Autonics PSQ Series Product Manual

TCD210186AC_MODI
Dual Display Type
Pressure Sensors
PSQ Series
PRODUCT MANUAL
For your safety, read and follow the considerations written in the instruction
manual, other manuals and Autonics website.
The specifications, dimensions, etc. are subject to change without notice for product
improvement. Some models may be discontinued without notice.
Features
• Pressure measurement of any gas, liquid or oil [fluid type]
except substances which may corrode stainless steel 316L
• Dual display for simultaneous display of process value (PV) and setpoint value (SV)
• Secondary (SV) display : setpoint value, pressure unit, or display-OFF
• Switch between NPN and PNP open collector output via parameter configuration
• 3-color main (PV) display (RUN mode : green/red, parameter setting mode : orange)
• 12-segment LCD display capable of diverse alphanumeric characters
• Measurement range : -100.0 to 100.0 kPa /-100 to 1000 kPa
(Pneumatic type : compound pressure, Fluid type : sealed gauge pressure)
• Analog output : voltage (1-5VDCᜡ), current (DC 4-20mA)
• Copy parameter settings function
• External input : Auto-Shift, Remote, Hold (PSQ-□C□□U-□ models only)
• Forced output control mode for device testing and inspection
• Display resolution : 0.1 kPa /1 kPa (by model)
• One-touch connector type for easy wiring and maintenance
• Password lock for parameter configuration settings
ᜢ ᜽ ᜧ ᜫ
Safety Considerations
• Observe all 'Safety Considerations' for safe and proper operation to avoid hazards.
• ᜸ symbol indicates caution due to special circumstances in which hazards may occur.
᜸ Warning
Failure to follow instructions may result in serious injury or death.
01. Fail-safe device must be installed when using the unit with machinery that
may cause serious injury or substantial economic loss. (e.g. nuclear power
control, medical equipment, ships, vehicles, railways, aircraft, combustion
apparatus, safety equipment, crime / disaster prevention devices, etc.)
Failure to follow this instruction may result in personal injury, economic loss or fire.
02. Do not use the unit in the place where flammable / explosive / corrosive gas,
high humidity, direct sunlight, radiant heat, vibration, impact or salinity
may be present.
Failure to follow this instruction may result in explosion or fire.
03. Install on a device panel or to a pressure port directly to use.
Failure to follow this instruction may result in fire.
04. Do not connect, repair, or inspect the unit while connected to a power
source.
Failure to follow this instruction may result in fire.
05. Check 'Connections' before wiring.
Failure to follow this instruction may result in fire.
06. Do not disassemble or modify the unit.
Failure to follow this instruction may result in fire or electric shock.
᜸ Caution
Failure to follow instructions may result in injury or product damage.
01. Use the unit within the rated specifications.
Failure to follow this instruction may result in fire or product damage.
02. Use a dry cloth to clean the unit, and do not use water or organic solvent.
Failure to follow this instruction may result in fire.
03. This product is designed to detect the pressure of noncorrosive medium. Do
not use for corrosive medium.
Failure to follow this instruction may result in product damage.
04. Keep the product away from metal chip, dust, and wire residue which flow
into the unit.
Failure to follow this instruction may result in fire or product damage.
Cautions during Use
• Follow instructions in 'Cautions during Use' . Otherwise, it may cause unexpected accidents.
• 12 - 24 VDCᜡ power supply should be insulated and limited voltage/current or Class 2, SELV
power supply device.
• Use the product, 3 sec after supplying power.
• When using switching mode power supply, frame ground (F.G.) terminal of power supply
should be grounded.
• Wire as short as possible and keep away from high voltage lines or power lines, to prevent
inductive noise.
• This unit may be used in the following environments.
- Indoors (in the environment condition rated in 'Specifications')
- Altitude max. 2,000 m
- Pollution degree 3
- Installation category II
