Instructions and Safety Information
AK-C7012F-F series
The wireless keyboard AK-C7012F-F is a high quality, highly reliable hygiene keyboard, full desktop layout with a built-
in rechargeable lithium-ion battery. It is particularly designed for the use at hospitals and by practitioners. The
keyboard is sealed with a silicone membrane. The CLEAN function avoids sending keystrokes to your PC during
cleaning/disinfection. Please follow the instructions provided by your authorities for standard disinfection of surfaces
for reprocessing of the keyboard.
Installation:
1) The keyboard is shipped with enabled TRANSPORT-Mode! Deactivate the TRANSPORT-Mode following the
steps in section "Frequently Asked Questions (FAQ).
2) Connect the wireless USB-RF-Dongle to the USB port of your computer.
3) The keyboard should now be functional and ready for usage.
Delivery Content:
1x 2.4 GHz wireless keyboard 1x IP65 Protection Plug for USB Charging Socket
1x 2.4 GHz USB-RF-Dongle 1x User Instructions and Safety Information
1x USB charging cable
Safety Note:
1) The keyboard contains a built-in rechargeable Lithium-Ion-Battery (Rated capacity 3,7 Wh)
2) The keyboard achieves the ingress protection against water jets (IP65) only with correctly mounted IP65
protection plug on top of the USB Charging Socket. The user shall always confirm that the protection plug is
mounted before exposing the device to liquids for cleaning and disinfection!
3) The shipment of up to 2 products with built-in Lithium-Ion-Battery where the rated capacity is ≤ 100 Wh per battery
does not require marking as per Dangerous Goods Regulations. Otherwise, the products need to be shipped with
correct declaration under the applicable Dangerous Goods Regulation with lithium battery mark UN 3481. Please
consult us with regards to MSDS and UN38.3 report if required.
4) Safe removal and disposal of the battery:
a. Discharge the battery by normal use until the keyboard stops operation.
b. Remove the silicone rubber cover and unscrew the housing using a standard screwdriver PH00.
c. Disconnect the cabling between Lithium-Ion-Battery and Printed-Circuit-Board.
Manufacturer:
Cherry Digital Health GmbH Web: www.cherry.de
Cherrystraße 2 Tel: +49 (0) 9643-2061-100
D-91275 Auerbach/OPf.
Legal information:
Hereby Cherry Digital Health GmbH declares that the type of radio equipment used with the product models CKW96A
(2.4G Wireless Keyboard) and DON002 (Wireless Keyboard Dongle) complies with the DIRECTIVE 2014/53/EU
(RED). The full text of the EU declaration of conformity is available at the following internet address:
http://www.cherry.de/compliance
As distributor of batteries, we have the following obligations under article 20 of directive 2006/66/EC:
1) Batteries can be returned free of charge after use in shops selling batteries.
2) End users are legally obliged to return used batteries.
3) Manufacturers of batteries are required to mark batteries with the symbol of the crossed-out
wheeled bin before placing them on the market for the first time.
The manufacturer of batteries shall label batteries containing more than 0.0005 % by mass of
mercury, more than 0.002 % by mass of cadmium or more than 0.004 % by mass of lead, before placing them on the
market for the first time with the chemical symbols of metals (Hg, Cd, Pb) in which the limit is exceeded. The
characters are to be applied below the symbol.
Batteries may contain ingredients that are harmful to human health or the environment or pose other hazards. In
particular, the handling of lithium-containing batteries requires special caution due to various risks. By collecting and
recycling old batteries and accumulators separately, you help to avoid negative effects on human health and the
environment.
Electrical and electronic equipment (EEE) is marked with the symbol of the crossed-out wheeled bin indicating the
requirement not to dispose of waste electrical and electronic equipment (WEEE) as unsorted municipal waste and to
collect such WEEE separately.
Final users of WEEE from private households shall be able to return WEEE as per EU country local regulations into
established collection facilities free of charge. Please consult your municipal waste department for detailed advice on
separate collection of WEEE.
Please follow the rules of your local community on collection of used packaging.
Frequently Asked Questions (FAQ):
Usage of Medical Protective Gloves!
Nitrile gloves reduce the risk of allergic reactions and help prevent discoloration caused by latex wear.
How to deactivate/activate the TRANSPORT-Mode ™?
a) Deactivate TM: use key combination "Fn" + "Shift Right"
b) Activate TM: use key combination "Fn" + "CapsLock" + "BackSpace"
Power save mode!
The status LEDs show the status of NumLock, CapsLock and ScrollLock as soon as those functions are enabled.
The status LEDs will turn off after a while to save battery power. Press the key "Fn" to check the status of the LEDs.
How to determine the battery status?
The keyboard indicates a battery low situation with the status LEDs. With each key actuation one of the status
LEDs will light up shortly in round robin manner. Please charge the battery as soon as possible via the USB Type-C
charging socket with the included USB charging cable. The keyboard can be charged via any standard USB
charging travel adapter or via USB ports on Host-PCs.
How to activate/deactivate the CLEAN function?
The key combination "Fn" + "Shift (Clean on/off)" activates and deactivates the CLEAN function.
The mode 'CLEAN function active' is indicated with the status LED "Clean". During this mode the user can wipe
disinfect or clean the keyboard and all key entries are suppressed.
The mode 'CLEAN function active' ends automatically after a timeout of 30 seconds or by key combination.
How to investigate a wireless connection problem?
1) Check whether CLEAN Mode is active and deactivate it if required.
2) Check whether the USB RF Dongle is still recognized in the device manager of your Operating System
(VID&PID=0x0F39&0x000F).
3) Follow the pairing instruction below.
4) In case all previous steps did not resolve the problem please consult with customer services.
How to pair a new USB-RF-Dongle with the device?
Note: This procedure is only required in case you received a new USB-RF-Dongle as a spare part in case the
dongle was lost or damaged!
1) Make sure that all other USB-RF-Dongle in the near neighborhood are removed from the USB ports and
connect only the new USB-RF-Dongle.
2) Initiate the pairing between USB-RF-Dongle and Keyboard with key combination "Fn" + "Esc".
3) The Scroll Lock status LED will flash in fast frequency for approx. 5 seconds until the pairing process
completed.
4) Test the keyboard. In case the pairing process failed double check Step 1.
5) In case the pairing process is not successful please consult with customer services.
Specification:
Compatibility All OS that support USB HID Keyboards.
Temperature Range Storage -20 to +60 °C / Operation 0 to +50 °C
Chemical Resistance Wipe Disinfection according to Guidelines Cleaning and Disinfection
DGHM/VAH
Wireless USB-RF-Dongle USB 2.0 FS Type A connector, wireless range 10 m
2400 MHz – 2483,5 MHz
Frequency-band
Maximum transmission power 10 mW
Supply Voltage / Current Consumption 5 V USB charging connection, typical 5 mA during wireless usage
Dimensions (incl. rubber cover) Approx. 362 x 137 x 17 mm
Weight Approx. 656 g
Agency Approvals / Tests CE, RoHS, Test Report FCC, EN 60601-1-2:2015*
*No Medical Device acc.to Regulation (EU) 2017/745
