WIRELESS BRIDGE

USER MANUAL

Model: CPE365/CPE366

Tips:

Thank you for ordering and using AdaLov CPE365/CPE366 Wireless Bridge,

please read the manual carefully before use.If there are any problems during the

use, please contact us in time.

Customer Service Email: cs@adalovus.com

Table of Contents

Need help?

Do you have a question about the CPE365 and is the answer not in the manual?

Questions and answers

Summary of Contents for Adalov CPE365

Page 1 WIRELESS BRIDGE USER MANUAL Model: CPE365/CPE366 Tips: Thank you for ordering and using AdaLov CPE365/CPE366 Wireless Bridge, please read the manual carefully before use.If there are any problems during the use, please contact us in time. Customer Service Email: cs@adalovus.com...
Page 2: Table Of Contents
English Contents Chapter 1 - Get to Know About Your Wireless Bridge 1.1 Product Overview 1.2 Appearance 1.2.1 Port and Button Description 1.2.2 LED Explanation 1.3 Specifications Chapter 2 - Highlights Chapter 3 - Package Chapter 4 - Wireless Bridge Pairing & Installation 4.1 POE Power Supplyower Supply 4.2 Master Bridge &...
Page 3: Chapter 1 - Get To Know About Your Wireless Bridge
English Chapter 1 Get to Know About Your Wireless Bridge 1.1 Product Overview WLAN Indicator SIG1-SIG4---Signal Light 1000Mbps LAN2 Port 100Mbps LAN1 Port PWR-- Power Indicator Power Indicator Digital Tube 1000Mbps LAN Port DC Jack Reset Button Slave Bridge Indicator A-B Button 100Mbps LAN Port cs@adalovus.com...
Page 4: Appearance
English 1.2 Appearance 1.2.1 Port and Button Description Port or Buttons Description Pushing the button to “A” indicates that the bridge acts as the master bridge(transmitter),and pushing the button to A-B Button “B” indicates that the bridge acts as the slave bridge (receiver) Short press once to toggle a different character to pairing;...
Page 5: Specifications
English 1.3 Specifications Model CPE365/CPE366 7620A + 7612E + IP1001 Flash 8MByte DRAM DDR 264MByte Interface 10/ 100/ 1000Mbps LAN x 1 & 10/100Mbps LAN x 1 Data rate 11a: 54M,48M,36M,24M,18M,12M,9M,6Mbps 11n: 7.2M, 14.4M, 21.7M, 28.9M, 43.3M, 57.8M, 65M, 72.2M,14.4M, 28.9M, 43.3M, 57.8M, 86.7M, 115.6M, 130M, 144.4Mbps 433Mbps...
Page 6: Chapter 2 - Highlights
English Chapter 2 - Highlights 1. Using 5.8Ghz wireless technology; 2. Gigabit wireless bridge with 1000Mbps RJ45 LAN port; 3. Built-in 16dbi high gain directional WiFi antenna; 4. IEEE802.11ac IEEE802.11n, IEEE802.11a, IEEE802.3u; 5. Transmission distance up to 3km(direct line-of-sight); 6. Master bridge supports WiFi hotspot access; 7.
Page 7: Chapter 4 - Wireless Bridge Pairing & Installation
Chapter 4 Wireless Bridge Pairing & Installation 4.1 POE Power Supplyower Supply The CPE365/CPE366 wireless bridge adopts a POE power supply, which is easy to Install and manage while saving costs. (1) According to the requirements, prepare along enough network cable (Recommended within 20 meters, must Cat 5e network cable to connect the wireless bridge and the POE power supply.
Page 8: Master Bridge & Slave Bridge Installation
English 2. Short press the reset button to change the channel from 0-9, A-F, the LED indicator will display the numeric to show what channel it is, please keep the master and slaves bridges in the same channel. Slave CPE Master CPE 3.
Page 9: Installation Steps
English 4.3.2 Installation Steps 1. Put the bridges front side face to face in the same direction, then use the ties to fix the CPE. (Note: The bracket is not included in the package). 2. Use a long network cable to connect the POE adapter and the bridge.
Page 10 English 5. Tips: (1). Before installation, please check whether the wireless bridge is paired well, please refer the master and slave pair setting page. (2). For installation, keep clear line of sight between the 2 wireless bridge. There is no strong electricity, strong magnetism, and other signal interference between the two wireless bridges.
Page 11: Chapter 5 - Application
English Note: (1). The slave bridges must in the front of the master bridge; (2). The master bridge and slave bridges must be face to face; (3). The maximum angle between the master bridge and slave bridges should not exceed 60 degrees. Chapter 5 - Application 5.1 Point to Point for Network Extend Diagram...
Page 12: Multiple Network Equipment Expansion Diagram
English 5.3 Multiple Network Equipment Expansion Diagram 5.4 Point to Multi-Point Connection Diagram 5.5 Multiples Clients Connection Diagram cs@adalovus.com...
Page 13: Relay Mode Connection Diagram
English 5.6 Repeater Mode Connection Diagram Chapter 6 - Computer Access 6.1 Modify Computer’s IP POE Charger Refer to the figure left to connect the CPE to the computer through a POE adapter and an Ethernet cable. Note: You can enable the device without advanced settings 2.
Page 14 English Select Ethernet and click “Change Adapter Options” cs@adalovus.com...
Page 15 English Find the network connection you are using, right click it and select “Properties” cs@adalovus.com...
Page 16: Login Via Browser
English Double-click the “Internet Protocol version 4(TCP/IPv4)” go to IP configure interface Configure your computer IP address as 192.168.255.x (x is a figure 0-200). Note: The Pc’s IP can not be the same as the bridge. 6.2 Login via browser Open the browser and enter the IP address of the wireless bridge to access, for example, enter “192.168.255.101″...
Page 17 English A login screen will appear, by default, the Username and Password of the wireless bridge all are "admin". Note: “admin” is not the password of the WiFi SSID, it is just the password for WEB access cs@adalovus.com...
Page 18 English Digital & IP Chart Digital & A - IP B - IP 5.8G ID WiFi SSID Password IP Chart 192.168.255.100 192.168.255.200 CPE5G_5G0 zllinkcpe1234560 192.168.255.101 192.168.255.201 CPE5G_5G36 zllinkcpe12345636 192.168.255.102 192.168.255.202 CPE5G_5G40 zllinkcpe12345640 192.168.255.103 192.168.255.203 CPE5G_5G44 zllinkcpe12345644 192.168.255.104 192.168.255.204 CPE5G_5G48 zllinkcpe12345648 192.168.255.105 192.168.255.205 CPE5G_5G120...
Page 19: Chapter 7- Advanced Settings
English Chapter 7- Advanced settings 7.1 How to Change Configutation 7.1.1 Set Master bridge Turn off the Digital tube by “Digit-on/off”. (Note:The digital tube mode must be turned off, then the settings could be saved.) Then short press the reset button, the digital tube won’t change the channel.
Page 20 English Hide SSID or Change SSID name and password: In the wireless settings, could turn on/off "Hide SSID", modify the SSID name and WiFi password (Note: Please remember the new SSID name and WiFi password. Because pair two bridges will need them). cs@adalovus.com...
Page 21 English cs@adalovus.com...
Page 22 English Change the IP for the bridge: (I changed it to 116.30.231.100) cs@adalovus.com...
Page 23 English After change the IP, then will appear this page 7.1.2 Set Slave birdge: Open a browser and Enter in the slave bridge’s IP to access in cs@adalovus.com...
Page 24 English Turn off the “Digit on/off”. (Note: The digital tube mode must be turned off, then the settings can be saved.) Change the IP for the slave bridge. (I changed it to 116.30.231.200) cs@adalovus.com...
Page 25 English After change the IP, then will appear this page. cs@adalovus.com...
Page 26 English 7.2 How to pair bridges in non-Digit tube mode (After you change the IP of two bridges, then you want to access in the bridge, please modify your computer’s IP, the IP must be in the same LAN as the bridge.) Change your computer’s IP to 116.30.231.xxx (IP couldn’t be same as two bridges) Open a browser to access in the slave bridge.
Page 27 English (After you change the IP of the two bridges, and if you want to access the bridge, please modify your computer’s IP. The IP must be in the same LAN as the bridge. ) Change your computer’s IP to 116.30.231.xxx (the IP must not be the same as the two cs@adalovus.com...
Page 28 English When the signal indicator lights up, it means pairing is successful. After setting up the bridge, reset your computer's IP. cs@adalovus.com...
Page 29: Chapter 8 - After-Sales Service
English Chapter 8 - After-Sales Service Tips: 1. The installation of this device requires network knowledge, if you can not install it, please contact us or ask a professional for help, if the product you receive is damaged or miss any accessories, please contact us for exchange or resend.
