- Page 1 Contour E-Vertex Servicing...
- Page 2 TO ENSURE WARRANTY, PERIODIC MAINTENANCE RECORDS MUST BE RETAINED. Disposal Contact Modsel or your institution expert for advice on disposal of this device. DO NOT repurpose this device. Modsel as the legal manufacturer of this medical device can advise if it can be reconditioned. v-06052025 - Page 2...
- Page 3 How To Service The Dropsides Refer to the separate Dropside Servicing guide. How To Remove The Plastic Base Cover 1. Remove the stretcher top assembly if you are fully replacing the base cover. If lifting the cover for base chassis access only, you may raise and tie the base cover to the top assembly (such as running a tie strap under the base cover and hooking back to the stretcher top on each side).
- Page 4 How To Adjust The Brake/Steer System Wear from continuous use may cause the trolley brake or steer action to not lock in properly over time. This may need to be corrected by adjusting the length of the Brake Linkage Rod. 1.
- Page 5 How To Replace A Headrest Actuator 1. Position the headrest upwards in both its height and tilt functions. 2. Undo the 3 retaining bolts holding the cover on the underside of the headrest. 3. Remove the headrest cover and slide out the plastic strip that covers the underside of the hinge system.
- Page 6 Spare Part Identification Overall Size: 2135 x 815mm overall size (705mm narrow or 965mm wide top options) v-06052025 - Page 6 Making a world of difference.
- Page 7 Spare Part Identification Table Item Code Description MPT-J1306 E-Vertex Pillow Scalloped 75mm MPT-J1304-Standard 75mm Premia E-Vertex Mattress - Standard MPT-J1304-Narrow 75mm Premia E-Vertex Mattress - Narrow MPT-J1304-Wide 75mm Premia E-Vertex Mattress - Wide MPT-C2718 Corner Casting MPT-E1745 PVC End Cap MPT-E2696-Standard End Rail PVC Extrusion - Standard MPT-E2696-Narrow...
- Page 8 25.1 MPT-WS3091-Narrow E-Vertex Backrest Frame-Narrow 25.2 MPT-WS3091-Wide E-Vertex Backrest Frame-Wide BIC-2340 Headrest Actuator MPT-K2320 E-Vertex Sliding Cover MPT-PI1824 E-Vertex Headrest Cover v-06052025 - Page 8 Making a world of difference.
- Page 9 Notes v-06052025 - Page 9 Making a world of difference. Making a world of difference.
- Page 10 Notes v-06052025 - Page 10 Making a world of difference. Making a world of difference.
- Page 11 Notes v-06052025 - Page 11 Making a world of difference. Making a world of difference.
