John JOSI-pro Instructions For Use Manual

Rehab buggy
Hide thumbs Also See for JOSI-pro:
Table of Contents

Advertisement

Quick Links

Download this manual
John GmbH
Ziddelrasen 1b
D-99830 Treffurt
+49 36923 8388-0
info@johngmbh.com
www.johngmbh.com
Rev: 04/11.2024
© John GmbH
JOSI-pro
Rehab buggy
Instructions for use
for authorised dealers and users
Size
Size XS
Size S
Size M
Size L
WE MANUFACTURE IN GERMANY
Qualität, die bewegt
Art. No.
JP-30001
JP-30002
JP-30003
JP-30004
EN
Videos
AL-JP22-EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JOSI-pro and is the answer not in the manual?

Questions and answers

Related Manuals for John JOSI-pro

Summary of Contents for John JOSI-pro

  • Page 1 Size Art. No. Size XS JP-30001 Size S JP-30002 Size M JP-30003 Size L JP-30004 Videos John GmbH Ziddelrasen 1b D-99830 Treffurt +49 36923 8388-0 info@johngmbh.com www.johngmbh.com WE MANUFACTURE IN GERMANY Rev: 04/11.2024 AL-JP22-EN © John GmbH...

  • Page 2: Table Of Contents

    Type-label ............................36 1. Introduction JOSI-pro rehab buggy is a quality product from John GmbH. It is equipped with an integrated seat unit (upholstered cover), tilt-in-space and a back adjustment. The seat depth and lower leg length are infinitely adjustable. Furthermore, the seating system can be equipped with additional components (lateral support, headrest, seat cushion, etc.).

  • Page 3: Intended Use And Indication

    When adjusting the tilt-in-space, always hold the push handle at the same time as opening the quick release. Make sure that the person transported does not lean out of the JOSI-pro. There is a risk of tipping or flipping over. If necessary, arms and legs must be positioned additionally.
  • Page 4 Pay attention to driving stability when travelling on inclines or uneven paths. Do not drive against obstacles. Only lift JOSI-pro by the frame. JOSI-pro must not be lifted by the push handle! Note the weight balance. Only hang the original bag on the push handle as described in the chapter Bag.

  • Page 5: Setting Up

    ü Mosquito net (JP-15600) or rain cover (JP-15300) as protection against insects and small objects (e.g. fine gravel) and to reduce the risk of limbs leaning out. 8. Setting up JOSI-pro JOSI-pro can be stored stand-alone upstanding Remove transportation strap Open buckle Open the buckle and remove the transportation strap around the bottom frame and the back that keeps the JOSI-pro together when folded.
  • Page 6 Transport lowering (optional) The transport lowering is optional and allows the buggy to be folded more compactly. The transport lowering can be retrofitted to JOSI-pro. The lowering cannot be combined with the mounting kit for user transport in motor vehicles.
  • Page 7 Please note: The backrest adjustment may have to be unlocked in order to be able to fold up the backrest. Attention! Danger of jamming back adjustment (A)! The back adjustment moves when the back is folded out. © John GmbH 7/36...
  • Page 8 Close the lower covers for the folding mechanism using the Velcro fastener. 4) Upper cover folding mechanism Close the upper covers for the folding mechanism using the Velcro fastener. 5) Lock the back adjustment Lock the back adjustment into the desired position. © John GmbH 8/36...

  • Page 9: Push Handle

    Attention! Lift JOSI-pro only by the frame. JOSI-pro must not be lifted by the push handle! Only hang the original bag on the sliding arch as described in the Bag chapter.

  • Page 10: Chassis Settings

    (10 - 20%) when the user is at rest. 11. Anti-tip and tipping lever (if equipped) 1) Setting JOSI-pro is equipped with a combined adjustable anti-tipper (A) with an integrated tipping lever (B). Please note: The anti-tipper can be adjusted by pulling lock (C).

  • Page 11: Brakes And Parking Brakes

    For the transfer of the person transported, set the parking brakes and lower the anti- tipper (see chapter Anti-tip and tipping lever). Always park JOSI-pro on horizontal surfaces and firmly apply the parking brake. The drum brakes must be serviced annually by a specialist dealer (see chapter Maintainance and care).

  • Page 12: Front Wheel

    14. Front wheel 1) Available front wheels JOSI-pro can optionally be equipped with the following pneumatic wheels: (A) 12.5" rigid front wheel (B) 8" swivel wheel without locking function (C) 8" swivel wheel Duo (D) 12.5" Front wheel Pro with locking function (E) 8"...

  • Page 13: Front Wheel Adapter And Wheel Change

    3. Tilt adjustment 4. Preparation for foot fixation 2) Adjusting the height of the footrest 1. Unlock the quick release (A). 2. Set the desired height. 3. Lock the quick release (A). © John GmbH 13/36...

  • Page 14: Tilt Adjustment

    Always use two anti-tippers for the backrest adjustment and the reclining position (see chapter Anti-tip and tipping lever). 19. Adjusting the seat and backrest tension 19.1 Adjusting the seat tension 1) Lift seat cushion Lift up the seat cushion. © John GmbH 14/36...
  • Page 15 3) Adjusting the back straps Adjust the individual back straps to the desired position and close the zips again. Please note: The individual back straps can be adjusted to different lengths depending on your wishes and body shape. © John GmbH 15/36...

  • Page 16: Seating System

    2. Fold the back cushion backwards on the upper side to the desired height 3. Velcro it to the inside. 4. Place the back cushion against the back again. 20.3 Seat depth 1) Lift seat cushion Lift up the seat cushion. © John GmbH 16/36...

  • Page 17: Available Belt Systems

    2) Open the back Open the back with the zip to access the belt connector (A). 3) Unhook the belt connector Unhook the belts from the belt connector and guide them forwards through the back. © John GmbH 17/36...
  • Page 18 3) Belt adjuster (A) Unlock the belt adjuster. (B) Adjust the belt to the desired length. Please note: When the belt is adjusted to the desired length, pull the belt buckles (front) to tighten the belt. © John GmbH 18/36...
  • Page 19 At the same time, make sure that the belts are fastened in such a way that the user can breathe freely. 2) Extend belt To extend the belt, press the release and pull the front of the strap. © John GmbH 19/36...
  • Page 20 21.2 Pelvic belt / Chest-shoulder belt / Seat trousers 1) Belt systems The following belt systems can alternatively be attached to the JOSI-pro: (A) Chest-shoulder belt (B) Pelvic belt (C) Seat trousers 21.2.1 Attachment with belt buckles 1) Chest shoulder belt at the bottom and pelvic...
  • Page 21 (D) Fasten the upper straps of the chest shoulder belt crosswise to the upper back arch. (E) Guide the straps around the tube and through the belt adjusters as shown. (F) Close the back and sun canopy again with the zips. © John GmbH 21/36...

  • Page 22: Lateral Support Pro (If Equipped)

    Extension for sun canopy • Mosquito net • Rain cover 23.2 Extension for sun canopy (if equipped) 1) Extension of the sun canopy The extension is attached to one of the two zips (A) on the sun canopy. © John GmbH 22/36...

  • Page 23: Rain Cover & Mosquito Net (If Equipped)

    Use the two zips, left and right, to open and close the bag. 4) Application as open bag To use as an open bag, open both zips and place the lid on the bottom of the bag. © John GmbH 23/36...

  • Page 24: Bike Option (If Equipped)

    Before using the bike option for the first time, be sure to read the chapter Safety instructions in full. 2) Safety bar The push handle of the JOSI-pro is to be turned completely forwards when cycling and therefore serves as a safety bar for the head. Attention! The plastic hinges (A) must be engaged.
  • Page 25 (B) Insert the anti-tipper into the side of the bike drawbar with the small rollers pointing towards the right-hand back wheel of the JOSI-pro and insert the locking pin (1). Place the anti-tipper/wheel deflector in the lowest position so that it is as far outwards as possible.
  • Page 26 (F) Use the Velcro to attach the flag to the push handle. Attention! Follow the enclosed instructions for use of the individual components of the safety kit. Switch on the light at dawn and dusk, in the dark or when visibility conditions require it. © John GmbH 26/36...

  • Page 27: Transport In Vehicles

    ISO 7176-19:2022-04 "Wheelchairs for use as seats in motor vehicles" (hereinafter ISO 7176-19). The JOSI-pro should always be used as a seat in a motor vehicle facing forwards in the direction of travel. The shortest possible turning radius of a wheelchair generally allows easier access to the vehicle and better manoeuvrability in a forward-facing position.
  • Page 28 In the vehicle, always use at the same time the integrated red-coloured lap belt of the fastening kit for vehicle transport in the JOSI-pro, the diagonal shoulder belt fitted in the vehicle and a four- point wheelchair restraint system approved in accordance with ISO 10542 to reduce the possibility of head and chest impact with vehicle parts.
  • Page 29 JOSI-pro must be taken out of service if it has been involved in an accident. If a 16" Decon E-Drive is fitted to the JOSI-pro, it must be switched off or the battery must be removed during vehicle transport. When putting on the diagonal shoulder belt and the wheelchair restraint system, make sure that the belt buckle is positioned so that the release button will not be contacted and opened by components of the JOSI-pro during a crash.
  • Page 30 (D) 2 x safety bolt for the backrest adjustment (if equipped). (E) Reinforcing plate for the tilt-in-space. 2) Tilt-in-space in the upper position (A) The tilt-in-space of the JOSI-pro must be set to the highest position when transporting the vehicle. (B) The safety bolt on the tilt-space should be inserted through the left-hand hole so that downward adjustment is no longer possible.
  • Page 31 6) Integrated red-coloured lap belt The integrated red-coloured lap belt is integrated in the JOSI-pro and must be used during vehicle transport: (A) Place the belt around the user's pelvis and close the buckle. Tighten the belt so that it fits close around stomach and thighs.

  • Page 32: Combination Options With Other Medical Products

    Attention! In addition, note the payload capacity of the different sizes of JOSI-pro (user weight and payload, see chapter Technical data). The payload of 100 kg (16” wheels) of 125 kg (20” wheels with Big Ben tyres) must not be...

  • Page 33: Maintenance And Care

    30. Useful life and long-term durability The useful life of JOSI-pro is set by the manufacturer at 5 years. With regular and proper care, maintenance and repair by the manufacturer, the service life of JOSI-pro can be extended depending on the intensity of use.

  • Page 34: Re-Use

    All serious incidents occurring in connection with the products must be reported to the manufacturer (John GmbH) and the competent authority. „Serious incident“ means any incident that directly or indirectly led, might have led or might lead to any of the following: the death of a patient, user or other person;...

  • Page 35: Dimensions And Weights

    Seat angle approx. 10° - 30° approx. 10° - 30° approx. 10° - 30° approx. 10° - 30° Back angle (optional) approx. 110° - 160° approx. 110° - 160° approx. 110° - 160° approx. 110° - 160° © John GmbH 35/36...

  • Page 36: Type-Label

    1,8 bar 36. Type-label The weather-resistant type label of the JOSI-pro is located on the frame underneath the footrest. If the type-label is no longer legible, be sure to contact your specialist dealer so that a new type- label can be requested from the manufacturer.
  • Page 37 John GmbH Ziddelrasen 1b - D-99830 Treffurt - Tel: +49 36923 8388-0 - Fax: +49 36923 8388-10 - info@johngmbh.com © John GmbH 37/36...
