-29 Section Technical data netTAP NT 100 Gateway [} page 89]: UKCA sign added. 2023-10-19 Section Dimensional drawings [} page 29]: Drawings added. Table 1: List of revisions 1.1.2... -
Page 6: Reference To Device, Software, Driver And Firmware
USB driver of Windows Table 4: Reference to driver Firmware for the protocol conversions, see section Protocol conversions [} page 21]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 7: Contents Of The Product Dvd
Introduction 7/135 Contents of the product DVD The product DVD for the netTAP NT 100 contains: Setup program for the configuration and diagnosis program SYCON.net · USB driver · · Documentation · Firmware · Device description files (EDS, GSD, GSDML, ...) ·... -
Page 8: Device Description Files
Note: Use the SDDML export function in SYCON.net to create a suitable SDDML file. Table 6: Device description files for netTAP NT 100 The device description files are used in the configuration software of the master. netTAP NT 100 | Gateway Devices ©... -
Page 9: Documentation For Nettap
Configuration of Gateway and Proxy Manual Devices OI xx EN.pdf netTAP, netBRICK and netLINK Step by step description of the configuration of the netTAP NT 100. Configuration of the netTAP NT 100 as EtherCAT Slave, EtherNet/IP Adapter, Open Modbus/TCP, POWERLINK Controlled Node, PROFINET IO-Device,... -
Page 10: Table 8: Additional Documentation For Nettap Nt 100 With Ethercat Master
EtherCAT Generic Slave DTM OI xx Manual EN.pdf Table 8: Additional Documentation for netTAP NT 100 with EtherCAT Master netTAP NT 100 with EtherNet/IP Scanner You need the following additional documents, if you use the protocol EtherNet/IP Scanner on the gateway device:... -
Page 11: Table 12: Additional Documentation For Nettap Nt 100 With Canopen Master
PROFIBUS DP Generic Slave DTM OI Manual xx EN.pdf Table 14: Additional Documentation for netTAP NT 100 with PROFIBUS DP Master netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 12: Table 15: Additional Documentation For Nettap Nt 100 With Netscript
Serial Communication UM xx Programming Language for serial communication EN.pdf Table 15: Additional Documentation for netTAP NT 100 with netSCRIPT netTAP NT 100 with ASCII You need the following additional documents, if you use the protocol ASCII on the gateway device:... -
Page 13: Safety
NT 100-CO-RS NT 100-DN-RS Table 18: netTAP devices: NT 100 The netTAP NT 100 devices are in a compact housing and suitable for DIN rail mounting according to DIN EN 60715. Personnel qualification The netTAP NT 100 Gateway must only be installed, configured and re- moved by qualified personnel. -
Page 14: References Safety
NT 100 device. Danger of unsafe system operation To prevent harm of persons, do not remove this device under runtime con- ditions before you can not guarantee further a safe and secure operation of the plant. -
Page 15: Safety Instructions To Avoid Property Damage
Make sure that the power supply to the device is not interrupted during write and delete accesses in the file system (firmware update, configuration download, etc.). netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 16: Device Destruction By Exceeding Allowed Supply Voltage
NT 100. The allowed range for the supply voltage is defined by the tolerances specified in this manual. The data on the mandatory supply voltage for the netTAP NT 100 device is documented in section Requirements for operation [} page 26]. There the required and permitted supply voltage for the netTAP NT 100 device is provided inclusively the permitted tolerance range. -
Page 17: Labeling Of Safety Messages
Indicates a hazardous situation which, if not avoided, may result in minor or moderate Injury. Indicates a property damage message Table 19: Signal words netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 18: Description And Requirements
18/135 3 Description and requirements Brief description The netTAP NT 100 devices described in this manual are communication devices and connect two communication networks. The netTAP devices act as a gateway between the two networks. The netTAP NT 100 is a device with two interfaces (communication channels) whose operating principle is shown in the following figure. -
Page 19: Device Type Name
Description and requirements 19/135 The firmware of the netTAP NT 100 with gateway function does not support the mapping of acyclic services/messages. Device type name The following figure shows an NT 100 RE-DP. Figure 2: Device name NT 100-RE-DP Figure 3: Device name (example) The device description consists of the following parts: 1. -
Page 20: Table 20: Network On Port X2 (Primary Network)
PROFIBUS DP Serial (Modbus RTU, ASCII, 3964R or serial with netSCRIPT) Table 21: Network on port X3 (secondary network) netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 21: Protocol Conversions
DeviceNet Slave NTPNSDNS.NXF Sercos Master DeviceNet Slave NTS3MDNS.NXF Sercos Slave DeviceNet Master NTS3SDNM.NXF Sercos Slave DeviceNet Slave NTS3SDNS.NXF netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 22: Table 22: Nt 100 For The Conversion "Ethernet To Fieldbus
PROFIBUS DP Master NTS3SDPM.NXF Sercos Slave PROFIBUS DP Slave NTS3SDPS.NXF Table 22: NT 100 for the conversion "Ethernet to Fieldbus" netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 23: Protocol Conversion 2: Ethernet To Serial
Modbus RTU Master/Slave NTS3SMBR.NXF Sercos Slave Serial with netSCRIPT NTS3SNSC.NXF Table 23: NT 100 for the conversion "Ethernet to Serial" netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 24: Protocol Conversion 3: Fieldbus To Fieldbus
PROFIBUS DP Master NTDNSDPM.NXF DeviceNet Slave PROFIBUS DP Slave NTDNSDPS.NXF Table 24: NT 100 for the conversion "Fieldbus to Fieldbus" netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 25: Protocol Conversion 4: Fieldbus To Serial
Modbus RTU Master/Slave NTDNSMBR.NXF DeviceNet Slave Serial with netSCRIPT NTDNSNSC.NXF Table 25: NT 100 for the conversion "Fieldbus to Serial" netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 26: Requirements
1. A suitable firmware must have been loaded into the device. 2. The netTAP must have been configured with SYCON.net without errors. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 27: Configuration Software Requirements
Ø the DTMs of the devices used in the project must also be installed on this additional PC. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 28: Licenses
The order name of the master license is: NXLIC-MASTER, part number: 8211.000 netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 29: Device Drawings And Connectors
The power supply plug is included within the delivery. As a spare part, the plug can be ordered from RIA connect GmbH in 78176 Blumberg; part number: 31369102-001792. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 30: Device Label
UL certification data, see http://www.ul.com Device type name Part number Serial number Hardware revision Table 26: Device label netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 31: Leds And Control Elements
LED, meaning depends on the protocol at X3. Table 27: LEDs and control elements (upper half of the device) netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 32: Leds Of The Lower Half Of The Device
ACT LED (activity) / Rx/Tx LED (activity) on channel 1 at X2, yellow. Table 30: LEDs (lower half of the device) netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 33: Device Drawings: Left Side (Connector X2)
The LED stickers are included within the delivery. Apply the LED sticker according to the firmware loaded. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 34: Device Drawings: Right Side (Connector X3)
NT100-DP-CC NT100-CO-DP NT100-CO-CO NT100-CO-RS NT100-CO-DN NT100-CO-CC NT100-DN-DP NT100-DN-CO NT100-DN-RS NT100-DN-DN NT100-DN-CC Table 33: Device drawings (right side, X3) netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 35: Connectors And Interfaces
Inside the device, a pull-up resistor of 100 kΩ is connected to "Rx/Tx+". Inside the device, a pull-down resistor of 100 kΩ is connected to "Rx/Tx-". netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 36: Table 36: Canopen Interface (Iso 11898)
Shield, 15 nF against PE CAN H CAN High signal +24 V DeviceNet power supply COMBICON socket Table 37: DeviceNet interface netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 37: Table 38: Rj45 Ethernet Interface
Field ground, pin 4 und 5 are internally connected to PE COMBICON socket Table 39: CC-Link interface netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 38: Table 40: Rs-232 Interface
Reference potential RxD/TxD+ Receive/send data, positive Shield Metal shell on PE D-Sub plug, 9-pin Table 42: RS-485 interface netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 39: Diagnostic Interface (Mini-B Usb)
Data- Data+ Reference potential Shield Metal shell on PE Mini-B USB 5-ping Table 44: USB interface (Mini-B) netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 40: Schematic Diagrams - Galvanic Isolation
(area X2). Fieldbus connecting area X3: D-Sub-plug/socket or COMBICON connector. Table 45: Areas netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 41 Cx3: 1 MΩ parallel to 15 nF 1000V directly parallel to 10 nF 500 V Table 46: Coupling of NT 100-RE-XX devices netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 42: Galvanic Isolation In Case Of Nt 100-Dp-Xx, Nt 100-Co-Xx, And Nt 100-Dn-Xx Devices
Fieldbus connecting area X2: D-Sub-plug/socket or COMBICON connector. Fieldbus connecting area X3: D-Sub-plug/socket or COMBICON connector. Table 47: Areas netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 43 10 nF 500 V Table 48: Galvanic isolation NT 100-DP-XX / NT 100-CO-XX / NT 100-DN-XX devices netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 44: Nt 100 Mounting And Dismounting
Grounding is done via a grounding contact located at the backside of the device connecting it electrically to the DIN top hat rail. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 45: Dismounting The Nt 100 From The Din Top Hat Rail
Ø You can then easily pull the device off the DIN top hat rail in direction of arrow (3). netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 46: Installing The Driver
At first, install the USB driver before you connect a netTAP device to the USB port of the PC for the first time. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 47: Commissioning
– NT 100-DN-XX with serial number 20283 and higher as well as – NT 100-CO-XX with serial number 20148 and higher. Only the SD card which can be ordered from Hilscher (part number 1719.003) can be used reliable with devices that have a lower serial number. - Page 48 9. Remove the memory card from the device to have a faster start of the device for the next power on, because the copy operation is not done. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 49: Start-Up Behavior
The following description refers to the parameter start behavior Every Start of the memory card. Ø Remove power supply from the netTAP NT 100 device. Ø Insert memory card with until it snaps in. Ø Supply 24 V operation voltage to the device. -
Page 50: Reset Device To Factory Settings With Memory Card
The device has to be recovered to the factory default settings. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 51 PC, windows will ask for a new USB driver, even if you have already installed it before. Please follow the instructions in the section Installation des USB-Treibers für den “Hilscher netX boot monitor“ [} page 52] . Just in the case that no driver installation is requested (cause the device has been previously connected in this state before already) please follow the in-structions in the section Firmware Laden [} page 55] .
-
Page 52: Figure 13: Usb Installation - Step 1
Commissioning 52/135 7.2.4.2 USB driver installation in boot loader mode as „Hilscher netX boot monitor“ Note: The following section only need to be done in case of an error, if the firm-ware download into the devices was not completed without error. -
Page 53: Figure 15: Usb Installation - Step 3
Ø Select Have Disk Ê The following window will be opened. Figure 17: USB installation - Step 5 Ø Select Browse netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 54: Figure 18: Usb Installation - Step 6
Ø Click Continue Anyway (1). Ø Wait until the driver has been installed. Ø Continue with section Firmware Laden [} page 55]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 55: Figure 20: Comprox Start
OK (2). Ê You are forwarded to the program’s start screen. Figure 22: ComProX File Explorer netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 56: Figure 23: Comprox File Explorer, Nt 100 File Structure
Ê Loading the firmware may take some seconds. Ø Right mouse click into the window area (B). netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 57: Figure 25: Comprox File Explorer, File Menu 2
SYCON.net via the USB port. From there you can now download the firmware of your choice. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 58: Troubleshooting
For some protocols it is necessary to synchronize data via a handshake be- tween the gateway and the superordinated PLC. Please make sure that the handshake mechanism is kept. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 59: Failure In 10 Mbit/S Half-Duplex Mode And Workaround
‘Y’ at position 5 (nnnnYnnnn). Reference “Summary of 10BT problem on EthernetPHY”, RenesasElectronics Europe, April 27, 2010 netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 60: Leds
To determine the position of the SYS LED use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 61: Apl
To determine the position of the LED use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 62: Leds Real-Time Ethernet Systems
LED yellow This LED is not used. (off) Table 53: LED states for the EtherCAT Master (V4) protocol netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 63 To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 64: Leds Ethercat Slave
To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 65: Leds Ethernet/Ip Scanner
The device does not send/receive Ethernet frames. (off) Table 57: LED states for the EtherNet/IP Scanner protocol netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 66 To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 67: Leds Ethernet/Ip Adapter
The device does not send/receive Ethernet frames. (off) Table 59: LED states for the EtherNet/IP Adapter protocol netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 68 To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 69: Leds Open Modbus/Tcp
To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 70: Leds Powerlink Controlled Node
To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 71: Leds Profinet Io-Controller
(load dependent) The device does not send/receive Ethernet frames. (off) Table 66: PROFINET IO Controller, Ethernet LEDs states netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 72 To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 73: Leds Profinet Io-Device
To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 74: Leds Sercos Master
(off) LED yellow This LED is not used. (off) Table 70: LED states for the Sercos Master protocol netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 75 To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 76: Leds Sercos Slave
(off) LED yellow This LED is not used. (off) Table 72: LED states for the Sercos Slave protocol netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 77 To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 78: Leds Fieldbus Systems
To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 79: Led Canopen Slave
To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 80: Led Cc-Link Slave
To determine the position of the LEDs use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 81: Led Devicenet Master
To determine the position of the LED use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 82: Led Devicenet Slave
To determine the position of the LED use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 83: Led Profibus Dp Master
To determine the position of the LED use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 84: Led Profibus Dp Slave
To determine the position of the LED use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 85: Leds Serial
To determine the position of the LED use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 86: Led Ascii
To determine the position of the LED use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 87: Led Serial With Netscript
To determine the position of the LED use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 88: Led 3964R
To determine the position of the LED use the device drawings in section LEDs and control elements [} page 31]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 89: Technical Data
Technical data 89/135 10 Technical data 10.1 Technical data netTAP NT 100 Gateway NT 100 Parameter Value Communication controller Type netX 100 Memory 8 MB SDRAM FLASH 4 MB serial Flash Memory card (optional) Type: MMC or SD card Storage capacity: Max. 2 GByte Important: Comply with the requirements on using the memory card: Type, max. - Page 90 NT 100-DN-DN NT 100-DN-CO NT 100-DN-CC NT 100-DN-DP NT 100-DN-RS Table 96: Technical data NT 100 (part 2) netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
- Page 91 RS-422: 6 ... 1000000 Bit/s RS-485: 6 ... 1000000 Bit/s Table 97: Technical data NT 100 (part 3) netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 92: Technical Data Of Real-Time Ethernet Protocols
The watchdog time is fixed to a value of 20 Reference to firmware/stack V2.0/V4.4 version Table 98: Technical data EtherCAT Master netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 93: Ethercat Slave
Acyclic communication not supported LRW is not supported Reference to firmware/stack V2.0/V4.7 version Table 99: Techncal data EtherCAT Slave netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 94: Ethernet/Ip Scanner
CIP Sync Services are not implemented TAGs are not supported Reference to firmware/stack V2.0/V2.10 version Table 100: Technical data EtherNet/IP Scanner netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 95: Ethernet/Ip Adapter
CIP Sync Services are not implemented TAGs are not supported Reference to firmware/stack V2.0/V2.13 version Table 101: Technical data EtherNet/IP Adapter netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 96: Open Modbus/Tcp
No acyclic user data communication No slave to slave communication Reference to firmware/stack V2.0/V3.4 version Table 103: POWERLINK Controlled Node netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 97: Profinet Io-Controller
Baud rate 100 MBit/s Full-duplex Data transport layer Ethernet II, IEEE 802.3 Configuration file Maximum 1 MByte netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 98 WriteMultiple-Record service is not supported. Reference to firmware/stack V2.0/V3.3 version Table 104: Technical data PROFINET IO-Controller netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 99: Profinet Io-Device
Only 1 Input CR and 1 Output CR are supported Multiple WriteRequests are not supported Reference to firmware/stack V2.0/V4.4 version Table 105: Technical data PROFINET IO-Device netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 100: Sercos Master
Master has a configuration Reference to firmware/stack V2.0/V2.1 version Table 106: Technical data Sercos Master netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 101: Sercos Slave
Cross Communication not supported NRT Channel only forwarding and S/IP Reference to firmware/stack V2.0/V3.5 version Table 107: Technical data Sercos Slave netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 102: Technical Data Of Field Bus Protocols
CoE upload, CoE download for user data transfer not supported Reference to firmware/stack V2.0/V2.14 version Table 108: Technical data CANopen Master netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 103: Canopen Slave
The address switches can be activated with SYCON.net version 1.351 (or higher) and can be used with firmware version 1.5 (or higher). netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 104: Cc-Link Slave
The address switches can be activated with SYCON.net version 1.351 (or higher) and can be used with firmware version 1.5 (or higher). netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 105: Devicenet Master
User data transfer through the gateway only via IO connections Reference to firmware/stack V2.0/V2.4 version Table 111: Technical data DeviceNet Master netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 106: Devicenet Slave
The address switches can be activated with SYCON.net version 1.351 (or higher) and can be used with firmware version 1.5 (or higher). netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 107: Profibus Dp Master
DP V2 services are not supported Reference to firmware/stack V2.0/V2.9 version Table 113: Technical data PROFIBUS DP Master netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 108: Profibus Dp Slave
The address switches can be activated with SYCON.net version 1.351 (or higher) and can be used with firmware version 1.5 (or higher). netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 109: Technical Data Of Serial Protocols
Character(s) without meaning (fix length) Checksum methods CRC8, CRC16, CRC32, Exor Reference to firmware/stack V2.0/V1.1 version Table 115: Technical data ASCII netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 110: Modbus Rtu Master/Slave
None, even, odd Restrictions Broadcast not supported Reference to firmware/stack V2.0/V1.5 version Table 116: Technical data Modbus RTU Master/Slave netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 111: Netscript (Serial)
Indicator for end of received Free definable end indicator with up to 64 telegram bit and bit by bit AND mask netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 112: 3964R
Ring Buffer with 30 buffers (FIFO) Number of transmission retries Adjustable Checksum method Reference to firmware/stack V2.0/V1.0 version Table 118: Technical data 3964 netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 113: Wiring Instructions
Cable shielding pulled back over the cable sheathing. Metallic or metallized connector housing Table 119: D-Sub cable assemblies netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 114: Ethernet
For further information refer to section Failure in 10 MBit/s half-duplex mode and workaround [} page 59]. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 115: Profibus
6 Mbit/s 100 m 12 Mbit/s 100 m Table 121: Max. cable length and baud rate for PROFIBUS netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 116: Canopen
30 m < 70 Ω/km 0.25 ... 0.34 mm Table 124: Max. cable length and baud rate for CANopen netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 117: Devicenet
6 m. The entire length of the cable and all branch lines must not exceed the max. length listed in the following table. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023... -
Page 118: Cc-Link
Cable specification V1.10 has not been changed for CC-Link V2.00. Depending on the baud rate, the different cable types allow the following cable lengths: netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 119 A CC-Link cable housing is included within the delivery of a netTAP NT 100-XX-CC gateway device. The cable housing is from Phoenix Contact, number 1803895, designation KGG-MSTB 2,5/5. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 120: Figure 31: Cc-Link Cable Housing - Separate Components
Ø Place the upper part of the cable housing onto the lower part to close the cable housing. Figure 32: Mounted CC-Link cable housing netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 121: Figure 33: Rs-232 Null Modem Cable Connection
Table 132: Max. cable length and baud rate with RS-232 Cables of a lower capacity allow even higher lengths. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 122: Figure 34: Rs-422 Cable
Capacity < 30 pF/m Loop resistance 110 Ω/km Wire diameter 0.64 mm Table 133: Electrical requirements: RS-422 cable netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 123: Figure 35: Rs-485 Cable
120 Ω and 220 Ω. The value of the pull-up and pull-down resistors ranges between 390 Ω and 650 Ω. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... - Page 124 0.3 m 600 m 500 kBit/s 0.6 m 1200 m 100 kBit/s 1.5 m Table 136: RS-485 cable lengths netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 125: Appendix
The manual delivered with the product shall apply. Under no circumstances shall Hilscher Gesellschaft für Systemautomation mbH be liable for direct, indirect, ancillary or subsequent damage, or for any loss of income, which may arise after use of the information contained herein. - Page 126 Appendix 126/135 Liability disclaimer The hardware and/or software was created and tested by Hilscher Gesellschaft für Systemautomation mbH with utmost care and is made available as is. No warranty can be assumed for the performance or flawlessness of the hardware and/or software under all application conditions and scenarios and the work results achieved by the user when using the hardware and/or software.
- Page 127 The customer hereby expressly acknowledges that this document contains trade secrets, information protected by copyright and other patent and ownership privileges as well as any related rights of Hilscher Gesellschaft für Systemautomation mbH. The customer agrees to treat as confidential all of the information made available to customer by Hilscher Gesellschaft für...
- Page 128 NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 129: Trademarks
(company names or trademarks) of the corresponding owner and may be protected under trademark or patent law. netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 130: List Of Figures
Figure 33: RS-232 null modem cable connection..............121 Figure 34: RS-422 cable......................122 Figure 35: RS-485 cable......................123 netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public... -
Page 131: List Of Tables
Additional Documentation for netTAP NT 100 with CANopen Master....Table 13: Additional Documentation for netTAP NT 100 with DeviceNet Master....Table 14: Additional Documentation for netTAP NT 100 with PROFIBUS DP Master ... Table 15: Additional Documentation for netTAP NT 100 with netSCRIPT ......Table 16: Additional Documentation for netTAP NT 100 with ASCII ........ - Page 132 LED state definitions for the DeviceNet Master protocol ........Table 81: LED states for the DeviceNet Slave protocol............netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
- Page 133 Max. cable length and baud rate for PROFIBUS............ 115 Table 122: Electrical requirements: PROFIBUS cable ............. 116 netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
- Page 134 RS-422 cable lengths ..................... 123 Table 135: Electrical requirements: RS-485 cable ..............124 Table 136: RS-485 cable lengths ..................... 124 netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
-
Page 135: Contacts
20090 Vimodrone (MI) E-mail: us.support@hilscher.com Phone: +39 02 25007068 E-mail: info@hilscher.it Support Phone: +39 02 25007068 E-mail: it.support@hilscher.com netTAP NT 100 | Gateway Devices © Hilscher 2009 – 2023 DOC081001UM22EN | Revision 22 | English | 2023-10 | Released | Public...
Need help?
Do you have a question about the netTAP NT 100 and is the answer not in the manual?
Questions and answers
