VAPOR ADX BIKE
OWNER'S MANUAL AND ASSEMBLY GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAPOR ADX and is the answer not in the manual?

Questions and answers

Related Manuals for True Fitness VAPOR ADX

Summary of Contents for True Fitness VAPOR ADX

  • Page 1 VAPOR ADX BIKE OWNER’S MANUAL AND ASSEMBLY GUIDE...

  • Page 2: Important-Please Read

    Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the appropriate sales representative to help answer your questions. • Phone | 800.426.6570 • Email | sales@truefitness.com • Hours | Monday - Friday 8:30am - 5:00pm (CST) © 2025 TRUE Fitness All Rights Reserved.

  • Page 3: Reporting Freight Claims Or Parts Damage

    Once you have called the carrier you will need to gather the serial number, model number, description of damage, and photos of damage. Contact TRUE product support (service@truefitness.com | 800.883.8783) or TRUE sales support (sales@truefitness.com | 800.426.6570) Monday-Friday during normal business hours. © 2025 TRUE Fitness All Rights Reserved.

  • Page 4: Table Of Contents

    PREASSEMBLY CHECKLIST............10 ASSEMBLY STEPS.................13 PRODUCT FEATURES BASE OVERVIEW................22 CONSOLE FEATURES..............23 WORKOUT PROGRAMS..............28 CONSOLE SERVICE MODE..............32 REPLACING THE CONSOLE BATTERIES........32 CARE AND MAINTENANCE INSPECTION................33 CLEANING THE EQUIPMENT............33 LEVELING THE MACHINE..............33 PREVENTATIVE MAINTENANCE............34 LONG TERM STORAGE..............35 © 2025 TRUE Fitness All Rights Reserved.

  • Page 5: Safety Instructions

    This stationary training equipment is not suitable for high accuracy purposes. humidity including extreme temperature changes. • Do not move the equipment by lifting the console. Do not use the console as a handlebar during a workout. © 2025 TRUE Fitness All Rights Reserved.
  • Page 6 Never place liquids of any type directly on the unit except in the accessory tray or bottle holders. Containers with lids are recommended. • Always follow the console instructions for proper operation. • Use correct ergonomic positioning while operating this equipment. © 2025 TRUE Fitness All Rights Reserved.

  • Page 7: Space Requirements

    DIMENSIONS (L X W X H) 55” x 26” x 53” (140cm x 66cm x 135cm) • MACHINE WEIGHT 112.5 lbs / 51 kg • MAXIMUM USER WEIGHT 350 lbs / 160 kg © 2025 TRUE Fitness All Rights Reserved.

  • Page 8: Warning Decals

    NOTE: The two numbers before the “-” refers to the year of manufacturing. base serial number location P/N 8013594 COMPLIANCES This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefitness.com. © 2025 TRUE Fitness All Rights Reserved.

  • Page 9: Proper Use

    C. To move the seat closer to, or away from the console, loosen the seat adjustment knob. Slide the seat to the desired position and fully tighten the knob. © 2025 TRUE Fitness All Rights Reserved.

  • Page 10: Assembly Instructions

    13mm/15mm Wrench VERIFY BOX CONTENTS IMPORTANT! Please verify box contents. If you have questions, or if there are any missing parts, contact product support (service@truefitness.com | 800.883.8783). 13mm Wrench (recommended) #2 Phillips Screwdriver (recommended) © 2025 TRUE Fitness All Rights Reserved.

  • Page 11: Box Contents

    REAR STABILIZER ASSEMBLY RIGHT HANDLEBAR ASSEMBLY LEFT HANDLEBAR ASSEMBLY RIGHT PEDAL LEFT PEDAL SEAT PAD ASSEMBLY FOOT PEGS TRANSPORT AND IMMOBILIZATION STRAP TWO D CELL BATTERY PACKAGE CONSOLE MAST ASSEMBLY HARDWARE PACK ASSEMBLY INSTRUCTIONS © 2025 TRUE Fitness All Rights Reserved.

  • Page 12: Hardware Pack Contents

    ALLEN KEY, 6MM, 190MM LENGTH, BALL END 8009379 WASHER, NYLON, FLAT, M16 X 32 X 2 THK 8006538 6MM HEX HEAD ALLEN WRENCH 8027423 SCREW, M8 X 1.25 X 14 SHCS BZ extra hardware © 2025 TRUE Fitness All Rights Reserved.

  • Page 13: Assembly Steps

    SCREW, SCKT BUTTON HEAD CAP, M8x1.25x16, STAINLESS STEEL tighten yet. 8013086 WASHER, FLAT, M8, NARROW, STAINLESS STEEL C. Once all fasteners are finger tight use a 6mm allen wrench to fully tighten. 8013079 WASHER, SPRING, M8, STAINLESS STEEL © 2025 TRUE Fitness All Rights Reserved.
  • Page 14 B. Securely fasten the pedals to the crank arm assemblies. CAUTION: If the threads strip due to improper installation, then the pedals can disengage from the bike and/or break while under usage, which can result in serious injury to the user. © 2025 TRUE Fitness All Rights Reserved.
  • Page 15 D. Insert and finger tight all fasteners. Once all fasteners are finger tight, use a 6mm allen wrench to fully tighten. © 2025 TRUE Fitness All Rights Reserved.
  • Page 16 If a torque wrench is curves available, tighten to 40 N-M (29.5 FT-LB). when using a torque wrench = 40 N-M (29.5 FT-LB) when using a torque wrench = 40 N-M (29.5 FT-LB) © 2025 TRUE Fitness All Rights Reserved.
  • Page 17 Do not let the washer fall off the foot peg during installation. 8009379 WASHER, NYLON, FLAT, M16 X 32 X 2 THK B. Attach the foot pegs to frame assembly. Tighten using a 6mm allen wrench. © 2025 TRUE Fitness All Rights Reserved.

  • Page 18: Step 6-Attach Seat

    SCREW, M8 X 1.25 X 14 SHCS BZ B. Using two 13mm wrenches tighten both nuts on the seat bracket to hold the seat 8013079 WASHER, SPRING, M8, STAINLESS STEEL 13mm Wrench (qty 2) in position. seat bracket seat post © 2025 TRUE Fitness All Rights Reserved.

  • Page 19: Optional Power Adapter

    If you use a power adapter for your machine, make sure that the cord stays clear of the path of the pedals. • It is recommended to remove batteries when they are not used, to avoid damage from battery corrosion. © 2025 TRUE Fitness All Rights Reserved.

  • Page 20: Step 8-Level The Bike

    2. Verify all four lock nuts are securely tightened and flush against the bottom of the frame. lock lock leveling leveling foot foot © 2025 TRUE Fitness All Rights Reserved.

  • Page 21: How To Move The Machine

    NOTE: Be sure to keep the fan assembly clear of the floor. D. Push the machine into position. E. Carefully lower the machine into position. seat post strap crank arm transport roller © 2025 TRUE Fitness All Rights Reserved.

  • Page 22: Product Features

    G. Pedals Moving part of the bike that provides resistance to the lower body during a workout. H. Leveling Feet An adjustable system used to aid in the leveling of the bike. © 2025 TRUE Fitness All Rights Reserved.

  • Page 23: Console Features

    B. LCD Tachometer Display The tachometer visually signals the user’ s output. C. Program Data Display Displays performance in heart rate, RPM, distance, watts and calories. D. Keypad Quick program and input keys. © 2025 TRUE Fitness All Rights Reserved.

  • Page 24: Tachometer Display

    D. Tach hill—represents the user’ s RPM performance on a 1-100 linear scale (divided into 10 segments). E. MAX CAL/MIN tick mark—the highest tick mark achieved (on the LCD tachometer display) stays on to show the maximum effort during the current workout. © 2025 TRUE Fitness All Rights Reserved.
  • Page 25 The prompt “ENTER AGE” turns on if the user presses the HR ZONES button. The default age is 35. The values in the FAT BURN, AEROBIC and ANAEROBIC heart rate zone fields are calculated from the Age value. © 2025 TRUE Fitness All Rights Reserved.

  • Page 26: Keypad Functions

    N. START/RESUME—Starts the timer, and resumes a paused workout. O. STOP/RESET—Push one time to stop the workout and display summary. Push two times to reset the console and erase data (except Custom Interval program). © 2025 TRUE Fitness All Rights Reserved.

  • Page 27: Remote Heart Rate Monitor

    Consult your physician for your individual target heart rate zone. NOTE: As with all exercises and fitness regimens, always use your best judgment when you increase your exercise time or intensity. © 2025 TRUE Fitness All Rights Reserved.

  • Page 28: Workout Programs

    E. The program starts in the sprint phase and counts down each phase and the total workout time. The work and distance values count up. An audible alert sounds 3 seconds before each phase change. © 2025 TRUE Fitness All Rights Reserved.
  • Page 29 C. The TIME/INTERVAL field blinks (default value is 10:00). To change the value, use increase/decrease (/) to adjust in 1 minute increments. D. Push START/RESUME to start the timer, and start to pedal. E. The program starts and counts down the time. The CALORIE, kJ, MI and KM values count up. © 2025 TRUE Fitness All Rights Reserved.
  • Page 30 C. The KM metrics field blinks (default value is 1.0). To change the value, use increase/decrease (/) to adjust in 1 kilometer increments. D. Push START/RESUME to start the timer, and start to pedal. E. The program starts and counts down the kilometers. The total time, CALORIE, kJ and MI values count up. © 2025 TRUE Fitness All Rights Reserved.

  • Page 31: Heart Rate Zones

    F. The heart rate area cycles the average HR and MAX HR values. If HR zones were calculated for the program, the values are displayed. The results display will show for 5 minutes and then reset. G. Push STOP/RESET to stop the results display and go back to idle mode. © 2025 TRUE Fitness All Rights Reserved.

  • Page 32: Console Service Mode

    NOTE: If you use rechargeable batteries, the optional power adapter will not recharge the batteries. CAUTION: • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable (Ni-Cd, Ni-MH, etc) batteries. © 2025 TRUE Fitness All Rights Reserved.

  • Page 33: Care And Maintenance

    CAUTION: Do not use any acidic cleaners. Doing so will weaken the paint or powder coatings and may void the TRUE Fitness Warranty. Never pour water or spray liquids on any parts of the machine. Allow the machine to dry completely before using. Frequently vacuum the floor underneath the unit to prevent the accumulation of dust and dirt, which can affect the smooth operation.

  • Page 34: Preventative Maintenance

    IF PARTS ARE DAMAGED OR WORN, PLEASE CONTACT PRODUCT SUPPORT. 13mm wrench (qty 2) handlebar cap screws hex bit serial number location pedal crank arm leveler cap screw lock nut 15mm 15mm hex bit wrench wrench © 2025 TRUE Fitness All Rights Reserved.

  • Page 35: Long Term Storage

    TRUE recommends that quarterly scheduled maintenance be performed by a qualified service technician. Please contact your dealer or visit www.truefitness.com to contact a local TRUE authorized service technician. IMPORTANT! Use only TRUE Fitness certified service providers. Using non-authorized service providers could void the TRUE Warranty. Frequency...

  • Page 36: Troubleshooting

    C. Try moving unit away from sources of interference (TV, Micro- wave, etc). D. Replace Chest Strap. D. If interference is eliminated and HR does not function, replace strap. E. Replace Console. E. If HR still does not function, replace Console. © 2025 TRUE Fitness All Rights Reserved.
  • Page 37 B. Check locking knob. B. Be sure knob is securely tightened. Handlebar arms click/ Check hardware. Screws at the base of handlebar arms should be tightened securely. (Screw torque tick during movement = 40 N.m.) © 2025 TRUE Fitness All Rights Reserved.

  • Page 38: Warranty Information Commercial Warranty

    Coax/TV, HDMI, USB, mirroring or 1 Year Bearings Ethernet connections, and safety key. Labor** 1 Year See Warranty Details for terms, conditions, and complete coverage details. Wear Items*** 90 Days © 2025 TRUE Fitness All Rights Reserved.

  • Page 39: Limited-Use Commercial Warranty

    LIMITED-USE COMMERCIAL WARRANTY* TRUE Fitness may offer alternative warranties to purchasers of CARDIO commercial equipment for limited-use commercial* or in-home use.** This policy ensures that customers who use commercial equipment for limited-use commercial or in-home use may WARRANTY ITEM VAPOR, APEX...

  • Page 40: Warranty Details

    WARRANTY DETAILS All TRUE Fitness products are distributed by TRUE and are warranted to the original registered product purchaser and the parts of the TRUE product (the “Product”) listed below, under normal use and service, shall be free of manufacturing defects in workmanship and materials only for the specified period of time.

  • Page 41: Warranty Registration

    WARRANTY REGISTRATION Base Serial Number Console Serial Number Purchase Date Company (if applicable) Customer Name (First and Last) Email Address Phone Number Street Address City State Postal Code Country © 2025 TRUE Fitness All Rights Reserved.
  • Page 42 CONTACT US service@truefitness.com 800.883.8783 865 Hoff Road St. Louis, MO 63366 T R U E F I T N E S S . C O M MAN-ADX-0A Owner’s Manual and Assembly Guide REV00 © 2025 TRUE Fitness All Rights Reserved.
