- Page 1 OPERATOR’S MANUAL SubliPro Countertop Electric Batch Sublimation Oven For Customer Service: Call 1-800-835-0606 or Visit hixcorp.com...
-
Page 2: Table Of Contents
Cleaning & Maintentance ....12 HIX Mug Wraps ......13 Using HIX Mug Wraps . -
Page 3: Receiving & Setup
RECEIVING & SETUP... -
Page 5: General Information
208 or 240 volt, 60 Hz., and 1- or 3-phase electrical service. Stainless steel oven interior and exterior is standard. Your HIX SubliPro-CT Electric Convection Oven is produced with quality workmanship and material. Proper installation, usage and maintenance of your oven will result in many years of satisfactory performance. -
Page 6: Unpacking & Placement
Before installing, verify that the electrical service agrees with the specifications on the oven rating plate, located on the inside of the top front cover. If the supply and equipment requirements do not agree, do not proceed with installation. Contact your HIX customer service representative immediately. UNPACKING This oven was inspected before leaving the factory. -
Page 7: Preparation
Trust only equipment that provide all 3 parameters in a controllable and uniform way. HIX equipment is designed to provide these parameters within very narrow tolerances, which is critical for success. Controllable time and temperature, properly and evenly distributed pressure and temperature are built in to all our product and are the reason for their generational popularity. -
Page 8: Quick Start Guide
QUICK START GUIDE TURNING THE POWER “ON” 1. Once the oven is plugged into power, the display will show a “Red Icon” as shown below. To turn the power on to the oven, simply press the Red Icon. 2. The display will then come on and look like what is shown below. To turn the oven “OFF”, simply press the Green “Power”... - Page 9 QUICK START GUIDE USER ADJUSTABLE SETTINGS Pressing the “GEAR” Icon in the upper left corner of the Home Screen will switch the screen to what is shown below for user adjustable settings Pressing the “Back Arrow/Return” Icon in the upper left corner of the display will take you to the previous screen.
- Page 10 QUICK START GUIDE STORING PRESETS FOR TIME &TIMER OPERATION The controller can save four TIME presets. The Factory Default time is 14:00. The button that is highlighted in “GREEN” is the ACTIVE timer preset on the controller. See below. To “Start” the timer, press the Timer Preset button that is highlighted in “GREEN”. You will see the time in the timer display window starting to count down and the active preset button will begin flashing alternating between Green and Gray.
-
Page 11: Operation
1. Press the Power Button on the display. The display will come on, indicating that power to the oven is on. The oven will need approximately 15 minutes to reach a sufficient sublimating temperature. 2. Set Thermostat as desired. As a general guideline, HIX’s in-house testing on standard 11/15 oz white ceramic mugs use a setting of: •... -
Page 12: Cleaning And Maintenance
The door hinges and mechanism require occasional lubrication with mineral oil. SERVICE AND PARTS INFORMATION To obtain service and parts information concerning this model, contact the HIX Customer Service Department. When calling for service, the following information must be available: model number, serial number, manufacture... -
Page 13: Hix Mug Wraps
WRAP STYLES HIX Snap Wraps can come in as many sizes and shapes as there are substrates in the market. For the standard straight 11oz and 15oz white mugs, HIX has a standard wrap which is readily available as part of its standard product stock. -
Page 14: Using Hix Mug Wraps
USING HIX MUG WRAPS CAUTION: MUG(S) and MUG WRAP(S) ARE HOT AFTER HEATING. ALWAYS WEAR PROTECTIVE GLOVES OR OVEN MITTS. KEEPS CHILDREN AWAY FROM HOT/SHARP MATERIALS. TRIM TRANSFER: Before applying, trim the transfer so that there is no excess paper above or below the mug. - Page 15 REMOVE AND COOL: NOTE: If you are not using a HIX Mug Oven with a Cooler then you will need to wear heat protective gloves to handle the finished wraps and mugs.
-
Page 16: Troubleshooting
TROUBLESHOOTING... - Page 17 TROUBLESHOOTING...
-
Page 18: Parts List
1201 E 27th Terrace, Pittsburg, KS Phone (620) 231-8568 Fax (620) Email: mail@hixcorp.com www This document and the information c It will be held confidentially and may prior written consent of HIX Corporat Tolerance Unless Noted +/- .060 +/- .030 .000 +/- .010... - Page 19 REPLACEMENT PARTS LIST ITEM# PART# TITLE ITEM# PART# TITLE 85076 CORD GRIP CG-6275 79426 WASHER LOCK HEL SPR 1/4 ZP 70813 INSUL BD ROXUL CURTAINROCK 80 70218 LEG METAL TXW 60079 INSUL FGLASS 1x24x87’ TIW 1 33605 DECAL, UNPLUG MACHINE 16774 WASHER FLT .281 X 0.625 X .063 ZPS 14910...
-
Page 20: Warranty
“Life” of the machine for the original purchaser. If a part becomes obsolete at the time for repair, and/or cannot be reasonably substituted for, HIX will credit, at half the then current list price or last recorded price, only that part toward a new machine or any product HIX offers.
