Summary of Contents for Nokia Smart Node 5G
- Page 1 Quick Start Guide Smart Node 5G...
-
Page 2: Table Of Contents
Table of Contents: Welcome ..................3 Box Content (Clip-On) ................4 Box Content (Stand Alone Only) ............. 4 Connection Overview ................5 All Smart Node Variants with BH Module ............. 5 Quick Setup..................6 Quick Setup..................7 Quick Setup..................8 Common Troubleshooting Procedures ............ -
Page 3: Welcome
Welcome The Smart Node 5G provides enhanced 5G service within buildings. It delivers high quality 5G, mobile data service. The Smart Node 5G connects to your broadband Internet service to deliver an extended indoor mobile network coverage. The in-building mobile phone connectivity, signal quality, and data bandwidth will improve, especially if the building is in a remote area or out of adequate mobile phone tower range. -
Page 4: Box Content (Clip-On)
Box Content (Clip-On) Quick Start 5G Unit without Backhaul module Guide (This document) 4G Cover Removal Tool Box Content (Stand Alone Only) 5G Unit with Wall/Ceiling Mounting Kit Backhaul (1 Bracket, 3 Screws, and 3 Wall Anchors) module AC Power Adaptor Ethernet Cable GPS Antenna... -
Page 5: Connection Overview
Connection Overview All Smart Node Variants with BH Module Power Automatically powers on when AC Adaptor is plugged in. Yellow WAN Port Connect to internet router. Grey LAN Port Connect to other devices, like PC, if needed. GPS Port Connect the external GPS antenna if needed. Reset Press and hold for 5 seconds for reboot. -
Page 6: Quick Setup
Quick Setup Remove the face plate of the 4G Smart Node and Plug in the 5G Smart Node module (Clip-On Only) Power down the deployed 4G Smart Node. Remove the faceplate using the tool provided; plug in the 5G smart node on top of the 4G Smart Node until they “click”. Connect Your Smart Node to the Internet Connect the Ethernet cable from the yellow “WAN”... -
Page 7: Quick Setup
Quick Setup • Power (Solid White) Power on. Device self-testing and update complete. • Internet (Solid White) Successful internet connection. • Status (Solid White) Successful connection established with mobile operator network. (Solid White) • Successful connection established with the Global Satellite System •... -
Page 8: Quick Setup
Quick Setup Flexible mount options are available for the Smart Node. Wall mounting or ceiling mounting (accessories included in the 4G or 5G Stand Alone box). Table, desk or flat surface mounting (not included in the box , optional accesory ) Congratulations! Your Smart Node setup is complete. -
Page 9: Common Troubleshooting Procedures
Common Troubleshooting Procedures Issue Description and Power Internet Status Resolution Device has a hardware issue. Solid Solid Solid Solid Solid Solid Solid Orange Orange Orange Orange Orange Orange/Off Orange/Off Tamper Detected Product has a temper alarm. Radio Solid Solid Solid Flashing Flashing Flashing... -
Page 10: Faqs
FAQs How do I know that I am using my Smart Node service? Your mobile phone display will automatically indicate if you are within small cell signal range. If registered and configured properly, your mobile phone should display a small cell service message and an associated signal indicator. -
Page 11: Fcc Regulations (Sn5I77)
FCC Regulations (SN5I77) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 12: Ised Notice (Sn5I78)
Afin d'éviter la possibilité de dépasser les limites d'exposition aux fréquences radio de la CNR-102, la proximité humaine à l'antenne ne doit pas être inférieure à 20 cm (8 pouces) pendant le fonctionnement normal. : Nokia and the Nokia logo are RADEMARKS registered trademarks of Nokia.
