Cherry AK-440-T Series Instructions And Safety Information

Instructions and Safety Information
AK-440-T series
The corded keyboard AK-440-T is a high quality, highly reliable keyboard with
Trackball.
It is particularly designed for the use in industrial and office.
Delivery Content:
1x Corded Keyboard
1x User Manual
Manufacturer:
Cherry Digital Health GmbH
Cherrystraße 2
D-91275 Auerbach/OPf.
Legal information:
The product complies with the Directive EMC 2014/30/EU. The full text of the EU
declaration of conformity is available at the following internet address:
http://www.cherry.de/compliance
Electrical and electronic equipment (EEE) is marked with the symbol of the
crossed-out wheeled bin indicating the requirement not to dispose of waste
electrical and electronic equipment (WEEE) as unsorted municipal waste and to
collect such WEEE separately.
Final users of WEEE from private households shall be able to return WEEE as per
EU country local regulations into established collection facilities free of charge.
Please consult your municipal waste department for detailed advice on separate
collection of WEEE.
The packaging material used with this product is identified as PAP-20
and LDPE-04. Please follow the rules of your local community on
collection of used packaging.
Web: www.cherry.de
Tel: +49 (0) 9643-2061-100
Cleaning the Trackball
1 Open Trackball-Unit Turn the trackball ring, e.g. with tweezers, fixed
on both openings on the ring, counterclockwise
2 Clean Trackball & After opening the module, clean the trackball and
lens the optics (lens) underneath it. Use a microfiber
cloth or a comparable cleaning cloth for this
purpose.
3 Reassemble Reassemble the trackball mount by turning it
Trackball-Unit clockwise until you hear a click.
Frequently Asked Questions (FAQ):
How do I enable or disable the emulated number keypad integrated in the
keypad?
The keyboard has the feature "emulated numberpad" which integrated in the
alpha-numeric key layout. The user can activate or deactivate the feature with
the key combination Fn and F11 (NumL).
My keyboard is not recognized when plugged in!
Remove the USB plug, restart the PC and make sure that you have the rights to
install a USB device (administrator account). Then plug in the USB connector
again, preferably into a different port than the first attempt. If you still have
problems, please contact us.
Specification:
Compatibility All operating systems supporting USB or PS/2
Keyboards
Temperature Range Storage: -20 °C to +60 °C
Operation: 0 °C to +50 °C
Supply Voltage 5 V +/-10% through USB
Current Consumption Max. 45 mA (USB: low power device)
Dimensions Approx. 293 mm x 168 mm x 34 mm
Interface USB 2.0 FS, PS/2 (Keyboard and mouse
separately)
Key Switch Technology Scissor Balancing Technology
Weight Approx. 600 g (without packaging)
Trackball Integrated: PS/2 plug through 2 connectors resp.
1 USB connector
Optical Sensor Resolution 1000dpi (Ø 14mm)
Agency Approvals / Tests CE, RoHS
*No Medical Device acc.to Regulation (EU) 2017/745
All rights reserved. Copy or duplication, except for personal use, not permissible without specific prior written consent by Cherry Digital
Health GmbH. Contents are subject to change without notice. Errors excepted. Copyright by Cherry Digital Health GmbH.
Version 20240924
